Schneider Electric 140MMD10400: Product Overview, Application, Advantages, and Related Models
Product Overview
The Schneider Electric 140MMD10400 is a communication module within the Modicon M340 series. This module is designed to provide efficient and reliable communication between the Modicon M340 PLC (Programmable Logic Controller) and external devices or remote I/O systems. The 140MMD10400 module operates on the Modbus TCP protocol, which is widely used for industrial data exchange in automation systems.
As part of the Modicon M340 series, the 140MMD10400 facilitates robust and seamless communication in complex industrial automation and control systems. It enhances the system’s overall performance, reliability, and scalability by offering multiple ports for network communication. With its compact design and robust processing capabilities, it is suited for a variety of industrial applications.
Product Applications
The 140MMD10400 communication module is widely used in different industrial sectors and applications:
-
Manufacturing Automation: Helps connect different equipment and sensors within a factory automation system.
-
Energy Distribution Systems: Allows for effective data collection and monitoring in energy management applications.
-
Building Automation Systems: Integrates with lighting, HVAC, and security systems for efficient building management.
-
Water Treatment and Waste Management: Enables the remote monitoring and control of water and waste treatment systems.
-
Oil & Gas Industry: Provides communication between various field devices and control systems for monitoring and control in harsh environments.
Product Advantages
-
High Performance: The 140MMD10400 module supports high-speed data exchange through Modbus TCP, ensuring quick communication for real-time monitoring and control.
-
Modular Design: It integrates seamlessly with other components of the Modicon M340 series, providing easy scalability as the system grows.
-
Compact and Space-Efficient: Despite its powerful features, the module has a small form factor, which allows for easy installation in space-constrained environments.
-
Industrial Grade Durability: The module is built to withstand industrial conditions, including temperature variations and environmental stress.
-
Easy Integration and Configuration: The module is compatible with Schneider Electric’s EcoStruxure™ Control Expert software, enabling easy programming and configuration for optimal performance.
Brand and Series Information
-
Brand: Schneider Electric
-
Series: Modicon M340 Series
Technical Specifications
Here are the detailed specifications for the 140MMD10400 module:
| Specification | Details |
|---|---|
| Model | 140MMD10400 |
| Type | Communication Module |
| Dimensions (L x W x H) | 90mm x 120mm x 140mm |
| Weight | 0.45 kg |
| Input Voltage | 24V DC |
| Output Voltage | 24V DC |
| Communication Protocol | Modbus TCP |
| Ethernet Ports | 2 Ports |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -25°C to 70°C |
| Protection Class | IP20 |
| Mounting Type | DIN Rail |
Related Models in the Modicon M340 Series
| Model | Key Specifications |
|---|---|
| 140CPU67160 | 1.6 GHz Processor, 1MB RAM, 512MB Flash, 24V DC Input |
| 140DRA84000 | 8 Digital Inputs, 4 Digital Outputs, 24V DC |
| 140ACM78000 | 2 Analog Inputs, 2 Analog Outputs, 24V DC |
| 140CPS11410 | Power Supply Module, 24V DC, 10A |
| 140EIA91000 | 16 Digital Inputs, 16 Digital Outputs, 24V DC |
Popular Schneider Electric Models
| Model | Key Specifications |
|---|---|
| A9F24610 | 16A, 1P+N, 6kA, Circuit Breaker, DIN Rail Mount |
| AXC2500 | Remote I/O, 4 Analog Inputs, 4 Digital Outputs, 24V DC |
| LXM32AD24M2 | 2.2kW Servo Drive, 24V DC Input |
| ATV320U15N4 | 15kW Variable Frequency Drive, 380-480V, 3-Phase |
| SCADAPack 4 | Remote Terminal Unit (RTU), 24V DC, Communication over TCP/IP |
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the 140MMD10400 module?
A1: The 140MMD10400 is a communication module that allows the Modicon M340 PLC to communicate with remote devices and systems over the Modbus TCP protocol, ensuring reliable data exchange in industrial automation systems.
Q2: How do I install the 140MMD10400 module?
A2: The 140MMD10400 module is designed for DIN rail mounting. You can easily mount it onto a standard DIN rail, then connect the power supply and communication cables as per the module’s wiring diagram.
Q3: What is the power supply requirement for the 140MMD10400 module?
A3: The module operates with a 24V DC power supply to ensure proper functionality.
Q4: Can the 140MMD10400 communicate with other Schneider Electric products?
A4: Yes, the 140MMD10400 is designed to integrate seamlessly with other Modicon M340 components and Schneider Electric’s automation systems.
Q5: What communication protocols are supported by the 140MMD10400?
A5: The module supports the Modbus TCP communication protocol for network communication and data exchange.
Q6: What is the operating temperature range of the 140MMD10400 module?
A6: The module can operate in temperatures ranging from 0°C to 60°C, making it suitable for most industrial environments.
Q7: What is the weight of the 140MMD10400?
A7: The 140MMD10400 module weighs approximately 0.45 kg, ensuring it is lightweight and easy to install.
Q8: Is the 140MMD10400 module suitable for outdoor use?
A8: The 140MMD10400 is rated IP20, meaning it is designed for indoor use only. For outdoor applications, additional protective housing is recommended.
Q9: How can I configure the 140MMD10400 module?
A9: The module can be configured using EcoStruxure™ Control Expert, Schneider Electric’s software platform for programming and configuration of Modicon M340 systems.
Q10: Is the 140MMD10400 module compatible with older Modicon PLCs?
A10: The 140MMD10400 is specifically designed for the Modicon M340 series, so it is not directly compatible with older Modicon PLCs. However, integration may be possible with appropriate network interfaces or gateway devices.
