Product Overview
Brand: Yokogawa
Series: ADV151 Series – Digital Input Modules (24 V DC discrete input)
Model: ADV151‑E63/D5A00
The ADV151‑E63/D5A00 is a high‑performance digital input module designed for industrial automation and process‑control systems. Belonging to the ADV151 family, it supports 24 V DC ON/OFF signals and offers advanced features such as sequence‑of‑events (SOE) capture, status display, and high‑isolation construction. The suffix “E” indicates SOE capture capability, “6” indicates status display version (no explosion proof), “3” indicates the ISA G3 option (wide temperature / corrosion resistance), and the “/D5A00” option indicates the module is supplied with the KS Cable Interface Adapter (ATD5A‑00) for 32‑channel digital input wiring.
This module is suited for applications where discrete input reliability matters, event logging is required, and integration into modular I/O racks/back‑planes is needed—such as in power generation, oil & gas, chemical plants, utilities, and large manufacturing systems.
Technical Specifications
| Parameter | Description |
|---|---|
| Number of input channels | 32 channels (some configurations may support 64) |
| Rated input voltage | 24 V DC (sink or source compatible) |
| Input ON voltage range | 20 V to 26.4 V DC |
| Input OFF voltage threshold | ≤ 5.0 V DC |
| Typical input current per channel | ~2.5 mA (±20%) |
| Maximum allowable input voltage | 30.0 V DC |
| Withstanding voltage (input ↔ system) | 2 kV AC for 1 minute |
| Withstanding voltage (between commons every 16 channels) | 500 V AC for 1 minute |
| Input response time (status input) | ≤ 8 ms |
| Minimum ON detection time (push‑button input) | ~20 ms |
| Maximum ON/OFF cycle rate (push‑button mode) | Up to ~25 Hz |
| Dimensions (W × H × D) | ~ 51 mm × 254 mm × 114 mm |
| Weight | ~ 0.63 kg |
| Operating temperature range | –20 °C to +70 °C |
| Field‑wiring interface | KS Cable Interface Adapter (ATD5A‑00) included (option /D5A00) |
Applications
-
Capturing discrete 24 V DC ON/OFF signals from field devices such as selector switches, proximity sensors, push‑buttons, limit switches, relay contacts.
-
Integration into distributed control systems (DCS) or modular I/O racks in process plants (chemical, petrochemical, power, utilities) where many discrete input points need to be reliably monitored.
-
Systems requiring sequence‑of‑events logging: when timestamping of discrete input changes is critical (e.g., plant event tracking, safety interlocks, fault diagnostics).
-
Machine automation systems: monitoring safety interlocks, conveyor endpoints, operator panel button presses, safety‑door sensors, emergency stops.
-
Building/infrastructure automation: capturing status signals from switchgear, alarms, lighting/discrete control panels, facility management systems.
-
Retrofit or expansion projects: replacing older discrete input modules with modern high‑density modules featuring event logging and high isolation.
Advantages
-
High channel density: 32 input channels (or more in some configurations) in one module reduce rack footprint and wiring cost.
-
SOE capture capability: Enables event logging of discrete input changes, which adds diagnostic and fault‑analysis value.
-
Robust electrical isolation & noise immunity: Withstanding voltages of 2 kV AC input‑to‑system and 500 V AC between channel commons ensure reliable performance in industrial environments.
-
Fast response time: ≤ 8 ms status detection supports real‑time operations; push‑button capability further enhances flexibility.
-
Modular system integration: Designed for plug‑in back‑plane or I/O rack installation, making system expansion and maintenance easier.
-
Wide environmental tolerance: Operation down to –20 °C and up to +70 °C suits harsh industrial conditions.
-
Field‑wiring option included: With the /D5A00 option, the module comes with the KS cable interface adapter, simplifying wiring.
-
Brand reliability & ecosystem: As part of the Yokogawa ADV151 series, long service life, spare availability and compatibility are assured.
Recommended Related Models (Same Series or Adjacent)
| Model | Description |
|---|---|
| ADV151‑E10 | 32‑channel, 24 V DC digital input module, basic “E10” variant status SOE version. |
| ADV151‑P00 | 32‑channel digital input module, basic “P00” variant (push‑button/discrete input variant) with D5A00 wiring adapter option. |
| ADV151‑P60 | 32‑channel digital input module, push‑button detection variant (P60 suffix) with advanced features. |
| ADV151‑E00 | 32‑channel digital input, basic “E00” status‑input version without additional display or push‑button features. |
| ADV161‑P50 | 64‑channel digital input module (higher channel‑count in adjacent series ADV161, 24 V DC domain) for large‑scale I/O systems. |
Recommended Popular Models (Same Brand)
| Model | Description |
|---|---|
| ADV551‑P53 | 32‑channel digital output module (24 V DC outputs) for actuator and drive control in industrial systems. |
| ADV151‑P13 | 32‑channel digital input module (24 V DC) simpler variant, widely used in plant automation. |
| ADV551 | Digital output module family, popular in discrete I/O systems for control and switching tasks. |
| ADV151‑P10 | 32‑channel digital input module (24 V DC) standard variant in the ADV151 family. |
| ADV151‑E00 | 32‑channel digital input module (24 V DC) basic status‑input version – low‑feature count but strong reliability. |
FAQ (10 Questions & Answers)
Q1: What is the rated input voltage for the ADV151‑E63/D5A00?
A1: The rated input voltage is 24 V DC for ON/OFF discrete signals.
Q2: How many input channels does the module offer?
A2: It supports 32 channels (in some configurations up to 64) of 24 V DC discrete input.
Q3: What are the module’s physical dimensions and weight?
A3: Approximate size: 51 mm (W) × 254 mm (H) × 114 mm (D); weight around 0.63 kg.
Q4: Does this module support sequence‑of‑events logging?
A4: Yes — the “E” suffix indicates SOE capture capability, allowing timestamped input event logging.
Q5: What does the “/D5A00” suffix mean?
A5: It specifies the module is supplied with the KS Cable Interface Adapter (ATD5A‑00) for 32‑channel digital inputs, simplifying wiring.
Q6: What is the input response time?
A6: The status input response time is ≤ 8 ms; for push‑button input modes, minimum ON detection ~20 ms and max cycle ~25 Hz.
Q7: What isolation protection is provided?
A7: Withstanding voltage is 2 kV AC between input and system, and 500 V AC between channel commons (every 16 channels) for 1 minute.
Q8: Can the module operate in harsh industrial environments?
A8: Yes — it supports an operating temperature range of –20 °C to +70 °C, designed for industrial robustness.
Q9: How is field wiring connected?
A9: Through the included KS Cable Interface Adapter or standard terminal blocks, depending on installation; the /D5A00 adapter version is included.
Q10: Can it be used as a direct replacement for older discrete input modules?
A10: Yes — provided the I/O rack/back‑plane architecture and system support the ADV151 family modules, the ADV151‑E63/D5A00 can serve as a modern replacement or upgrade module for discrete input systems.
