Ovation 5X00106G02 HART High-Performance Analog Input Module
Product Introduction
The Ovation 5X00106G02 is a cutting-edge high-performance analog input module, designed to provide precise and rapid signal acquisition with the added benefit of HART (Highway Addressable Remote Transducer) protocol support. This module is part of Emerson’s Ovation series, which is specifically engineered for use in distributed control systems (DCS) in critical industrial environments.
The 5X00106G02 module supports 4–20 mA analog inputs and is capable of handling up to 8 input channels. The integration of HART communication makes it particularly useful in systems that require real-time diagnostics and control of smart field devices. Its ability to transmit both process data and diagnostic information over the same wires improves plant performance and reliability.
This module is designed for high-speed scanning, ensuring fast response times that are crucial in time-sensitive industrial applications. With robust diagnostics, it enhances overall operational efficiency by providing real-time fault detection and status monitoring.
Product Parameters
| Parameter | Value |
|---|---|
| Product Name | HART High-Performance Analog Input Module |
| Model Number | 5X00106G02 |
| Brand | Ovation (Emerson) |
| Series | Ovation Control System |
| Input Type | 4–20 mA with HART Communication |
| Input Channels | 8 |
| Input Resolution | 16-bit |
| Scan Rate | High-Speed (typically ≤100ms) |
| HART Compatibility | Yes (Full HART pass-through) |
| Isolation | Channel-to-channel, system |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Power Supply | 24 VDC |
| Dimensions | 263 x 183 x 55 mm |
| Weight | 0.85 kg |
| Mounting Type | DIN rail or system backplane |
| Certifications | CE, CSA, UL |
Product Applications
The 5X00106G02 is primarily used in high-demand industries where rapid and reliable signal acquisition is critical. Its primary applications include:
-
Power Generation: Especially in thermal, nuclear, and renewable energy plants, where precise control of power generation processes is vital.
-
Oil and Gas: Used in upstream and downstream oil production, where real-time monitoring of equipment performance is essential for safety and efficiency.
-
Water Treatment: Ideal for use in both municipal and industrial water treatment facilities to monitor key process variables.
-
Chemical and Petrochemical Plants: Provides accurate monitoring of process variables in complex chemical reactions and distillation processes.
-
Manufacturing: Widely used in industries like paper, cement, and steel manufacturing, where precise control of production processes is crucial.
This module ensures effective integration with HART-enabled field instruments, offering superior diagnostics and enhanced communication capabilities for real-time monitoring and control.
Product Advantages
-
High-Speed Analog Input: With a rapid scanning rate of ≤100ms, this module can acquire and process signals quickly, making it ideal for fast-paced environments.
-
Full HART Communication: Allows for seamless two-way communication with field devices, providing access to process data and diagnostics for enhanced asset management.
-
Advanced Diagnostics: Includes real-time diagnostic information for detecting faults and potential issues in the system, reducing downtime and maintenance costs.
-
Flexibility and Compatibility: It is fully compatible with other Ovation DCS modules, ensuring smooth integration within the Ovation system environment.
-
Robust and Compact Design: Designed to operate in harsh industrial environments, with a compact size that fits easily into control cabinets and system backplanes.
Brand Information
-
Brand: Ovation
-
Ovation is a flagship DCS platform from Emerson, designed to offer unparalleled control, efficiency, and asset management in the power and industrial sectors. The Ovation system excels in large-scale industrial environments, providing control, monitoring, and data analytics for mission-critical processes.
Related Models from the Same Series
| Model | Description | Input Type | Channels | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| 5X00106G01 | Analog Input HART module, standard speed | 4–20 mA with HART | 8 | 263 x 183 x 55 | 0.85 |
| 5X00106G03 | High-density analog input module with HART | 4–20 mA with HART | 16 | 263 x 183 x 55 | 0.90 |
| 5X00105G01 | Standard analog input module | 4–20 mA | 8 | 263 x 183 x 55 | 0.80 |
| 5X00489G01 | HART Multiplexer Module | Digital/HART | 32 | 263 x 183 x 55 | 0.87 |
| 5X00368G01 | Ethernet Communication Interface Module | Ethernet/HART | 8 | 160 x 130 x 50 | 0.85 |
Popular Emerson/Ovation Models
| Model | Description | Application Area | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| 5X00790G01 | Ovation controller processor module | Core control logic | 265 x 185 x 60 | 1.10 |
| 5X00790G02 | Advanced processor with expanded memory | Power plants | 265 x 185 x 60 | 1.12 |
| 1C31125G02 | Power supply module | Power management | 120 x 200 x 80 | 0.95 |
| 1C31194G01 | Digital Output 24VDC module | Actuator and solenoid control | 140 x 180 x 65 | 0.76 |
| 5X00368G01 | Ethernet communication interface module | Network communication | 160 x 130 x 50 | 0.85 |
FAQ – Frequently Asked Questions
Q1: What is the scan rate of the 5X00106G02?
A1: The scan rate of the 5X00106G02 is typically ≤100ms, making it ideal for high-speed data acquisition.
Q2: Can the module be used with traditional 4–20 mA devices?
A2: Yes, the module is compatible with traditional 4–20 mA devices, in addition to supporting HART communication.
Q3: How many input channels does the module support?
A3: The 5X00106G02 supports 8 analog input channels.
Q4: Is HART communication necessary for operation?
A4: HART communication is optional for operation, but it enables advanced diagnostics and remote configuration capabilities.
Q5: What kind of isolation does the module provide?
A5: The module provides both channel-to-channel and system isolation, ensuring signal integrity and safety.
Q6: Is the module compatible with older Ovation systems?
A6: Yes, the 5X00106G02 is backward compatible with older Ovation platforms.
Q7: How does the module help with diagnostics?
A7: The module offers real-time fault detection and status monitoring, allowing operators to detect and address issues quickly.
Q8: What is the warranty period for the module?
A8: The typical warranty period for Emerson Ovation modules is one year, with options for extended service plans.
Q9: How is the module mounted?
A9: The module can be mounted using a DIN rail or directly into the Ovation system backplane.
Q10: Can the module be used in hazardous areas?
A10: It is certified for general industrial environments; however, further certifications may be required for use in hazardous locations.
