Yokogawa AAV142-S00 Analog Input Module
Product Overview
The Yokogawa AAV142-S00 is an advanced analog input module that offers high precision and reliability for a wide range of industrial automation applications. Designed to work seamlessly within industrial systems, the AAV142-S00 allows for accurate analog signal conversion to digital form for further processing and monitoring. This module supports both voltage and current input signals, making it an ideal solution for environments where diverse sensor types are used.
The AAV142-S00 is built for high-performance applications, delivering a combination of speed, accuracy, and stability. This makes it well-suited for process control, monitoring, and data acquisition systems where continuous, real-time monitoring is crucial. With its compact size and easy integration into existing control systems, the AAV142-S00 is an excellent choice for both new installations and upgrades in automation environments.
Part of Yokogawa’s reputable AAV series, this module is engineered to meet the demanding needs of industries such as oil and gas, chemical processing, manufacturing, and energy management. The AAV142-S00 stands out as a versatile, reliable, and efficient module that guarantees optimal performance in any industrial application.
Product Parameters
| Parameter |
Details |
| Model |
Yokogawa AAV142-S00 |
| Type |
Analog Input Module |
| Input Types |
Voltage, Current |
| Dimensions (W × H × D) |
32.8 × 130 × 107.5 mm |
| Weight |
0.2 kg |
| Power Supply |
24 V DC |
| Input Range |
–10 V to +10 V (Voltage), 4 to 20 mA (Current) |
| Accuracy |
±0.1% of reading or ±0.05% of full scale |
| Operating Temperature |
–20°C to 60°C |
| Mounting |
DIN Rail Mount |
| Signal Processing |
High-Resolution, Digital Signal Conversion |
| Response Time |
< 100 ms |
| Environmental Protection |
IP20 (dust protected) |
| Output Type |
Digital Signal to Controller |
| Communication Protocol |
Modbus RTU, Yokogawa Proprietary Protocol |
| EMC Protection |
EN 61326-1 |
Applications
The Yokogawa AAV142-S00 is designed for a wide range of applications that require accurate analog signal measurement and conversion. It is ideal for:
-
Process Automation: Used for monitoring and controlling temperature, pressure, flow, and level processes in industrial environments.
-
Machine Control Systems: Ideal for data acquisition in industrial machine control systems, where precise measurement and real-time monitoring are critical.
-
Monitoring Systems: Perfect for integration into monitoring systems in areas like environmental controls, HVAC systems, and energy management.
-
Energy Management Systems: The module’s ability to handle both voltage and current inputs makes it suitable for energy measurement and optimization.
-
Data Acquisition Systems: Essential for data logging and converting analog signals from sensors into digital data that can be processed and analyzed for decision-making.
-
Instrumentation Systems: Widely used in industrial instrumentation systems that require high accuracy and stable performance for signal conversion.
-
Industrial Automation: An integral part of industrial automation systems, the AAV142-S00 ensures accurate control of various industrial processes.
Product Advantages
-
Wide Input Range: The AAV142-S00 supports both voltage and current input signals, offering flexibility for different industrial applications.
-
High Accuracy: The module provides ±0.1% accuracy or ±0.05% of full scale, ensuring reliable, precise measurements for critical processes.
-
Fast Response Time: With a response time of < 100 ms, it ensures real-time signal processing, making it ideal for time-sensitive applications.
-
Compact Design: With dimensions of 32.8 × 130 × 107.5 mm, the module can be easily integrated into existing control systems, even in tight spaces.
-
Seamless Integration: Supports Modbus RTU and Yokogawa proprietary protocols, enabling easy integration with other Yokogawa devices and control systems.
-
Energy Efficient: Powered by 24 V DC, the module is optimized for energy efficiency, making it suitable for long-term, continuous operation.
-
High Reliability: With its IP20 rating, the AAV142-S00 is dust-protected, providing reliable operation even in challenging industrial environments.
-
Versatile Applications: This module is suitable for a wide range of industrial applications, from process control to data acquisition, ensuring flexibility across different sectors.
-
Easy Mounting: The module can be easily mounted on DIN rails, simplifying installation and reducing setup time.
-
Cost-Effective Solution: The AAV142-S00 provides high-performance at a competitive price, making it a cost-effective solution for industrial applications.
