Product Model: Yokogawa ADV551‑P00
Brand: Yokogawa
Series: ADV551 Series – Digital Output Modules
Product Introduction
The ADV551‑P00 is a 32‑channel digital output module designed for industrial automation and control‑system use. It provides a high‑density discrete output solution, capable of driving field devices such as solenoids, relays, indicators, actuators and other 24 V DC loads from a control system interface.
As part of the ADV551 series, this module is engineered for reliability, fast response and compact installation in I/O racks. Its designation “P00” indicates that it is the basic version of the module (i.e., without extended options such as status display, explosion protection, or special temperature ratings).
The module supports a 24 V DC nominal output voltage, with each of the 32 output channels offering current‑sink format, allowing for direct connection of compatible field devices. The compact build and platform compatibility make it suitable for system expansion, retrofit projects or new installations in process, manufacturing, utility or infrastructure applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Number of Output Channels | 32 channels |
| Rated Applied Voltage | 24 V DC nominal |
| External Power Supply Voltage Range | 20.4 to 26.4 V DC |
| Output Format | Current sink digital outputs |
| Maximum Load Current per Channel | Approx. 100 mA per channel (at ~26.4 V) |
| Output ON Voltage Maximum | ≤ 2 V DC (maximum voltage drop when ON) |
| Leakage Current when OFF | ≤ 0.1 mA (typical) |
| Withstanding Voltage (Isolation) | Between output signal & system: ~2 kV AC (1 min) Between commons (every 16 channels): ~500 V AC (1 min) |
| Output Response Time | ≤ 3 ms for status output ≤ 10 ms for mixed status/pulse outputs |
| Pulse Width (when supported) | 8 ms to 7200 s (for variants supporting pulse width) |
| Maximum Current Consumption | ≈ 700 mA at 5 V DC internal logic |
| Dimensions (W × H × D) | Approx. 107.5 mm × 130 mm × 32.8 mm |
| Weight | Approx. 0.20 kg |
| Operating Temperature Range | –20 °C to +60 °C (typical for base version) |
Applications
-
Process control systems (e.g., chemical plants, petrochemical facilities, power generation) where multiple discrete output devices must be driven reliably.
-
Manufacturing automation systems (assembly lines, machine control) where many output points are required, and a high‑density module reduces rack footprint and wiring.
-
Utilities and infrastructure (water/wastewater treatment, pump stations, motor control) where many relay/solenoid outputs are used.
-
I/O rack expansion or retrofit scenarios where existing systems need additional output capacity without expanding cabinet size significantly.
-
Automation systems requiring both standard ON/OFF control of outputs and, in variant modules, time‑proportioned or pulse width outputs for more advanced control logic.
Advantages
-
High channel density: 32 discrete outputs in one compact module means fewer modules, less wiring and a smaller cabinet footprint.
-
Robust electrical design: Strong isolation (2 kV AC between signal and system, 500 V between commons), low leakage current, and current‑sink outputs deliver reliable performance in industrial environments.
-
Fast response time: Status output response of ≤ 3 ms ensures timely control of field devices and supports real‑time system demands.
-
Compact and lightweight: At around 0.20 kg and modest dimensions, the module is easy to install and manage even in tight rack space.
-
Platform compatibility: As part of the ADV551 series, it integrates into established Yokogawa I/O systems — simplifying integration, spare‑parts management and system expansion.
-
Installation efficiency: High density + standard connections reduce wiring, terminal blocks and installation time — lowering cost and complexity.
-
Flexible control capability: While the “P00” base version supports ON/OFF outputs, the series offers variants that add pulse width or time‑proportioning features, enabling more advanced control when needed.
-
Durable long‑term performance: Designed for industrial ambient conditions, the module is built to perform reliably over time in maintenance‑friendly configurations.
Related or Same‑Series Models (within ADV551 or related I/O modules)
| Model | Key Specification / Description |
|---|---|
| ADV551‑P00 | Basic 32‑channel digital output module (this model). |
| ADV551‑P50 | 32‑channel digital output module variant with pulse width/time‑proportional output support. |
| ADV551‑P63 | Output module variant with additional status display or extended temperature option. |
| ADV561‑32DO | 64‑channel digital output module in same platform family for higher density output needs. |
| ADV151‑P10 | 32‑channel digital input module in same I/O ecosystem (input side companion). |
Popular Yokogawa Models (same brand)
| Model | Description / Typical Specification |
|---|---|
| ADV161‑P00 | 64‑channel digital input module — high‑density input counterpart in the ecosystem. |
| ADV169‑P00 | 64‑channel digital input module variant — for many discrete input points. |
| ADV171‑P00 | 16‑channel analog input module — for process variable sensing. |
| ADV181‑P00 | 16‑channel analog output module — for analog control and actuator driving. |
| ADV151‑E63 S2 | Advanced digital input module with enhanced diagnostics and monitoring functions in the Yokogawa I/O family. |
FAQ – Frequently Asked Questions (10 Q&A)
Q1: How many output channels does the ADV551‑P00 provide?
A1: It provides 32 discrete digital output channels in one module.
Q2: What voltage does this module operate on?
A2: The module uses a nominal 24 V DC applied voltage, typically in a range of 20.4 to 26.4 V DC.
Q3: What is the maximum load current per channel?
A3: Each channel can handle up to approximately 100 mA when operating near the upper supply voltage (~26.4 V).
Q4: How fast does the module respond when an output is activated?
A4: For status ON/OFF outputs the response time is ≤ 3 ms; when using mixed status and pulse‑width outputs the response may be ≤ 10 ms.
Q5: What are the physical dimensions and weight of the module?
A5: Dimensions are approximately 107.5 mm wide × 130 mm high × 32.8 mm deep. Weight is about 0.20 kg (200 grams).
Q6: What type of output format does the module use?
A6: It uses current‑sink digital outputs suited for field devices compatible with 24 V DC control.
Q7: Can the module support advanced output functions such as pulse width or time‑proportioned outputs?
A7: The base “P00” version is focused on ON/OFF status outputs. However, the ADV551 series overall includes variants (e.g., P50) that support pulse width and time‑proportioning output functions.
Q8: Is this module compatible with the Yokogawa I/O platform and backplane?
A8: Yes — the module is part of the ADV551 series designed for Yokogawa I/O base frames, backplanes and cable systems, enabling integration with control systems and ease of replacement/spare parts.
Q9: What operating environment conditions does it support?
A9: Typical ambient operating conditions are from approximately −20 °C to +60 °C, and it is built to function in industrial automation environments with appropriate ventilation and wiring shielding.
Q10: How should I replace or maintain this module in the system?
A10: To replace: power down the I/O rack or isolate the backplane; remove the module; install the replacement into the same slot; reconnect any field wiring or terminal blocks; restore power; and perform channel tests to verify correct output functioning. Regular inspection of wiring, terminals and module seating is also advised.
