Product Overview
The Ingersoll Rand 47704433001 / 24242398 Pipeline Filter Cartridge is a replacement filtration component designed for compressed-air treatment systems. It is used to remove contaminants from compressed air before the air enters downstream equipment and processes.
Compressed air can contain solid particles, oil aerosols, moisture, and other contaminants introduced during compression, storage, or distribution. A properly selected pipeline filter cartridge helps protect pneumatic equipment, control components, instruments, and production processes from these contaminants.
The 24242398 part number is associated with an Ingersoll Rand pipeline filter cartridge, while 47704433001 is provided as the related product/assembly reference for this item.
With supplied dimensions of 150 × 150 × 500 mm and an approximate weight of 2.5 kg, the cartridge is intended for industrial compressed-air filtration applications where reliable contaminant removal is required.
The cartridge is a consumable maintenance component rather than an electrical or control module. It is normally replaced at scheduled maintenance intervals or when pressure drop and filtration performance indicate that the filter element has reached the end of its useful service life.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Ingersoll Rand |
| Product Type | Pipeline Filter Cartridge |
| Related Part Number | 47704433001 |
| Filter Cartridge Part Number | 24242398 |
| Application | Compressed-air filtration |
| Component Type | Replacement Filter Cartridge |
| Dimensions | 150 × 150 × 500 mm |
| Weight | Approx. 2.5 kg |
| Installation | Pipeline filter housing |
| Medium | Compressed air |
| Main Function | Contaminant removal |
| Application Environment | Industrial compressed-air systems |
| Maintenance Type | Filter element replacement |
| Typical Contaminants | Particles, aerosols and other compressed-air contaminants |
The supplied dimensions and weight represent the stated product specifications. The actual filter housing, seals, and complete filtration assembly may have different dimensions and weight.
Function and Working Principle
The main purpose of the 24242398 Pipeline Filter Cartridge is to remove contaminants from compressed air as it passes through a dedicated filter housing.
A simplified compressed-air path is:
Air Compressor → Aftercooler → Pipeline Filter → Air Receiver / Distribution System → Pneumatic Equipment
When compressed air enters the filter housing, it passes through the filter media inside the cartridge.
Particles and other contaminants are captured by the filtration media while the treated air continues toward the downstream compressed-air system.
Depending on the filter configuration, the filtration stage may be used for:
- Solid particle removal
- Oil aerosol reduction
- General compressed-air purification
- Protection of downstream equipment
- Improvement of compressed-air quality
The cartridge itself is a replaceable filtration element. Once the filter media becomes loaded with contaminants, the pressure drop across the filter increases and the cartridge should be replaced.
Role in Industrial Compressed-Air Systems
Pipeline filtration is an important part of compressed-air treatment.
A typical system can include:
Compressor → Aftercooler → Water Separator → Pipeline Filters → Dryer → Air Receiver → Production Equipment
Different filtration stages can be installed depending on the required compressed-air quality.
A filter cartridge such as the 24242398 can help protect downstream components from contaminants that could otherwise enter:
- Pneumatic valves
- Cylinders
- Air tools
- Instrumentation
- Control systems
- Spray equipment
- Packaging machines
- Production processes
Clean compressed air can also help reduce contamination-related maintenance and improve the reliability of pneumatic equipment.
Importance of Filter Cartridge Maintenance
A pipeline filter cartridge is a consumable component and cannot be expected to operate indefinitely.
As contaminants accumulate within the filter media, airflow resistance gradually increases.
A heavily loaded cartridge may cause:
- Increased pressure drop
- Reduced downstream pressure
- Lower system efficiency
- Increased compressor workload
- Reduced pneumatic equipment performance
- Poor compressed-air quality
For this reason, filter cartridges should be inspected and replaced according to the equipment maintenance schedule and actual operating conditions.
A filter should not be replaced only according to calendar time when a pressure differential indicator or maintenance monitoring system provides more accurate information about cartridge condition.
Industrial Applications
The Ingersoll Rand 47704433001 / 24242398 filter cartridge can be used in various compressed-air applications.
Manufacturing Plants
Compressed air is widely used for pneumatic tools, actuators, assembly equipment, and automated production machinery.
Automotive Production
Clean compressed air is important for pneumatic tools, painting systems, assembly equipment, and automated manufacturing processes.
Packaging Equipment
Pneumatic actuators and control components require clean and reliable air to maintain stable operation.
Process Industries
Compressed-air filtration helps protect instrumentation and pneumatic equipment in chemical and process plants.
Food and Beverage Applications
Appropriate compressed-air treatment can help reduce contamination risks in applications where air quality is important.
General Industrial Utilities
Pipeline filters are commonly installed in central compressed-air distribution systems to protect multiple downstream users.
Installation and System Integration
The cartridge should be installed inside its compatible Ingersoll Rand pipeline filter housing.
A typical replacement procedure includes:
- Shut down or isolate the relevant compressed-air line.
- Completely release pressure from the filter housing.
- Open the filter housing according to the equipment service procedure.
- Remove the used filter cartridge.
- Inspect the housing and sealing surfaces.
- Install the new cartridge in the correct orientation.
- Check or replace seals when required.
- Reassemble the filter housing.
- Restore the compressed-air supply.
- Check for leakage and abnormal pressure drop.
After installation, technicians should verify:
- Correct airflow direction
- Housing sealing
- Absence of compressed-air leakage
- Normal downstream pressure
- Proper filter seating
- Stable operation of downstream equipment
Never open a pressurized pipeline filter housing.
Compatible System Components
The pipeline filter cartridge normally operates as part of a complete compressed-air treatment system.
| Component | Function |
|---|---|
| Air Compressor | Produces compressed air |
| Aftercooler | Reduces compressed-air temperature |
| Water Separator | Removes condensed liquid |
| Pipeline Filter Housing | Holds the filter cartridge |
| Filter Cartridge | Removes contaminants |
| Air Dryer | Reduces moisture content |
| Air Receiver | Stores compressed air |
| Pressure Regulator | Controls downstream pressure |
| Drain System | Removes accumulated condensate |
| Pneumatic Equipment | Uses treated compressed air |
The filter cartridge should always be matched with the correct filter housing and filtration specification.
Recommended Alternative Models
Filter cartridges are highly dependent on housing dimensions, filtration grade, flow capacity, and application requirements. Therefore, alternatives should be confirmed against the original filter housing.
| Model | Type | Key Feature | Application |
|---|---|---|---|
| 24242398 | Pipeline Filter Cartridge | Replacement filtration element | Compatible Ingersoll Rand systems |
| 47704433001 | Filter Cartridge Reference | Pipeline filtration component | Industrial compressed-air treatment |
| 24242405 | Pipeline Filter Element | Replacement filter design | Selected compressed-air applications |
| 24242399 | Filter Cartridge | Alternative filtration element | Compatible filter systems |
| Ingersoll Rand Pipeline Filter Series | Filter Assembly | Multi-stage air treatment | Industrial compressed-air systems |
The closest replacement should be determined by comparing the original cartridge part number, filter housing, filtration grade, dimensions, flow capacity, and operating conditions.
Key Advantages
- Designed for compressed-air filtration
- Helps remove contaminants from pipeline air
- Protects downstream pneumatic equipment
- Supports cleaner compressed-air distribution
- Helps reduce contamination-related maintenance
- Supports stable pneumatic system operation
- Compact 150 × 150 × 500 mm dimensions
- Approximate 2.5 kg weight
- Suitable for industrial compressed-air systems
- Designed as a replaceable maintenance component
Technical FAQs
What is Ingersoll Rand 24242398?
It is a pipeline filter cartridge used as a replacement filtration element in compatible compressed-air treatment systems.
What is 47704433001?
47704433001 is the related product/assembly reference supplied for this pipeline filter cartridge.
What does the filter cartridge do?
It filters compressed air and helps remove contaminants before the air reaches downstream equipment.
What are the dimensions?
The supplied dimensions are approximately 150 × 150 × 500 mm.
How much does it weigh?
The supplied weight is approximately 2.5 kg.
Is the cartridge reusable?
It is generally treated as a replaceable filter element rather than a reusable component. Cleaning or reuse should only be considered if specifically permitted by the applicable equipment design.
When should the filter cartridge be replaced?
Replacement is normally based on the manufacturer’s maintenance requirements, operating hours, pressure differential, contamination level, or a combination of these factors.
What happens if a filter cartridge becomes clogged?
A clogged cartridge can create excessive pressure drop, reduce downstream airflow, and increase the energy required to maintain compressed-air pressure.
Can this cartridge fit any Ingersoll Rand filter housing?
No. The cartridge must match the specific filter housing and filtration requirements. Physical dimensions alone are not sufficient to confirm compatibility.
Why is pipeline filtration important?
Pipeline filtration helps protect pneumatic equipment and production processes from contaminants carried by compressed air, improving system reliability and reducing maintenance problems.
Conclusion
The Ingersoll Rand 47704433001 / 24242398 Pipeline Filter Cartridge is a replacement filtration component designed for industrial compressed-air treatment systems.
Its main purpose is to help remove contaminants from compressed air before the air reaches downstream pneumatic equipment, instrumentation, and production processes. By maintaining effective filtration, the cartridge helps reduce contamination, protect sensitive components, and support reliable compressed-air distribution.
With supplied dimensions of 150 × 150 × 500 mm and an approximate weight of 2.5 kg, the cartridge is suitable for industrial maintenance and spare-parts management.
For replacement applications, engineers should verify the original filter housing, cartridge part number, filtration requirements, airflow capacity, pressure rating, and installation dimensions. Selecting the correct cartridge is essential for maintaining the intended compressed-air quality and minimizing unnecessary pressure loss.
