Schneider BMXFTB2820 28-Pin Detachable Spring Clamp Terminal Block
Product Introduction
The Schneider BMXFTB2820 is a 28-pin detachable spring clamp terminal block designed for use in the Modicon X80 series PLC system. This terminal block is an essential accessory for providing secure electrical connections and easy wiring management in industrial automation systems. It is widely used to connect various field devices such as sensors, actuators, and controllers, allowing for fast, reliable, and efficient installation and maintenance.
The BMXFTB2820 terminal block features 28 pins, offering spring clamp technology for secure wire connections. This ensures a solid and reliable connection without the need for specialized tools, simplifying the wiring process. The detachable design allows for easy maintenance, quick replacement, and modular expansion of the system. Its robust and compact design ensures durability, even in challenging industrial environments.
Applications
The BMXFTB2820 is used in a wide variety of industrial automation applications where reliable and easy electrical connections are required. Some common applications include:
-
PLC Wiring: Used to connect input and output devices such as sensors, actuators, and switches to the Modicon X80 series PLC.
-
Control Panels: Facilitates efficient wiring in control panels by offering clear and organized connections.
-
Machinery: Provides secure and detachable connections for wiring in industrial machinery, ensuring easy replacement and maintenance.
-
Automation Systems: Ensures reliable connection between various field devices and the central controller in industrial automation systems.
-
Test Equipment: Used in test setups for accurate electrical connections during system diagnostics and maintenance.
Advantages
-
Detachable Design: The BMXFTB2820 terminal block features a detachable design, allowing easy removal and replacement of wiring connections during maintenance or upgrades.
-
Spring Clamp Technology: The spring clamp connection ensures secure, vibration-resistant connections without the need for additional tools, reducing installation time and costs.
-
Compact and Lightweight: With dimensions of 91.4 x 41.8 x 32 mm and a weight of 0.07 kg, this terminal block is compact and lightweight, making it ideal for space-constrained environments.
-
Easy Wiring Management: The terminal block allows for organized and efficient wiring, ensuring a tidy installation with minimal risk of errors.
-
Compatibility: Fully compatible with the Modicon X80 series PLC, offering seamless integration into Schneider Electric’s automation systems.
-
Durability: Built for use in harsh industrial environments, providing long-term, reliable performance even in challenging conditions.
Brand Information
-
Brand: Schneider Electric
-
Series: Modicon X80 series
-
Module Type: 28-Pin Detachable Spring Clamp Terminal Block
-
Module Name: BMXFTB2820
-
Weight: 0.07 kg
-
Dimensions: 91.4 x 41.8 x 32 mm
-
Operating Temperature Range: -20°C to +60°C
-
Mounting: Designed for rail mounting within a Modicon X80 series PLC system.
Parameters (Schneider BMXFTB2820)
| Parameter | Value |
|---|---|
| Module Type | 28-Pin Detachable Spring Clamp Terminal Block |
| Dimensions (WxHxD) | 91.4 x 41.8 x 32 mm |
| Weight | 0.07 kg |
| Number of Pins | 28 Pins |
| Technology | Spring Clamp |
| Operating Temperature Range | -20°C to +60°C |
| Mounting | Rail Mounted |
| Certification | UL, CE, ROHS |
| Wire Range | 0.2 mm² to 2.5 mm² (AWG 24 to 12) |
| Max Current | 10 A |
| Max Voltage | 250 V |
Recommended Models
5 Models from the Same Series or Related:
| Model | Type | Dimensions (WxHxD) | Weight | Pin Count | Technology |
|---|---|---|---|---|---|
| BMXFTB2810 | Detachable Spring Clamp Terminal | 91.4 x 41.8 x 32 mm | 0.07 kg | 16 Pins | Spring Clamp |
| BMXFTB2830 | Detachable Spring Clamp Terminal | 91.4 x 41.8 x 32 mm | 0.08 kg | 32 Pins | Spring Clamp |
| BMXFTB2825 | Detachable Spring Clamp Terminal | 91.4 x 41.8 x 32 mm | 0.07 kg | 28 Pins | Spring Clamp |
| BMXFTB2800 | Detachable Spring Clamp Terminal | 91.4 x 41.8 x 32 mm | 0.07 kg | 12 Pins | Spring Clamp |
| BMXFTB2822 | Detachable Spring Clamp Terminal | 91.4 x 41.8 x 32 mm | 0.07 kg | 24 Pins | Spring Clamp |
5 Popular Schneider Models
| Model | Type | Dimensions (WxHxD) | Weight | Pin Count | Technology | Max Current |
|---|---|---|---|---|---|---|
| BMXDRA1605 | Discrete Output Module | 160 x 100 x 35 mm | 0.15 kg | – | Sourcing | 10 A |
| BMXDRA1620 | Discrete Output Module | 160 x 100 x 35 mm | 0.18 kg | – | Sinking | 10 A |
| BMXPIMT200 | I/O Module | 160 x 100 x 35 mm | 0.25 kg | – | – | 24V DC |
| BMXPPS5000 | Power Supply | 160 x 100 x 35 mm | 0.35 kg | – | – | 24V DC |
| BMXEHC0800 | High-Speed Counter | 160 x 100 x 35 mm | 0.113 kg | – | – | 500 kHz |
FAQ (Frequently Asked Questions)
Q1: What is the Schneider BMXFTB2820 used for?
A1: The BMXFTB2820 is a 28-pin detachable spring clamp terminal block, used for making secure and reliable electrical connections in industrial automation systems, particularly with Modicon X80 series PLC systems.
Q2: How does the spring clamp technology work in the BMXFTB2820 terminal block?
A2: The spring clamp technology provides a vibration-resistant connection that does not require additional tools, allowing for quick and secure wire insertion and removal.
Q3: What is the maximum current the BMXFTB2820 terminal block can handle?
A3: The BMXFTB2820 can handle up to 10 A of current, making it suitable for a wide range of industrial applications.
Q4: What is the wire range supported by the BMXFTB2820 terminal block?
A4: The terminal block supports a wire range of 0.2 mm² to 2.5 mm², or AWG 24 to 12.
Q5: How many pins does the BMXFTB2820 terminal block have?
A5: The terminal block has 28 pins, providing a reliable connection for multiple devices.
Q6: Can the BMXFTB2820 terminal block be used in harsh industrial environments?
A6: Yes, the BMXFTB2820 is designed for use in industrial environments and operates within a temperature range of -20°C to +60°C.
Q7: How is the BMXFTB2820 terminal block mounted?
A7: The BMXFTB2820 is designed for rail mounting, making it easy to integrate into existing control panels or PLC systems.
Q8: What is the size and weight of the BMXFTB2820 terminal block?
A8: The terminal block measures 91.4 x 41.8 x 32 mm and weighs 0.07 kg, making it compact and lightweight for easy installation.
Q9: Is the BMXFTB2820 terminal block compatible with other Schneider Electric PLC systems?
A9: The BMXFTB2820 is specifically designed for use with the Modicon X80 series, but can also be compatible with other Schneider Electric systems when properly integrated.
Q10: What certifications does the BMXFTB2820 terminal block have?
A10: The terminal block is certified to UL, CE, and ROHS standards, ensuring high quality and compliance with international safety regulations.
