Product Overview – Yokogawa AAI543‑H61
The AAI543‑H61 is a premium industrial analog output module engineered for high-end distributed control systems (DCS). It includes 16 fully isolated 4–20 mA analog output channels designed for secure and precise signal transmission. The H61 variant elevates the design with advanced environmental resistance, supporting broader temperature ranges and enhanced surge immunity while retaining HART communication for remote diagnostics and module configuration.
This module is optimized for critical applications in sectors like power generation, chemical processing, and manufacturing facilities where both accuracy and resilience are imperative.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AAI543‑H61 |
| Output Channels | 16 (individually isolated) |
| Output Signal | 4–20 mA analog |
| Update Interval | 10 ms |
| Load Resistance | 0–750 Ω |
| Accuracy | ±40 µA (improved precision) |
| Temperature Drift | ±12 µA per 10 °C |
| Operating Temp Range | –25 °C to +75 °C (extended industrial range) |
| Withstand Voltage | 2000 V AC (1 minute, output vs system) |
| HART Communication | Yes |
| Power Consumption | 220 mA @ 5 V DC; 500 mA @ 24 V DC |
| Terminal Interface | Pressure clamp with reinforced surge protection |
| Mounting Style | Narrow base-mount (27 mm width) |
| Dimensions (W × H × D) | 27 mm × 130 mm × 110 mm |
| Weight | 0.47 kg |
Applications
The AAI543‑H61 excels in a range of challenging industrial environments:
-
Power Generation – Controls steam valves and turbine actuators, even under high heat and electrical stress.
-
Chemical & Petrochemical – Manages process loops requiring surge tolerance and reliable analog output.
-
Water/Wastewater Treatment – Enables accurate pumping and dosing in fluctuating temperature environments.
-
Pharmaceutical Manufacturing – Ensures precision control of sterilization equipment and fill systems.
-
Heavy Manufacturing – Drives hydraulic systems or heavy-duty actuators under harsh industrial conditions.
Key Advantages
-
Improved Precision – ±40 µA accuracy and reduced drift deliver consistently reliable output control.
-
Superior Resilience – Operates from –25 °C to +75 °C with elevated surge handling (2000 V), engineered for tough environments.
-
Smart Monitoring – HART communication enables live diagnostics, configuration, and remote calibration.
-
Quick Response – Outputs refresh every 10 ms, supporting real-time control loops.
-
Compact, Strong Build – Slim 27 mm form factor and reinforced terminal design provide both space-saving and durability.
-
Ready for Harsh Conditions – Designed with heavy-duty materials to withstand thermal cycles and noise.
Brand & Series
-
Brand: Yokogawa (not mentioned directly for compliance)
-
Series: AAI543 (16‑channel analog output modules)
5 Related Models (Same Series / Variants)
| Model | Key Feature | Channels | Temp Range |
|---|---|---|---|
| AAI543‑H60/K4A00 | High-temp with KS interface | 16 | –20 °C to +70 °C |
| AAI543‑H53 | Extended-temp and G3 standard support | 16 | –20 °C to +70 °C |
| AAI543‑H50/A4S10 | Standard alternate temp with surge clamp | 16 | –20 °C to +60 °C |
| AAI543‑H03 | Resilient mid-range temp variant | 16 | –20 °C to +60 °C |
| AAI543‑S53 | Standard output at extended temps | 16 | –20 °C to +70 °C |
5 Popular Models from the Same Brand
| Model | Function | Details |
|---|---|---|
| AAI143‑H61 | High-temp analog input module | Matches H61’s environmental performance |
| ADV152‑P00 | Digital output (fast switching) | Supports 32 channels |
| ATD6A‑00 | Enhanced thermocouple input | Multi-channel for temperature data |
| AAR181‑H60 | Remote I/O communication up to 75 °C | Field-distributed I/O for networked control |
| AFV11D‑S00 | Field control station (HART-ready) | Embeds logic for field-level control |
Top 10 FAQs
Q1: What distinguishes the AAI543‑H61 from its series counterparts?
A1: It offers tighter precision (±40 µA), extended temperature range (–25 °C to +75 °C), and elevated surge capability (2000 V) for heavy-duty operations.
Q2: Are the 16 outputs electrically isolated?
A2: Yes—each channel is fully isolated to ensure clean and interference-free signals.
Q3: What is the module’s weight and size?
A3: It measures 27 × 130 × 110 mm and weighs approximately 0.47 kg.
Q4: Does it support remote monitoring?
A4: Yes—HART communication enables remote diagnostics and parameter changes.
Q5: What kind of environments can it handle?
A5: It performs reliably from –25 °C to +75 °C and withstands electrical surges up to 2000 V—ideal for harsh industrial settings.
Q6: How quickly does it react to inputs?
A6: Outputs refresh in 10 ms, supporting responsive control loops.
Q7: Is wiring simplified for maintenance?
A7: While lacking a plug interface, the pressure clamp design supports secure, durable connections under duress.
Q8: What industries benefit most?
A8: Power generation, chemicals, water treatment, pharmaceuticals, and heavy manufacturing profit most from its enhanced resilience.
Q9: What is the typical load resistance?
A9: It works across a load resistance range of 0–750 Ω, suitable for diverse field devices.
Q10: Is its design compact enough for dense control panels?
A10: Yes—its slim 27 mm width maximizes panel space efficiency.
