Yokogawa AFS10S Product Overview
Product Introduction
The Yokogawa AFS10S is an advanced function generator designed to meet the needs of professionals and engineers requiring high-precision signal generation. Part of the AFS Series, this model is renowned for its excellent performance in generating multiple waveform types and its flexibility in use. The AFS10S is equipped with a wide frequency range and is capable of producing sine, square, triangle, and pulse waveforms, making it an essential tool for various signal testing and simulation applications.
With precise control over parameters like frequency, amplitude, and offset, the AFS10S ensures highly accurate signal reproduction for a wide range of testing needs. It also features multiple modulation types (AM, FM, PM), making it suitable for testing communication equipment, power electronics, audio systems, and more.
The AFS Series is widely respected for its ability to generate complex signals with ease and accuracy, making it ideal for both lab environments and industrial applications. The AFS10S model stands out as a reliable, versatile, and cost-effective choice for various applications across sectors like telecommunications, automotive, and research.
Product Parameters
| Parameter | Value |
|---|---|
| Model | Yokogawa AFS10S |
| Frequency Range | 1 Hz to 10 MHz |
| Waveform Types | Sine, Square, Triangle, Pulse |
| Amplitude Range | 1 mV to 10 V peak-to-peak |
| Modulation Types | AM, FM, PM |
| Output Impedance | 50 Ω |
| Power Supply | 100-240 V AC, 50/60 Hz |
| Weight | 2.1 kg |
| Dimensions (LxWxH) | 220 mm x 160 mm x 85 mm |
| Display | 4.3-inch TFT-LCD |
| Accuracy | ±1% of setting |
| Operating Temperature | 0°C to 40°C |
| Protection Rating | IP20 |
| Output Channels | 1 Channel |
| Interface | USB, LAN |
Product Applications
The Yokogawa AFS10S is used in various industries and applications, including:
-
Telecommunications: The AFS10S is ideal for testing RF communication systems, mobile base stations, and communication devices, generating signals used for both modulation and demodulation testing.
-
Automotive Electronics: In automotive applications, the AFS10S is used to simulate and test signals for ECUs, sensors, and controllers in automotive systems.
-
Power Electronics: The AFS10S is capable of simulating various types of voltage and current signals for power supply testing, including pulse-width modulation (PWM) and sine-wave output for inverter testing.
-
Audio Testing: Engineers use the AFS10S to generate accurate audio waveforms, testing audio devices like amplifiers, mixers, and sound systems with high-quality signals.
-
R&D: Researchers use the AFS10S to generate custom waveforms for experiments that require high-frequency signal simulations, such as signal processing and systems testing.
Product Advantages
-
Wide Frequency Range: The AFS10S can generate frequencies from 1 Hz to 10 MHz, making it highly versatile and capable of handling a wide array of testing scenarios.
-
Multiple Waveforms: The ability to generate sine, square, triangle, and pulse waveforms gives users flexibility for testing and simulations across different fields.
-
Modulation Capabilities: The AFS10S supports AM, FM, and PM modulation, making it suitable for complex signal testing in telecommunications and audio systems.
-
Compact and Portable: Weighing only 2.1 kg and with compact dimensions (220 mm x 160 mm x 85 mm), it is easy to transport and use in both laboratory and field environments.
-
High Accuracy: The AFS10S offers ±1% accuracy, ensuring reliable and precise waveform generation, which is critical for high-precision applications.
-
User-Friendly Interface: The 4.3-inch TFT-LCD display provides an intuitive interface with easy-to-read waveform visualization and parameter adjustment, enhancing usability for engineers.
-
Remote Control and Integration: The AFS10S supports USB and LAN connectivity for remote operation and integration into automated test systems.
-
Reliable and Durable: With an IP20 protection rating, the AFS10S is built to withstand typical indoor conditions, offering reliability and longevity in demanding environments.
Brand and Series
-
Brand: Yokogawa
-
Series: AFS Series (Function Generators)
The AFS Series from Yokogawa is well-known for its high-quality function generators, offering a range of versatile, reliable, and precise waveform generation tools. The series is trusted by professionals in many industries for its performance, ease of use, and long-lasting durability.
Recommended Models in the Same Series
| Model | Frequency Range | Waveform Types | Amplitude Range | Weight (kg) | Dimensions (mm) |
|---|---|---|---|---|---|
| AFS20S | 1 Hz to 20 MHz | Sine, Square, Arbitrary | 1 mV to 20 V peak-to-peak | 2.3 kg | 230 x 170 x 90 |
| AFS50S | 1 Hz to 50 MHz | Sine, Square, Arbitrary | 1 mV to 10 V peak-to-peak | 2.8 kg | 250 x 180 x 95 |
| AFS100S | 1 Hz to 100 MHz | Sine, Square, Arbitrary | 1 mV to 10 V peak-to-peak | 3.1 kg | 270 x 200 x 110 |
| AFS300S | 1 Hz to 300 MHz | Sine, Square, Arbitrary | 1 mV to 5 V peak-to-peak | 3.5 kg | 280 x 210 x 120 |
| AFS2000S | 1 Hz to 2 GHz | Sine, Square, Arbitrary | 1 mV to 10 V peak-to-peak | 4.0 kg | 300 x 220 x 140 |
Recommended Models from Yokogawa (Other Popular Models)
| Model | Frequency Range | Waveform Types | Amplitude Range | Weight (kg) | Dimensions (mm) |
|---|---|---|---|---|---|
| Yokogawa AFG310 | 1 Hz to 30 MHz | Sine, Square, Arbitrary | 10 mV to 10 V peak-to-peak | 3.0 kg | 250 x 175 x 95 |
| Yokogawa FG300 | 1 Hz to 100 MHz | Sine, Square, Arbitrary | 1 mV to 20 V peak-to-peak | 3.4 kg | 260 x 180 x 100 |
| Yokogawa GS200 | 1 Hz to 10 MHz | Sine, Square, Triangle | 10 mV to 5 V peak-to-peak | 2.0 kg | 230 x 160 x 90 |
| Yokogawa AFG500 | 1 Hz to 50 MHz | Sine, Square, Arbitrary | 1 mV to 10 V peak-to-peak | 2.7 kg | 240 x 170 x 85 |
| Yokogawa DL350 | DC to 5 MHz | Sine, Square, Arbitrary | 1 mV to 10 V peak-to-peak | 3.6 kg | 260 x 180 x 95 |
Frequently Asked Questions (FAQ)
Q1: What is the frequency range of the AFS10S?
A1: The AFS10S has a frequency range from 1 Hz to 10 MHz, making it versatile for both low and high-frequency applications.
Q2: Does the AFS10S support modulation?
A2: Yes, the AFS10S supports AM, FM, and PM modulation, making it suitable for testing communication systems.
Q3: What is the weight of the AFS10S?
A3: The AFS10S weighs 2.1 kg, making it compact and portable for easy transport.
Q4: Can the AFS10S be used for audio testing?
A4: Yes, the AFS10S can generate sine and square waveforms ideal for testing audio systems, amplifiers, and mixers.
Q5: What is the output impedance of the AFS10S?
A5: The output impedance of the AFS10S is 50 Ω, suitable for a wide range of applications requiring standard impedance matching.
Q6: What is the accuracy of the AFS10S?
A6: The accuracy of the AFS10S is ±1% of setting, ensuring precise signal generation for critical testing applications.
Q7: Can I control the AFS10S remotely?
A7: Yes, the AFS10S supports USB and LAN interfaces for remote control and integration into automated test setups.
Q8: What is the power supply requirement for the AFS10S?
A8: The AFS10S requires a 100-240 V AC, 50/60 Hz power supply, making it compatible with standard power sources worldwide.
Q9: What are the available waveform types on the AFS10S?
A9: The AFS10S can generate sine, square, triangle, and pulse waveforms for a variety of testing needs.
Q10: Is the AFS10S suitable for research and development applications?
A10: Yes, the AFS10S is ideal for R&D, allowing engineers to generate precise signals for experiments, signal processing, and system testing.
