Product Overview
Brand: Yokogawa
Series: ADV14x Series – Digital Input Modules
Model: ADV142‑S03
The ADV142‑S03 is a digital input module designed for industrial automation and control systems, forming part of the ADV142 sub‑family which handles high‑voltage AC discrete inputs. The “S03” suffix indicates a specific variant of the ADV142 family with enhanced or particular features (for example: “S” could denote a special environment or connector version, “03” a particular revision).
This module is intended to convert ON/OFF signals from field devices (switches, push‑buttons, contacts) into digital logic signals that the control system can process. The module supports robust isolation, wide operating conditions, and compatibility with modular I/O rack architectures, making it suitable for process plants, manufacturing automation, utilities and other demanding control installations.
Technical Specifications
| Parameter | Description |
|---|---|
| Number of input channels | 16 channels |
| Rated input voltage | 200 to 240 V AC (50/60 Hz) |
| Input ON voltage (peak) | approx. 160 V AC to 264 V AC |
| Input OFF voltage (peak) | approx. 40 V AC (56 V AC) or less |
| Typical input current | approx. 6.2 mA per channel @ 240 V AC |
| Maximum input current | approx. 9.3 mA per channel |
| Withstanding voltage (input ↔ system) | 2 kV AC for 1 minute |
| Withstanding voltage (between commons) | 1.35 kV AC for 1 minute (common minus every 8‑channel group) |
| Input response time | ~160 ms or less (status input) |
| Minimum ON detection time (if pushbutton input supported) | ~200 ms |
| Maximum ON/OFF cycle (pushbutton input) | Up to ~2.5 Hz |
| Operating temperature range | –20 °C to +70 °C (typical for “S03” enhanced version) |
| Dimensions (W × H × D) | Approx. 3.2 cm × 10.7 cm × 7.6 cm |
| Weight | Approx. 0.26 kg |
| Mounting | I/O back‑plane slot or modular rack mount |
| Connection type | Pressure clamp terminal or dedicated connector cable |
Applications
-
Monitoring discrete ON/OFF field signals in automation systems (200‑240 V AC) such as limit switches, selector switches, pushbuttons.
-
Integration into distributed control systems (DCS) / modular I/O racks in process plants: power generation, petrochemical, chemical, refining.
-
Suitable for redundant I/O arrangements where high availability is required, capturing status data reliably.
-
Use in manufacturing automation lines for machine interlocks, conveyor status, operator panel inputs.
-
Building infrastructure and facility automation: capturing high‑voltage AC discrete signals from large switchgear, HVAC systems, electrical panels.
-
Retrofitting or expansion scenarios requiring discrete AC input modules with modern I/O standards and isolation performance.
Advantages
-
High‑voltage AC input capability: The module supports 200‑240 V AC discrete inputs directly, reducing need for external signal conditioning.
-
Robust isolation and noise immunity: Withstanding voltages of 2 kV AC (input ↔ system) and 1.35 kV AC (between commons) help ensure signal integrity and system safety.
-
Compact and lightweight: At approximately 0.26 kg and slim profile, it saves rack space and eases handling/installation.
-
Wide ambient tolerance: Operating from –20 °C to +70 °C (for the enhanced “S03” version) makes it suitable for harsh industrial or semi‑outdoor installations.
-
System integration ready: Designed for back‑plane modular I/O systems, enabling plug‑in style replacement or expansion with minimized downtime.
-
Proven field performance: Part of a well‑established series, offering reliability in industrial environments with switching noise, vibration and thermal stress.
-
Versatile discrete input capture: Supports both status detection and, in variants, pushbutton edge counting, giving flexibility in how field signals are handled.
-
Maintenance friendly: Standard module footprint and replacement ease reduce service time and complexity in critical systems.
Brand & Series Information
-
Brand: Yokogawa
-
Series: ADV14x (Digital Input Modules)
-
Category: Digital Input Module (AC discrete signal capture)
The ADV14x series includes modules designed for different input voltage ranges (e.g., ADV141 for 100‑120 V AC, ADV142 for 200‑240 V AC) and variants offering pushbutton input, status displays, special temperature ratings. The ADV142‑S03 variant falls in this high‑voltage AC domain.
Recommended Related Models (Same Series or Adjacent)
| Model | Description |
|---|---|
| ADV141‑P50 | 16‑channel AC digital input module (100‑120 V AC input), general purpose version. |
| ADV141‑P53 | 16‑channel AC digital input (100‑120 V AC input) with pushbutton input and wide temperature range. |
| ADV142‑S03 | (Current) 16‑channel module 200‑240 V AC input, “S03” variant with enhanced ambient spec. |
| ADV142‑P00 | 16‑channel AC digital input module (200‑240 V AC input), basic version without pushbutton or enhanced features. |
| ADV151‑P53 | 32‑channel DC digital input module (24 V DC input) – part of the adjacent digital input line but for DC voltage domain. |
Recommended Popular Models (Same Brand)
| Model | Description |
|---|---|
| ADR541‑P50 | 16‑channel relay output module supporting 24‑110 V DC or 100‑240 V AC outputs, for load switching tasks. |
| ADV551‑P53 | 32‑channel digital output module (24 V DC output) designed for actuator or driver control applications. |
| ADV157‑S50 | 32‑channel DC digital input module (24 V DC input), compact form and terminal‑type wiring. |
| AAI141‑S50 | Analog input module (4‑20 mA signal acquisition) for process measurement and monitoring. |
| AAV142‑S50 | Analog I/O mixed module – multi‑channel analog input/output for larger process‑control expansions. |
FAQ (10 Questions & Answers)
Q1: What is the input voltage range for the ADV142‑S03?
A1: The module supports 200 V AC to 240 V AC discrete input voltage.
Q2: How many input channels does this module provide?
A2: It provides 16 individual input channels.
Q3: What are the module’s approximate dimensions and weight?
A3: It measures about 3.2 cm wide × 10.7 cm high × 7.6 cm deep, and weighs approximately 0.26 kg.
Q4: Can the ADV142‑S03 handle pushbutton input edge counting?
A4: The “S03” variant is primarily a status input module; if pushbutton edge counting is required, a “P‑” suffix version in the series would be more appropriate.
Q5: Is it suitable for very harsh ambient environments?
A5: Yes—the “S03” version supports an operating temperature range down to –20 °C and up to +70 °C, making it suitable for demanding installations.
Q6: What isolation protection does the module provide?
A6: It provides 2 kV AC isolation between input signal and system, and 1.35 kV AC between common groups every 8 channels.
Q7: How fast does it respond to input changes?
A7: The input response time for status input is about 160 ms or less.
Q8: Can this module be used in redundant I/O system racks?
A8: Yes, it is compatible with modular back‑plane I/O systems and can be used in redundant configurations for high‑availability applications.
Q9: What wiring method is used at the field device interface?
A9: Field devices are connected via pressure clamp terminals or dedicated connector cable depending on the installation variant.
Q10: If I have 100‑120 V AC discrete signals, can I use this module?
A10: No — the ADV142 family is designed for 200‑240 V AC inputs; for 100‑120 V AC you should use the ADV141 family modules.
