Schneider Electric 140MMS53502: Product Overview, Applications, Advantages, and Related Models
Product Overview
The Schneider Electric 140MMS53502 is an advanced communication module designed for use with the Modicon M340 PLC system. This module enables efficient communication over Ethernet using the Modbus TCP protocol, ensuring smooth data exchange between a wide range of industrial automation components. It is a critical component of the Modicon M340 series, enhancing system flexibility and scalability for both simple and complex industrial setups.
The 140MMS53502 is specifically tailored for distributed control systems, allowing PLCs to communicate effectively with remote I/O, sensors, actuators, and other control devices. By offering a modular design and robust communication features, this module supports high-speed data transfer, improving real-time monitoring and control in industrial automation applications.
Product Applications
The 140MMS53502 communication module is widely used across various industries where seamless and reliable data transfer is crucial for operational efficiency. Some common applications include:
-
Industrial Automation: Used to connect different devices within the automation system, including PLCs, sensors, actuators, and machines, ensuring seamless communication.
-
Energy Management: Facilitates data exchange in power plants, electrical substations, and other energy management systems, enhancing real-time monitoring and optimization.
-
Building Automation: Enables integration of HVAC, lighting, and other building systems, helping to streamline operations and improve energy efficiency.
-
Water Treatment Plants: Ensures effective communication between remote systems and central controllers for water quality monitoring and management.
-
Oil & Gas: Used in harsh environments to facilitate communication between control systems and remote field devices, ensuring efficient and safe operations.
Product Advantages
-
High-Speed Communication: The 140MMS53502 supports Modbus TCP and Ethernet protocols, enabling rapid data exchange and reliable communication between PLCs and other industrial devices.
-
Scalability: This module integrates seamlessly with other Modicon M340 components, allowing for easy expansion as the system grows or new devices are added.
-
Compact Form Factor: Despite offering advanced functionality, the module has a compact design, making it easy to install in space-constrained environments.
-
Reliability in Harsh Conditions: The module is built to operate under challenging environmental conditions, such as temperature variations, vibrations, and dust, ensuring continuous operation in demanding industrial settings.
-
User-Friendly Configuration: With the integration of Schneider Electric’s EcoStruxure™ Control Expert, users can easily configure the 140MMS53502 module, simplifying the installation and programming process.
Brand and Series Information
-
Brand: Schneider Electric
-
Series: Modicon M340 Series
Technical Specifications
The following table outlines the detailed specifications of the 140MMS53502 module:
| Specification | Details |
|---|---|
| Model | 140MMS53502 |
| Type | Communication and I/O Module |
| Dimensions (L x W x H) | 90mm x 120mm x 140mm |
| Weight | 0.45 kg |
| Input Voltage | 24V DC |
| Output Voltage | 24V DC |
| Communication Protocols | Modbus TCP, Ethernet |
| Ethernet Ports | 2 Ports |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -25°C to 70°C |
| Protection Class | IP20 |
| Mounting Type | DIN Rail |
Related Models in the Modicon M340 Series
| Model | Key Specifications |
|---|---|
| 140CPU67160 | 1.6 GHz Processor, 1MB RAM, 512MB Flash, 24V DC Input |
| 140DRA84000 | 8 Digital Inputs, 4 Digital Outputs, 24V DC |
| 140ACM78000 | 2 Analog Inputs, 2 Analog Outputs, 24V DC |
| 140CPS11410 | Power Supply Module, 24V DC, 10A |
| 140EIA91000 | 16 Digital Inputs, 16 Digital Outputs, 24V DC |
Popular Schneider Electric Models
| Model | Key Specifications |
|---|---|
| A9F24610 | 16A, 1P+N, 6kA, Circuit Breaker, DIN Rail Mount |
| AXC2500 | Remote I/O, 4 Analog Inputs, 4 Digital Outputs, 24V DC |
| LXM32AD24M2 | 2.2kW Servo Drive, 24V DC Input |
| ATV320U15N4 | 15kW Variable Frequency Drive, 380-480V, 3-Phase |
| SCADAPack 4 | Remote Terminal Unit (RTU), 24V DC, Communication over TCP/IP |
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the 140MMS53502 module?
A1: The 140MMS53502 is a communication module that allows the Modicon M340 PLC to communicate with remote devices over Modbus TCP and Ethernet, enabling real-time control and monitoring in industrial applications.
Q2: How is the 140MMS53502 module installed?
A2: The 140MMS53502 module is designed for DIN rail mounting. Once mounted, connect the appropriate power and communication cables as per the installation guidelines.
Q3: What is the power requirement for the 140MMS53502?
A3: The module requires a 24V DC power supply to operate.
Q4: What communication protocols does the 140MMS53502 support?
A4: The 140MMS53502 supports Modbus TCP and Ethernet protocols for communication between PLCs and external devices.
Q5: Is the 140MMS53502 module suitable for outdoor use?
A5: The module has an IP20 rating, meaning it is suitable for indoor use only. For outdoor use, additional protective housing is recommended.
Q6: What is the operating temperature range of the 140MMS53502 module?
A6: The 140MMS53502 operates within a temperature range of 0°C to 60°C, which is suitable for most industrial environments.
Q7: Can the 140MMS53502 be integrated with other Schneider Electric devices?
A7: Yes, the 140MMS53502 integrates seamlessly with other Modicon M340 series devices and Schneider Electric’s broader automation systems.
Q8: How do I configure the 140MMS53502 module?
A8: The module can be configured using EcoStruxure™ Control Expert, Schneider Electric’s intuitive software platform for programming and system configuration.
Q9: What is the weight of the 140MMS53502 module?
A9: The 140MMS53502 weighs approximately 0.45 kg, making it lightweight and easy to install.
Q10: Is the 140MMS53502 compatible with older Modicon PLCs?
A10: The 140MMS53502 is designed specifically for the Modicon M340 series. While it may not be directly compatible with older Modicon PLC models, integration is possible with the appropriate network interfaces.
