Schneider BMXXBP0600 Ethernet Backplane Rack
Product Introduction
The Schneider BMXXBP0600 is a robust Ethernet backplane rack designed for the Modicon X80 series automation platform. It provides the mechanical and electrical backbone for housing processor, communication, and I/O modules. With precision-engineered connectors and a slim profile, this backplane rack ensures reliable data transfer and power distribution across all inserted modules, making it a critical component in high-performance control cabinets.
Built from corrosion-resistant materials and featuring high-precision PCB traces, the BMXXBP0600 delivers long-term stability and minimal signal interference. Its standardized form factor streamlines cabinet design and module replacement, reducing maintenance time and cost.
Product Parameters
| Parameter | Specification |
|---|---|
| Dimensions | 103.7 × 307.6 × 19 mm |
| Weight | 0.79 kg |
| Number of Slots | 6 |
| Slot Pitch | 20.3 mm |
| Backplane Voltage | 5 V DC |
| Max Current per Slot | 2 A |
| Connector Type | 64-pin DIN-style gold-plated edge connector |
| Operating Temperature | –20 to 60 °C |
| Storage Temperature | –40 to 85 °C |
| Humidity | 5 to 95% non-condensing |
| EMC Compliance | EN 61000-6-2, EN 61000-6-4 |
| Mounting | DIN Rail (35 mm) |
Product Applications
The BMXXBP0600 backplane rack is ideal for:
-
Centralized PLC and PAC control cabinets in manufacturing lines
-
Process automation control panels in chemical plants
-
Water and wastewater treatment facility control systems
-
Energy distribution and substation automation
-
Building management and HVAC control centers
-
Material handling and conveyor automation
-
Batch and continuous process control in food & beverage industry
-
Automotive test rigs and assembly line orchestrations
Product Advantages
-
High Slot Density: Six module slots with 20.3 mm pitch maximize I/O capacity in a compact footprint.
-
Reliable Connectivity: Gold-plated edge connectors ensure low contact resistance and long service life.
-
Slim Profile: At only 19 mm thick, the backplane rack minimizes cabinet space while maintaining full functionality.
-
Industrial-Grade Durability: Operating temperature range of –20 to 60 °C and robust EMC compliance guarantee reliable performance under harsh conditions.
-
Easy Installation: Standard DIN-rail mounting and keyed connector alignment reduce wiring errors and installation time.
-
Scalable Architecture: Supports simultaneous mounting of processors, communication, and I/O modules from the Modicon X80 family.
-
Low Power Loss: Optimized copper traces and power buses minimize voltage drop and heat generation.
Brand Information
-
Brand: Schneider Electric
-
Series: Modicon X80
Schneider Electric is a global leader in industrial automation and energy management. The Modicon X80 series delivers high-performance control solutions for large-scale and distributed automation systems, known for robustness, flexibility, and seamless integration.
Recommended Related Models from Modicon X80 Series
| Model Number | Type | Slots | Dimensions (mm) | Weight (kg) | Notes |
|---|---|---|---|---|---|
| BMXXBP0300 | Backplane Rack | 3 | 103.7 × 150 × 19 | 0.45 | Half-size for compact cabinets |
| BMXXBP0900 | Backplane Rack | 9 | 103.7 × 460 × 19 | 1.20 | Extended slot count for larger I/O systems |
| BMXXBP0601 | Backplane Rack with Bypass | 6 | 103.7 × 307.6 × 19 | 0.82 | Includes integrated module bypass contacts |
| BMXXBP0602 | Backplane Rack with LEDs | 6 | 103.7 × 307.6 × 19 | 0.85 | Slot-status LED indicators per connector |
| BMXXBP1200 | Backplane Rack | 12 | 103.7 × 615 × 19 | 1.55 | High-density solution for large systems |
Recommended Popular Schneider Electric Models (Other Series)
| Model Number | Type | Key Features | Dimensions (mm) | Weight (kg) | Application Area |
|---|---|---|---|---|---|
| BMXP342020 | M340 Processor Module | 1 GHz CPU, 512 KB RAM, Ethernet | 104 × 100 × 33 | 0.205 | Mid-range PLC applications |
| BMXP3420302 | M340 Processor Module | 1 GHz CPU, 1 MB RAM, 8 MB memory | 104 × 100 × 33 | 0.215 | High-memory control tasks |
| BMXCPS3410 | M340 Power Supply | 24 V, 5 A output | 90 × 100 × 60 | 0.35 | Primary power for M340 racks |
| BMXDDI1602 | M340 Digital Input | 16 DI channels, 24 V DC | 90 × 100 × 60 | 0.40 | Discrete input processing |
| BMENOC0200 | Ethernet Bridge Module | Modbus TCP, Ethernet/IP gateway | 104 × 100 × 35 | 0.25 | Network segmentation and protocol conversion |
FAQ (Q&A)
Q1: What is the maximum number of modules supported by BMXXBP0600?
A1: It supports up to six modules, including processors, communication cards, and I/O modules.
Q2: Can the backplane rack handle high-current modules?
A2: Yes, each slot provides up to 2 A at 5 V DC, sufficient for standard X80 modules.
Q3: How is the BMXXBP0600 mounted in a control cabinet?
A3: It uses a standard 35 mm DIN-rail bracket for quick snap-on installation.
Q4: What connector type does it use?
A4: It employs 64-pin DIN-style gold-plated edge connectors to ensure low-resistance, reliable contact.
Q5: Is there any visual indication of module status?
A5: The standard BMXXBP0600 does not include LEDs; refer to BMXXBP0602 for slot-status indicators.
Q6: What is the recommended ambient humidity range?
A6: It operates reliably in 5 to 95% non-condensing humidity environments.
Q7: Does the backplane comply with EMC standards?
A7: Yes, it meets EN 61000-6-2 for immunity and EN 61000-6-4 for emissions.
Q8: Can it be used outdoors?
A8: It is intended for indoor cabinet use; for outdoor installations, additional environmental protection is required.
Q9: What is the operating temperature range?
A9: It functions between –20 and 60 °C.
Q10: How do I clean or maintain the backplane?
A10: Power down the rack, gently remove dust with a dry, lint-free cloth, and avoid using liquids or solvents.
