Technical Specification and Product Overview – Schneider 140XCP40200

1. Product Identification

Model: 140XCP40200

Product Type: Analog Output Module

Category: Modular PLC System I/O Modules

2. Product Introduction

The 140XCP40200 is an analog output module designed for integration within a modular programmable logic controller (PLC) system. This module provides high-precision voltage and current output capabilities, which are essential for controlling and driving analog devices in industrial automation systems. The 140XCP40200 converts digital control signals from the PLC into analog signals that can be used to control devices such as actuators, variable frequency drives (VFDs), and other analog-controlled machinery.

With the ability to output both voltage (0–10 V) and current (4–20 mA), this module offers a high degree of versatility, enabling it to interface with a wide range of equipment. Its robust design ensures stable and accurate performance even in demanding industrial environments, making it an ideal choice for critical automation applications that require precise and reliable analog control.

3. Brand and Series Information

Brand: Schneider

Schneider Electric is a global leader in industrial automation and energy management solutions, providing products and services designed to optimize efficiency, reliability, and safety across various industries.

Series: Modular PLC I/O Modules Series

This series includes a variety of analog and digital input/output modules specifically designed to work with modular PLC systems. These modules allow for easy scaling of control systems and enable reliable interaction with the physical world by providing necessary input and output capabilities.

4. Product Specifications

5. Product Applications

The 140XCP40200 analog output module is ideal for a range of applications where precise control over physical variables is needed. Its ability to output analog signals makes it essential for controlling equipment that responds to voltage or current signals. Common uses include:

• Variable Frequency Drives (VFDs): To control motor speed and torque in industrial machinery.

• Actuators: For controlling the position or movement of valves, dampers, and other mechanical components.

• Temperature Control Systems: Providing analog output to control heaters, chillers, or HVAC systems.

• Flow and Level Control Systems: Outputting control signals to pumps and valves in fluid handling systems.

• PID Control Systems: Used in systems requiring continuous regulation of physical processes with high precision.

6. Product Advantages

The 140XCP40200 offers several advantages that enhance its performance and reliability in demanding industrial environments:

• High Precision Control: 16-bit resolution ensures highly accurate analog control, essential for systems requiring fine adjustments.

• Wide Output Range: Supports both voltage and current outputs, making it compatible with a wide range of industrial devices.

• Fast Response Time: With a sampling rate of 1.5 ms per output, this module provides quick and accurate control signals.

• Compact and Space-Saving Design: The module’s compact size (130 × 50 × 150 mm) ensures it fits within standard PLC racks, saving valuable space.

• Protection Features: Built-in overvoltage and overcurrent protections ensure safe and reliable operation, even in harsh conditions.

• Versatile Application Range: Suitable for use in various industries, including manufacturing, process control, and environmental monitoring.

• Robust Industrial Design: Engineered for reliability in industrial settings, with an operating temperature range of 0 °C to +60 °C.
