Product Overview
Brand: Yokogawa
Series: ADV151 Series – Digital Input Modules (32‑channel, 24 V DC domain)
Model: ADV151‑P00 S2
The ADV151‑P00 S2 is a 32‑channel digital input module designed for industrial automation and process‑control systems. It supports 24 V DC discrete ON/OFF signals from field devices such as switches, proximity sensors and push‑buttons. The “P” suffix indicates support for push‑button input (edge detection) in addition to standard status input, the “00” denotes the basic feature set, and “S2” indicates a hardware/firmware revision 2 of the P00 variant.
This module is suited for modular rack/back‑plane I/O systems, typical in large distributed control systems (DCS) or manufacturing automation platforms. Its high channel density, compatibility with the Yokogawa ADV151 family, and support for push‑button inputs make it an efficient choice for discrete input acquisition.
Technical Specifications
| Parameter | Description |
|---|---|
| Number of input channels | 32 channels |
| Rated input voltage | 24 V DC (sink or source compatible) |
| Input ON voltage range | ~18 – 26.4 V DC |
| Input OFF voltage threshold | ≤ 5.0 V DC |
| Typical input current per channel | ~4.1 mA ± 20% at rated voltage |
| Maximum allowable input voltage | ~30.0 V DC |
| Isolation (input ↔ system) | 2 kV AC for 1 minute |
| Isolation between channel‐common groups (per 16 channels) | 500 V AC for 1 minute |
| Input response time (status mode) | ≤ 8 ms |
| Minimum ON detection time (push‑button mode) | ≈ 20 ms |
| Maximum ON/OFF cycle rate (push‑button mode) | ~25 Hz |
| Dimensions (W × H × D) | Approx. 107 mm × 130 mm × 33 mm |
| Weight | Approx. 0.30 kg |
| Operating ambient temperature range | –20 °C to +70 °C |
| Field‑wiring interface | Standard terminal block / cable adapter depending on variant |
Applications
-
Acquisition of 24 V DC discrete ON/OFF signals from field devices (limit switches, selector switches, push‑buttons, proximity sensors) in manufacturing automation lines.
-
Integration into modular I/O racks/back‑planes within DCS systems, especially in process industries (chemicals, power generation, utilities) needing many discrete input points.
-
Monitoring operator panel push‑buttons, machine start/stop controls, interlocks and other human‑machine interface discrete signals (thanks to push‑button support).
-
Building automation and infrastructure: collecting discrete status inputs from alarms, switchgear, lighting/hvac discrete signals in large facilities.
-
Retrofit or extension of existing systems: upgrading an older discrete‑input architecture to a modern, high‑density input module while retaining 24 V DC domain and modular rack format.
Advantages
-
High channel density: 32 inputs in one module reduce rack space, wiring complexity and streamline system I/O architecture.
-
Push‑button edge detection support: The “P” variant supports detecting push‑button input changes, making it suitable for panel and operator‑controlled discrete inputs.
-
Robust electrical isolation and noise immunity: Withstanding voltages of 2 kV between input and system, and 500 V between common groups, provide reliability in electrically noisy industrial environments.
-
Fast response time: ≤ 8 ms for status input ensures timely capture; push‑button detection (~20 ms min ON) supports operator panel responsiveness.
-
Compact and lightweight: At approx. 107 × 130 × 33 mm and ~0.30 kg, the module is easy to install, maintain and replace.
-
Modular system compatibility: Plug‑in design works with the ADV151 series I/O rack/back‑plane systems, facilitating expansions and replacements with minimal wiring changes.
-
Wide ambient tolerance: –20 °C to +70 °C operating range makes it suitable for demanding industrial environments.
-
Proven brand & ecosystem: Part of the Yokogawa ADV151 series, offering long‑term support, compatibility and proven field performance.
Recommended Related Models (Same Series or Adjacent)
| Model | Description |
|---|---|
| Yokogawa ADV151‑P10 S2 | 32‑channel, 24 V DC digital input module, “P10” variant (similar push‑button support) in the ADV151 family. |
| Yokogawa ADV151‑E00 | 32‑channel, 24 V DC input module, “E00” variant (basic status input version without push‑button support) in same family. |
| Yokogawa ADV151‑E63 S2 | Advanced 32‑channel digital input module, “E63” variant (SOE capture, status display) in the ADV151 line. |
| Yokogawa ADV161‑P00 | 64‑channel 24 V DC digital input module (higher channel count version in adjacent ADV161 series) for large‑scale I/O systems. |
| Yokogawa ADV551‑P10 | 32‑channel digital output module (24 V DC outputs) from the same brand ecosystem, useful when paired with input modules. |
Recommended Popular Models (Same Brand)
| Model | Description |
|---|---|
| Yokogawa ADV551‑P10 S2 | 32‑channel digital output module (24 V DC outputs), popular in industrial automation setups. |
| Yokogawa AAB841‑S00 | Analog I/O module (1‑5 V / 4‑20 mA) widely used within the same brand for process variable measurement. |
| Yokogawa SDV144‑S33 S2 | 24 V DC digital input module (16 channel) alternative family, popular in retrofits. |
| Yokogawa ADV559‑P00 | Variant digital output module within the same brand, widely used. |
| Yokogawa Modec SDV144 | Digital input module family recognized in the same brand ecosystem; though slightly different series, still relevant for comparisons. |
FAQ (10 Questions & Answers)
Q1: What input voltage does the ADV151‑P00 S2 accept?
A1: The module is designed for 24 V DC discrete input signals (sink or source compatible).
Q2: How many input channels does it provide?
A2: 32 independent input channels.
Q3: What are its approximate physical size and weight?
A3: Approximate dimensions are 107 mm (W) × 130 mm (H) × 33 mm (D) and weight about 0.30 kg.
Q4: Does the module support push‑button edge detection?
A4: Yes — the “P” suffix indicates support for push‑button input (edge detection) in addition to status ON/OFF detection.
Q5: What level of isolation protection is offered?
A5: The module provides 2 kV AC isolation between input signal and system for 1 minute, and 500 V AC isolation between common channel groups (per 16 channels) for 1 minute.
Q6: What’s the input response time for status inputs or push‑button mode?
A6: For status input the response time is ≤ 8 ms; for push‑button mode, minimum ON detection ~20 ms and maximum ON/OFF cycling around ~25 Hz.
Q7: Is this module suitable for harsh industrial environments?
A7: Yes — it supports an operating ambient temperature range of –20 °C to +70 °C and is built with rugged isolation and modular design for industrial use.
Q8: Can it be used in redundant I/O configurations within a rack/back‑plane?
A8: Yes — the ADV151 family supports modular rack/back‑plane installation; redundancy configuration depends on overall system architecture.
Q9: What field wiring connection does it use?
A9: The module uses standard terminal block or dedicated cable adapter connections. Field wiring may use pressure clamp terminals or cable connector options specific to variant.
Q10: Can this module replace older discrete‑input modules?
A10: Yes — provided the back‑plane/rack architecture supports the ADV151 family and 24 V DC discrete input domain, the ADV151‑P00 S2 can serve as a modern upgrade or replacement.
