Product Overview
Brand: Yokogawa
Series: ADV14x Series – Digital Input Modules
Model: ADV144‑S13
The ADV144‑S13 is a 16‑channel digital input module designed for industrial automation and control system installations. It belongs to the ADV144 family within the ADV14x input‑module series, tailored for DC signal input acquisition with isolation. In this variant, the suffix “S13” typically denotes the standard type with enhanced specifications—such as ISA G3 conformity, wide temperature range (‑20 °C to +70 °C) and module isolation.
This module is engineered to receive ON/OFF discrete signals (for example, from switches, pushbuttons, contacts) and convert them into logic‑level data for the control system backplane. It supports modular rack or I/O‑base mounting, making it suitable for process automation plants, manufacturing lines, power/utilities, building automation and other harsh industrial environments where discrete input reliability and noise immunity are required.
Technical Specifications
| Parameter | Description |
|---|---|
| Number of input channels | 16 channels |
| Rated input voltage | 24 V DC nominal (with tolerance) |
| Input signal type | No‑voltage contact or dry contact (in some variants) |
| Typical input current | Approx. 6 mA per channel (at 24 V DC, input ON condition) |
| Input response time | Approx. ≤ 40 ms (for standard version) |
| Withstanding voltage (input ↔ system) | 2 kV AC for 1 minute (module isolation) |
| Operating temperature range | –20 °C to +70 °C (for S13 variant) |
| Dimensions (W × H × D) | Approx. 3.0 cm × 10.0 cm × 13.0 cm |
| Weight | Approx. 0.36 kg |
| Mounting | I/O rack slot or backplane mount (modular system) |
| Ambient humidity | 5 % to 95 % RH (non‑condensing) |
* Dimensions are approximate and may vary slightly by version/configuration.
Applications
-
Capturing discrete ON/OFF status signals from field devices (switches, contacts, pushbuttons) in automation systems.
-
Integration into DCS (Distributed Control System) or modular I/O racks in process plants, power generation, utilities, chemical/petrochemical industries.
-
Use in redundant I/O architectures where high availability of input signals is required.
-
Monitoring machine interlocks, safety switches, limit switches and operator‑panel buttons in manufacturing lines.
-
Building automation and large infrastructure environments: connecting discrete signal outputs from switchgear, HVAC panels, lighting systems into the control network.
-
Retrofit installations: updating legacy discrete‑input systems with modern module‑based I/O while retaining field wiring and signal interface.
Advantages
-
High reliability and isolation: With module isolation and 2 kV AC withstand voltage between input and system, the module offers robust protection against electrical noise, transients and grounding issues.
-
Widely compatible input domain: Designed for 24 V DC discrete signals (typical in many automation systems) and can handle dry contact or no‑voltage contact inputs, simplifying field interface.
-
Compact and lightweight: With a weight around 0.36 kg and moderate size, installation, replacement and system upgrades are easier and less space‑consuming.
-
Wide ambient capability: The S13 variant supports a broad operating temperature range (‑20 °C to +70 °C) and high humidity tolerance, making it suitable for harsh industrial or semi‑outdoor environments.
-
Modular system integration: Fits into standard module backplanes or I/O racks, supporting plug‑in type installation, simplifying wiring and maintenance.
-
Future‑proof and flexible: Supports contact‑type inputs, stress‑tested for industrial noise, offers a good solution for system expansions or modernization of discrete‑signal I/O architecture.
-
Proven brand ecosystem: As part of the Yokogawa ADV14x series, the module benefits from established system compatibility, spare‑parts availability and worldwide support.
Brand & Series Information
-
Brand: Yokogawa
-
Series: ADV14x Digital Input Modules (including ADV141, ADV142, ADV144 etc)
-
Category: Digital Input Module (Discrete DC signal input)
The ADV14x family encompasses modules designed for different input voltage levels (for example AC, DC), different channel counts and optional features such as pushbutton input detection, status display, temperature rating options. The ADV144 sub‑family is optimized for discrete DC input modules in a modular I/O architecture.
Recommended Related Models (Same Series or Adjacent)
| Model | Description |
|---|---|
| ADV144‑S13 | (Current model) 16‑channel DC digital input module with module isolation, 24 V DC input and wide ambient spec. |
| ADV144‑S00 | 16‑channel DC digital input module standard version (24 V DC input) without enhanced temperature option. |
| ADV142‑P00 | 16‑channel AC digital input module (200‑240 V AC input) in the ADV142 family; for high‑voltage AC discrete signals. |
| ADV142‑P10 | 16‑channel digital input module variant designed for 24 V DC input (within ADV142 family) for lower‑voltage discrete signals. |
| ADV151‑P53 | 32‑channel DC digital input module (24 V DC input) in the adjacent series for higher channel‑count applications. |
Recommended Popular Models (Same Brand)
| Model | Description |
|---|---|
| ADR541‑P50 | 16‑channel relay‑output module capable of switching 24‑110 V DC or 100‑240 V AC loads; output side of discrete I/O. |
| ADV551‑P53 | 32‑channel digital‑output module (24 V DC output) designed for actuators, driver control and discrete output tasks. |
| ADV157‑S50 | 32‑channel DC digital‑input module (24 V DC input) compact terminal‑type module used for discrete input tasks. |
| AAI141‑S50 | Analog‑input module (4‑20 mA signal acquisition) for measurement and process variable capture in the same brand ecosystem. |
| AAV142‑S50 | Analog I/O mixed‑module (multi‑channel analog input/output) for larger process‑control I/O expansions. |
FAQ (10 Questions & Answers)
Q1: What input voltage does the ADV144‑S13 support?
A1: It supports a 24 V DC nominal input voltage for its discrete input channels and is designed for dry‑contact or no‑voltage contacts.
Q2: How many input channels are provided on this module?
A2: The module provides 16 independent input channels.
Q3: What are the module’s dimensions and weight?
A3: The module is approximately 3.0 cm wide × 10.0 cm high × 13.0 cm deep and weighs about 0.36 kg.
Q4: Can the ADV144‑S13 be used in harsh ambient conditions?
A4: Yes — the S13 variant supports an operating temperature range as low as ‑20 °C and up to +70 °C, making it suitable for demanding installations.
Q5: Does the module support pushbutton‑type input (edge detection) or just status?
A5: This module is primarily designed for status‑type discrete inputs (ON/OFF). If you need pushbutton edge counting functions you may consider model variants explicitly labelled for pushbutton input.
Q6: Is this module compatible with redundant I/O rack/back‑plane systems?
A6: Yes — it is designed for modular slot mounting and can be used in redundant I/O configurations to support high availability.
Q7: What kind of field wiring connection does it use?
A7: Field wiring is typically connected via pressure‑clamp terminals or a dedicated cable connector depending on the configuration.
Q8: What is the typical response time for input changes?
A8: The input response time is approximately 40 ms or less (for standard status input).
Q9: What isolation protection does it provide?
A9: It provides 2 kV AC withstand voltage between input signal lines and the system circuit for 1 minute, ensuring robust signal isolation.
Q10: Can this module replace older discrete input modules in an existing system?
A10: Yes — provided the rack/back‑plane is compatible and the control system supports the ADV14x family modules, it can serve as a replacement or retrofit module for discrete DC input signals.
