Product Introduction

The ADV151‑P60/B5S00 is a 32‑channel digital input module designed for use in advanced industrial automation and process control systems. It belongs to Yokogawa’s ADV151 series of field I/O modules.

This variant features the “P60” suffix, meaning it supports push‑button input capability and status display, while the “/B5S00” denotes a pressure‑clamp terminal block (model ATB5S‑00) for field wiring. With 32 discrete inputs at 24 V DC, strong electrical isolation, fast response time and high channel density, the module is intended for demanding applications including manufacturing automation, utilities, power generation, oil & gas and process plants. The compact design and wiring terminal option make the module suitable for retrofit or expansion projects where cabinet space, wiring cost and reliability are key factors.

Technical Specifications

Applications

• In distributed control systems (DCS) and field I/O racks the ADV151‑P60/B5S00 acquires ON/OFF signals from field devices such as limit switches, float switches, proximity sensors, push‑buttons, and relay contact outputs, and forwards them to the control logic for monitoring, alarms, interlocks and sequencing.

• In manufacturing automation installations the module monitors machine status inputs, operator panel switches, conveyor run/stop feedback, emerg­ency stop buttons and other digital inputs, providing high‑density input in one module for panel space efficiency.

• In process industries such as oil & gas, petrochemical, power generation, water and wastewater treatment, and utilities, the module supports large volumes of discrete input signals, offering robust isolation, fast response and long‑term field reliability even in harsh ambient or electrical noise conditions.

• In redundant or high‑availability architectures where dual I/O paths or redundant racks are required for continuous operation, the ADV151‑P60/B5S00 supports field I/O architectures that require fault‑tolerant installations and minimal downtime.

• In retrofit or expansion projects where many new discrete input points must be added but space, wiring cost or time are constrained, this high‑density module combined with the pressure‑clamp wiring option simplifies installation and reduces overall cabinet cost.

Advantages

1. High channel density – With 32 input channels in one module, the ADV151‑P60/B5S00 reduces the number of modules needed, wiring complexity and panel footprint.

2. Fast and accurate detection – With status‑input response time of ≤ 8 ms and push‑button detection capability (minimum ON 20 ms, maximum cycle up to ~25Hz), the module supports timely acquisition of discrete events.

3. Robust electrical isolation and noise immunity – Withstanding ratings of 2 kV AC between input and system and 500 V AC between channel groups help maintain signal integrity under noisy industrial conditions.

4. Standard industrial interface – Accepts 24 V DC discrete signals (sink/source) common in industrial instrumentation, easing integration and reducing signal‑conditioning needs.

5. Compact and lightweight – Approximate weight of 0.30 kg and dimensions around 10.7 × 13.0 × 3.3 cm make installation in tight I/O racks simpler.

6. Simplified wiring – The inclusion of a pressure‑clamp terminal block (ATB5S‑00) provides secure and efficient field wiring, reducing installation effort and time.

7. Redundancy‑ready architecture – Compatible with field I/O racks that support dual redundant modules, enabling higher uptime and fault tolerance.

8. Long‑term field performance – As part of the ADV151 series, this module integrates with a proven ecosystem and offers reliable performance in industrial automation environments.

Brand & Series

• Brand: Yokogawa

• Series: ADV151 Digital Input Module Series

• Category: 24 V DC isolated digital input modules (32‑channel high‑density)

• Positioning: The ADV151 series offers digital input modules, digital output modules, analog input/output modules and event‑capture modules for field I/O racks in process automation systems. The P60/B5S00 variant specifically addresses high‑density discrete input needs with push‑button detection, status display capability, and wiring terminal block convenience in rugged conditions.
