Product Overview

The Yokogawa ADV151‑P13/D5A00 is a high‑density digital input module designed for advanced industrial automation and process control systems. It belongs to the ADV151 series of digital input modules. The module accepts discrete ON/OFF signals at 24 V DC from field devices such as push‑buttons, limit switches, proximity sensors, relay contacts and other digital‑type devices, and converts them into logic inputs for the control system.

The variant P13 indicates a particular configuration of the ADV151 line, and the option code /D5A00 signifies the module is equipped with the KS Cable Interface Adapter (ATD5A‑00) or equivalent, enabling simplified wiring of the 32‑channel digital input. The module offers robust electrical isolation, fast response times, high channel count in one unit, and compatibility with redundant I/O setups, making it highly suited for large‑scale industrial environments, retrofits or new installations where reliability, wiring simplicity and compactness matter.

Technical Specifications

Applications

• In distributed control systems (DCS) and field I/O cabinets, this module serves to capture ON/OFF signals from field devices like limit switches, float switches, proximity sensors, push‑buttons and relay contacts, and passes them into the controller logic for monitoring, alarms, interlocks and sequencing.

• In manufacturing automation environments it monitors machine status inputs, operator panel buttons, safety interlocks, conveyor run/stop signals, and other discrete field inputs, providing high‑density input acquisition.

• In process industries such as oil & gas, petrochemical, power generation, water treatment, and utilities where large volumes of discrete inputs must be reliably acquired, isolated and transferred into the automation system—even under electrically noisy conditions.

• In redundant or high availability system installations where dual channel or redundant I/O racks are required, this module supports the field I/O architecture designed for high uptime and fault tolerance.

• In retrofit or system expansion projects, where compact size, standardized 24 V input interface, and compatibility with existing I/O ecosystems enable easier upgrades without major wiring overhaul.

Advantages

1. High channel density – With 32 channels in one module, cabinet space and wiring cost are reduced, simplifying installation and maintenance.

2. Fast response and accurate detection – With ≤ 8 ms status input response and push‑button detection capability, the module supports timely and accurate acquisition of digital events.

3. Strong electrical isolation and noise immunity – Withstanding voltage ratings (2 kV AC between input signal and system, 500 V AC between commons) help protect against ground loops, electromagnetic interference and harsh environments.

4. Standard discrete interface – Accepts 24 V DC ON/OFF signals, compatible with many field devices and control systems, simplifying integration and reducing signal conditioning needs.

5. Compact and lightweight design – At approx. 0.30 kg and moderate dimensions, the module is easy to handle, install and replace in tight rack spaces.

6. Redundancy‑ready design – Its architecture supports field I/O redundancy, enabling continuous operation and improved system availability in mission‑critical applications.

7. Flexible wiring and modularity – The /D5A00 option (KS cable interface) and compatible wiring options reduce wiring complexity and facilitate field replacements and upgrades.

8. Proven field I/O ecosystem – As part of the ADV151 series, this module enjoys long‑term support, compatibility with a wide I/O rack system and ease of combination with output and analog modules.

Brand & Series

• Brand: Yokogawa

• Series: ADV151 Digital Input Module Series

• Category: 24 V DC isolated digital input modules (high‑density 32‑channel type)

• Positioning: The ADV151 series is designed for field I/O racks and distributed control systems, offering digital input, digital output, analog input/output and event capture modules. The ADV151‑P13/D5A00 variant provides 32‑channel digital input capability in a compact form designed for large‐scale automation systems.
