Product Introduction

The ADV151‑P60/D5A00 is a 32‑channel digital input module, designed for demanding industrial automation and process‑control systems. It is part of the Yokogawa ADV151 series of field I/O digital input modules.

This variant uses the suffix “P60” to indicate that it supports push‑button input mode and status display capability, and the option code “/D5A00” indicates the inclusion of the KS Cable Interface Adapter (model ATD5A‑00) for streamlined 32‑channel digital input wiring. It accepts 24 V DC discrete ON/OFF signals (sink or source), has strong electrical isolation, fast input response and high channel density. It is suited for use in systems such as DCS, remote I/O racks, manufacturing automation, utilities and large‑scale installations where high reliability, compact wiring and maintainability are crucial.

The module is typically used to capture a large number of field discrete signals (switches, push‑buttons, limit contacts, sensors) and transfer them reliably into the control logic environment. With the high‑density 32‑channel input, wiring adapter, and standard 24 V interface, the ADV151‑P60/D5A00 reduces cabinet space, simplifies wiring, and supports long‑term field operation with minimal maintenance.

Technical Specifications

Applications

• In distributed control systems (DCS) and field I/O racks, the ADV151‑P60/D5A00 is used to capture discrete ON/OFF signals from field devices such as limit switches, float switches, push‑buttons, proximity sensors, relay contacts, and transfer them reliably into the control logic for monitoring, interlocks and automation.

• In manufacturing automation installations, it monitors numerous machine status inputs, operator panel switches, conveyor run/stop signals, emergency stop buttons and other discrete input signals, offering high density in a compact module which reduces cabinet footprint and wiring complexity.

• In process industries such as oil & gas, petrochemical plants, power generation, water/wastewater treatment and utilities, the module supports acquisition of large numbers of digital input points, providing strong electrical isolation to cope with harsh environments, noise, ground loops and long service life demands.

• In redundant or high‑availability system architectures, the module supports installation in dual‑channel or redundant I/O racks, enabling fault‑tolerant operation, minimal downtime and high system availability.

• In retrofit or expansion projects, where new discrete input points must be added but wiring cost, space and installation time are constrained, the high‑density 32‑channel input module with a wiring adapter allows a streamlined upgrade path, reduced downtime, and simplified field integration.

Advantages

1. High channel density – With 32 discrete input channels in one module slot, the ADV151‑P60/D5A00 significantly reduces the number of modules required, lowers wiring complexity and conserves cabinet space.

2. Fast and accurate signal acquisition – With an input response time of ≤ 8 ms for status inputs, and support for push‑button input mode with minimum ON detection ~20 ms and maximum cycle ~25 Hz, the module ensures timely detection of digital events and quick reaction in control logic.

3. Robust electrical isolation and noise immunity – The 2 kV AC withstand voltage between input signals and system, and 500 V AC between each group of 16 channels and system, provide strong protection against interference, ground loops and harsh electrical environments.

4. Standard 24 V DC discrete input interface – Compatible with widely used industrial switches and sensors, making integration easier and reducing the need for signal conversion or conditioning.

5. Compact and lightweight design – With approximate weight 0.30 kg and a size of ~10.7 × 13.0 × 3.3 cm, the module is easy to install, replace or maintain in dense I/O racks or tight panel space.

6. Simplified wiring via adapter – The “/D5A00” option equips the module with the KS Cable Interface Adapter, which simplifies 32‑channel wiring, improves field installation speed, reduces connection errors and supports efficient maintenance.

7. Redundancy‑ready architecture – Designed to support field I/O racks with redundant channels or dual modules, enabling high system availability and reliability in mission‑critical automation installations.

8. Proven field I/O platform – Being part of the ADV151 series, the module benefits from a mature ecosystem, long term serviceability and integration compatibility with Yokogawa automation platforms.

Brand & Series

• Brand: Yokogawa

• Series: ADV151 Digital Input Module Series

• Category: 24 V DC isolated digital input modules (32‑channel high‑density)

• Positioning: The ADV151 series serves as the digital input family for Yokogawa’s field I/O architecture: modules with various feature levels, channel counts, environmental ratings and wiring interface options. The ADV151‑P60/D5A00 variant is positioned for customers requiring 32 channels, push‑button input support, high density, a wiring adapter, and installation in demanding environments.
