Woodward 8200-1205 Discrete Output Channel
Product Introduction
The Woodward 8200-1205 discrete output channel is a reliable and precise output module designed for industrial control and engine management systems. As part of Woodward’s 8200 series, this module provides discrete switching outputs used to control various auxiliary devices such as solenoids, alarms, and indicator lights.
Engineered for rugged environments, the 8200-1205 supports high switching capacity and fast response times. It is built with high-quality components to ensure stable operation in harsh industrial, marine, and power generation settings. This module acts as a vital interface between control logic and mechanical devices, facilitating accurate and dependable control signals.
With its compact size and ease of installation, the 8200-1205 is a versatile choice for system integrators and OEMs aiming to enhance their control architecture without compromising reliability or performance.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model Number | 8200-1205 |
| Product Type | Discrete Output Channel |
| Output Type | Relay contact / transistor output |
| Number of Outputs | 1 |
| Output Voltage Rating | 24-28 VDC |
| Maximum Switching Current | 2 A |
| Response Time | < 10 ms |
| Operating Temperature | -40°C to +85°C |
| Dimensions | 120 × 80 × 35 mm |
| Weight | 0.22 kg |
| Mounting | Panel Mount |
| Environmental Rating | IP54 |
Product Applications
The Woodward 8200-1205 discrete output channel is commonly used in various industrial and engine control systems where discrete output control is essential:
-
Engine Control Systems: Used to trigger alarms, activate solenoids, or switch on indicator lamps in diesel and gas engine control panels.
-
Power Generation: Controls discrete outputs for generator protective relays and other auxiliary devices in power plants.
-
Marine Industry: Provides reliable switching for navigation and safety devices in marine engine control systems.
-
Industrial Automation: Interfaces with mechanical actuators and safety interlocks in process automation environments.
-
Oil & Gas: Controls emergency shutdown valves and signal lamps in harsh oilfield conditions.
Product Advantages
-
Robust and Reliable: Designed to endure tough industrial environments with wide operating temperature range and vibration resistance.
-
Fast Response: Less than 10 milliseconds response time ensures timely control signal delivery for critical applications.
-
Compact Design: Small footprint allows for easy integration into existing control panels with limited space.
-
High Switching Capacity: Supports up to 2 A switching current, suitable for a wide range of discrete loads.
-
Versatile Outputs: Can drive both relay and transistor loads, enhancing flexibility for different control needs.
-
Easy Installation: Panel mounting and clear terminal markings simplify setup and maintenance.
Brand Overview: Woodward
Woodward is a globally recognized leader in control solutions for engines and industrial automation. Known for its innovative engineering and high reliability, Woodward products like the 8200-1205 discrete output channel offer long-lasting performance in demanding industrial applications. The brand emphasizes durability, precision, and system integration, helping customers optimize engine efficiency and safety worldwide.
Recommended Related Models (Same Series or Related)
| Model Number | Output Type | Dimensions (mm) | Weight (kg) | Key Feature |
|---|---|---|---|---|
| 8200-1201 | Discrete Output Channel | 120 × 80 × 35 | 0.20 | Basic discrete output |
| 8200-1203 | Discrete Output Channel | 125 × 80 × 40 | 0.25 | Increased current capacity |
| 8200-1210 | Multi-Output Module | 140 × 90 × 45 | 0.30 | Multiple discrete outputs |
| 8200-1225 | Relay Output Module | 130 × 85 × 40 | 0.28 | High durability relay outputs |
| 8200-1230 | Solid State Output | 120 × 80 × 35 | 0.22 | Solid state switching technology |
Popular Woodward Models
| Model Number | Type | Dimensions (mm) | Weight (kg) | Description |
|---|---|---|---|---|
| 2301-810 | Mechanical Governor | 210 × 150 × 80 | 2.5 | Classic engine governor |
| 545-130 | Digital Fuel Controller | 180 × 130 × 70 | 1.8 | Integrated fuel management module |
| 505-169 | Actuator Positioner | 150 × 110 × 60 | 1.2 | Precise actuator control |
| 2300-999 | Load Sharing Controller | 220 × 160 × 90 | 3.0 | Parallel load sharing for generators |
| 3100-940 | Turbine Controller | 240 × 180 × 100 | 4.0 | Advanced turbine management |
Frequently Asked Questions (FAQ)
Q1: What type of outputs does the 8200-1205 support?
A1: It supports relay contact or transistor-type discrete outputs.
Q2: What is the maximum current it can switch?
A2: The maximum switching current is 2 Amperes.
Q3: What voltage range does it operate within?
A3: It operates with output voltages from 24 to 28 VDC.
Q4: Can this module be used in harsh industrial environments?
A4: Yes, it is designed with an operating temperature range of -40°C to +85°C and an IP54 rating for protection.
Q5: How fast does the output respond?
A5: The response time is under 10 milliseconds, suitable for time-critical applications.
Q6: What mounting options are available?
A6: The module is designed for panel mounting.
Q7: What is the physical size of the unit?
A7: Its dimensions are 120 × 80 × 35 mm.
Q8: How much does the module weigh?
A8: The weight is approximately 0.22 kg.
Q9: Is it compatible with other Woodward control products?
A9: Yes, it integrates seamlessly with other Woodward control systems and modules.
Q10: What safety features are included?
A10: The module has built-in protections against overload and short circuits.
