- Ingersoll Rand
- 47588692001 54601513
- Oil Separator Core
- USA
- 300 × 300 × 190 mm
- 5.4 kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 6
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
Product Overview
The Ingersoll Rand 47588692001 54601513 Oil Separator Core is an air-oil separation component designed for use in compatible industrial rotary screw air compressors. Its primary function is to separate lubricating oil from compressed air before the air moves into the downstream delivery system.
In oil-injected rotary screw compressors, lubricating oil is introduced into the compression chamber to support sealing, cooling, and lubrication. After compression, the resulting air-oil mixture enters the separator system. The oil separator core helps remove suspended oil droplets and return separated oil to the compressor’s lubrication circuit.
Effective oil separation is important for maintaining compressed-air quality, controlling oil consumption, and protecting downstream equipment. Excessive oil carryover can contaminate air dryers, filters, pneumatic tools, production machinery, and other components connected to the compressed-air network.
The 54601513 reference is identified as an Ingersoll Rand air-oil separator element. It is associated with certain rotary screw compressor applications, including selected EP and related 75/100-series machines. The exact compatibility of the 47588692001-associated listing should be confirmed against the compressor’s parts documentation and serial number before ordering.
For industrial maintenance teams, selecting the correct separator element is essential. Similar-looking separator cores may differ in dimensions, sealing arrangements, filtration media, pressure resistance, and oil-return design.
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Ingersoll Rand |
| Manufacturer | Ingersoll Rand |
| Reference Number | 47588692001 |
| Part Number | 54601513 |
| Product Name | Oil Separator Core |
| Product Category | Air-Oil Separator Element |
| Application | Rotary Screw Air Compressors |
| Main Function | Separation of lubricating oil from compressed air |
| Dimensions Provided | 300 × 300 × 190 mm |
| Weight Provided | 5.4 kg |
| Installation Location | Compressor oil separator assembly |
| Typical Equipment | Compatible Ingersoll Rand compressor models |
| Related Part Reference | 39894597 |
| Product Type | Compressor Replacement Component |
Note: Dimensions and weight are the supplied listing specifications. Confirm the exact outside diameter, flange dimensions, internal diameter, height, sealing arrangement, and net weight against the physical component before ordering.
Function and Working Principle
The oil separator core is an important component in the compressed-air treatment process of an oil-injected rotary screw compressor. Its performance directly affects oil carryover, compressed-air cleanliness, and the operating condition of the compressor.
1. Separation of Oil from Compressed Air
During compression, lubricating oil mixes with incoming air. This mixture passes into the separator vessel, where the separator element helps remove suspended oil droplets.
The separation process reduces the amount of oil carried by the compressed air. Separated oil can then return to the compressor’s oil circuit through the designed oil-return arrangement.
2. Coalescence and Filtration
Many compressor separator elements use specialized filtration media to capture small oil droplets. As these droplets collect and combine, they form larger droplets that can drain from the separator element.
The effectiveness of this process depends on the filter media, airflow velocity, operating pressure, temperature, and condition of the element.
A damaged, incorrectly installed, or unsuitable separator can reduce separation efficiency and increase oil carryover.
3. Oil Return
After oil is separated from the compressed air, it must be returned to the compressor’s lubrication system through the appropriate oil-return path.
The oil-return arrangement is part of the compressor design. Incorrect installation, blocked return lines, or unsuitable replacement elements may interfere with normal oil recovery.
4. Control of Oil Carryover
Oil carryover refers to lubricating oil that remains in the compressed air after the separation process.
Excessive oil carryover can lead to oil contamination in downstream pipelines and equipment. It may also increase oil consumption and create additional maintenance requirements.
A correctly matched and maintained separator element helps maintain the intended separation performance of the compressor.
5. Management of Differential Pressure
As a separator element accumulates contaminants or deteriorates, the pressure difference across the element may increase.
Higher differential pressure can affect compressor performance and increase energy consumption. Monitoring separator differential pressure according to the compressor manufacturer’s maintenance instructions helps identify when inspection or replacement is necessary.
Role in Industrial Compressed-Air Systems
The 47588692001 54601513 Oil Separator Core supports the compressed-air generation process by helping maintain separation between lubricating oil and compressed air.
Compressor Air Treatment
The separator element is installed within the compressor’s separation assembly. It helps reduce oil contamination before compressed air enters the downstream air-treatment equipment.
This is particularly important in facilities where compressed air is distributed to multiple production areas.
Protection of Downstream Equipment
Oil contamination can affect air dryers, pipeline filters, pneumatic valves, cylinders, and other compressed-air components.
Maintaining the separator element helps reduce the amount of oil entering the distribution network and supports the operating condition of downstream equipment.
Compressor Efficiency
The separator element influences airflow resistance and oil separation performance. A suitable element operating within its intended service range helps the compressor maintain its designed operating conditions.
A separator that is clogged, damaged, or incorrectly specified may cause abnormal differential pressure or inadequate oil separation.
Maintenance Planning
Separator elements are consumable maintenance components. Their replacement should be included in the compressor’s preventive maintenance program.
Maintenance personnel should consider operating hours, differential pressure, oil condition, operating temperature, and manufacturer recommendations when planning replacement.
Industrial Applications
The Ingersoll Rand 54601513 Oil Separator Core is intended for compatible oil-injected rotary screw air compressor systems.
1. Manufacturing Plants
Manufacturing facilities use compressed air for pneumatic tools, automated machinery, material handling, and production equipment.
The separator element helps reduce oil contamination in the compressed-air supply, supporting the operation of connected equipment.
2. Automotive Production
Automotive manufacturing facilities use compressed air for assembly equipment, pneumatic tools, handling systems, and general production operations.
Maintaining the compressor’s oil separator helps control oil carryover and reduce the risk of contamination in compressed-air lines.
3. Packaging and Processing Equipment
Packaging and processing machinery may rely on compressed air for pneumatic actuators, product handling, and equipment control.
A properly maintained separator element supports cleaner compressed-air delivery and helps protect downstream pneumatic components.
4. Industrial Maintenance Workshops
Maintenance workshops commonly use compressed air for pneumatic tools, cleaning equipment, and repair operations.
The separator element contributes to the reliable operation of the compressor by maintaining the intended oil separation process.
5. General Industrial Compressed-Air Stations
Centralized compressed-air stations supply multiple machines and production areas. Separator performance is important because oil contamination can spread through the distribution network.
Regular inspection and replacement help maintain the compressor’s intended performance.
Installation and System Integration
Correct installation is essential for achieving reliable separation performance and avoiding oil leakage or abnormal pressure conditions.
1. Verify the Part Number
Before installation, confirm the separator reference number and compressor model.
The 54601513 element is associated with selected Ingersoll Rand compressor applications, but not every compressor in the same product family necessarily uses the same separator.
Check the compressor model, serial number, parts catalog, and original element markings before purchasing.
2. Check Dimensions and Sealing Surfaces
The supplied dimensions are 300 × 300 × 190 mm.
Before installation, compare the replacement element with the removed component. Check the overall height, body diameter, flange dimensions, internal opening, and sealing surfaces.
A separator with incorrect dimensions or sealing geometry may not fit correctly and could allow unfiltered air or oil to bypass the intended separation path.
3. Inspect the Separator Housing
Before installing the new element, inspect the separator vessel and its internal surfaces.
Remove accumulated debris where appropriate and check for corrosion, damage, or abnormal deposits. Inspect the sealing surfaces and confirm that the housing is suitable for reuse.
Follow the compressor manufacturer’s service instructions when opening and servicing the separator assembly.
4. Check the Oil Return System
Inspect the oil-return line and associated components for blockage, damage, or incorrect installation.
A restricted oil-return path can interfere with the return of separated oil and may contribute to abnormal oil consumption or oil carryover.
5. Replace Seals as Required
Inspect all applicable gaskets and sealing components. Replace damaged or hardened seals using the correct parts for the compressor configuration.
Do not reuse damaged sealing components simply because the separator element itself is new.
6. Follow Safe Maintenance Procedures
Before servicing the separator assembly:
- Stop the compressor.
- Isolate the electrical supply.
- Follow the equipment’s lockout procedure.
- Allow the system to cool.
- Depressurize the compressor and separator vessel.
- Confirm that pressure has been fully released before opening the assembly.
Never open a pressurized separator vessel. Follow the manufacturer’s safety and maintenance instructions throughout the procedure.
7. Test After Installation
After fitting the replacement element, check the assembly for correct seating and sealing.
Restart the compressor according to the approved commissioning procedure. Monitor operating pressure, temperature, differential pressure, and oil carryover where applicable.
Investigate abnormal pressure changes, oil leakage, or excessive oil consumption before returning the compressor to normal service.
Compatible System Components
The oil separator core works together with other components in the compressor’s lubrication and compressed-air systems.
| Component | Function | Maintenance Considerations |
|---|---|---|
| Air-oil separator housing | Contains the separator element | Inspect for corrosion, damage, and sealing problems |
| Compressor air filter | Removes particles from incoming air | Replace according to operating conditions and service recommendations |
| Oil filter | Removes contaminants from compressor oil | Maintain the correct replacement interval |
| Compressor lubricant | Provides lubrication, cooling, and sealing | Use the specified oil grade and approved lubricant |
| Oil-return line | Returns separated oil to the lubrication circuit | Inspect for restrictions and damage |
| Minimum pressure valve | Maintains required separator-system pressure | Check operation and sealing condition |
| Air cooler | Reduces compressed-air temperature | Keep cooling surfaces clean and airflow unobstructed |
| Aftercooler | Helps cool compressed air downstream | Inspect for contamination and drainage issues |
| Air receiver | Stores compressed air | Inspect drainage and pressure-system condition |
| Air dryer | Reduces moisture in compressed air | Maintain according to the dryer manufacturer’s instructions |
The components listed above are typical parts of an industrial compressed-air installation. Their exact arrangement depends on the compressor model and system design.
Alternative Models and Replacement Considerations
The 54601513 reference is associated with related Ingersoll Rand separator references and certain compressor applications. However, alternative part numbers should not be treated as interchangeable without confirmation.
| Part Number or Reference | Description | Replacement Consideration |
|---|---|---|
| 54601513 | Air-Oil Separator Element | Main reference for this listing |
| 39894597 | Related separator reference | Confirm the compressor parts catalog before substitution |
| 54601513 equivalent separator | Aftermarket replacement element | Check media, dimensions, pressure rating, and sealing design |
| Other Ingersoll Rand separator elements | Compressor-specific separator components | Select according to the exact compressor model and serial number |
Before selecting an alternative, compare:
- Overall height and body diameter.
- Flange diameter and internal opening.
- Seal dimensions and material.
- Filtration media and separation efficiency.
- Maximum operating pressure.
- Temperature compatibility.
- Differential-pressure characteristics.
- Oil-return design.
- Compressor model and serial-number compatibility.
A separator element that appears physically similar may have different filtration characteristics or sealing geometry. Always confirm technical compatibility before installation.
Key Advantages
Effective Oil Separation
The separator core helps remove lubricating oil from compressed air, supporting the intended operation of oil-injected rotary screw compressors.
Protection of Downstream Equipment
Reducing oil carryover helps limit contamination in air dryers, pneumatic components, pipelines, and production equipment.
Support for Compressor Efficiency
A correctly selected and maintained separator helps manage airflow resistance and maintain the compressor’s designed operating conditions.
Oil Recovery
The separation process allows collected oil to return to the compressor’s lubrication circuit through the designed oil-return system.
Maintenance-Friendly Replacement
The separator element is a service component that can be replaced as part of a planned compressor maintenance program.
Industrial Compressed-Air Reliability
Maintaining the separator supports stable compressed-air production and helps reduce maintenance problems associated with excessive oil contamination.
Technical FAQs
1. What is the Ingersoll Rand 54601513 Oil Separator Core?
It is an air-oil separator element designed for compatible Ingersoll Rand rotary screw air compressors. It separates lubricating oil from compressed air before the air enters the downstream system.
2. What is the function of an air-oil separator?
An air-oil separator removes suspended oil droplets from compressed air. The separated oil is returned to the compressor’s lubrication system through the designed oil-return arrangement.
3. Which compressors use the 54601513 separator?
The 54601513 reference is associated with selected Ingersoll Rand rotary screw compressors, including certain EP, HP, XP, and XF 75/100-series applications. Exact compatibility must be confirmed using the compressor model and serial number.
4. Is 39894597 related to 54601513?
Yes. Compressor-parts information identifies 39894597 as an older related reference for 54601513. Confirm the replacement relationship using the applicable compressor parts documentation.
5. What happens when an oil separator becomes clogged?
A restricted separator may cause increased differential pressure, reduced compressor efficiency, and abnormal operating conditions. Maintenance personnel should inspect the separator when differential pressure reaches the manufacturer’s specified replacement threshold.
6. What are the signs of a damaged oil separator?
Possible symptoms include excessive oil carryover, increased oil consumption, abnormal differential pressure, and oil contamination in downstream equipment. These symptoms can also have other causes, so the complete compressor system should be inspected.
7. How often should the separator element be replaced?
The replacement interval depends on compressor model, operating hours, oil condition, environmental conditions, and the manufacturer’s maintenance schedule. Follow the service interval specified for the actual compressor.
8. Can an aftermarket separator replace the original part?
An aftermarket separator may be suitable if it matches the original element’s dimensions, filtration performance, pressure rating, sealing arrangement, and compressor compatibility. Physical similarity alone is not sufficient.
9. Why should the oil-return line be checked during separator replacement?
The oil-return line carries separated oil back to the compressor’s lubrication system. A blockage or restriction can interfere with oil recovery and may contribute to abnormal oil carryover or oil consumption.
10. What information should be checked before purchasing?
Confirm the complete part number, compressor model, serial number, separator dimensions, flange configuration, sealing arrangement, and required operating specifications. These checks help reduce the risk of purchasing an incompatible element.
Procurement and Maintenance Recommendations
When purchasing the Ingersoll Rand 47588692001 54601513 Oil Separator Core, verify the part number against the compressor’s original parts documentation. The 47588692001 reference should be checked against the supplier’s catalog or equipment records to establish its exact relationship to the 54601513 separator element.
For replacement projects, request clear photographs of the element, including its outer body, flange, internal opening, and sealing surfaces. Compare these details with the removed separator before confirming an order.
For used or surplus compressor components, inspect the physical condition carefully. Separator elements are filtration components, and a previously used element should not be treated as equivalent to a new replacement part without an appropriate technical assessment.
During routine maintenance, monitor separator differential pressure, oil consumption, compressed-air quality, and operating temperature. Replace the element according to the compressor manufacturer’s recommendations and investigate abnormal oil carryover rather than assuming that the separator is always the only possible cause.
Maintaining the separator together with the compressor air filter, oil filter, lubricant, and oil-return system helps support reliable operation of the complete compressed-air installation.
Conclusion
The Ingersoll Rand 47588692001 54601513 Oil Separator Core is an important maintenance component for compatible rotary screw air compressors. Its primary role is to separate lubricating oil from compressed air, reduce oil carryover, and support the compressor’s lubrication and compressed-air systems.
Correct part identification, dimensional verification, proper installation, and scheduled maintenance are essential for reliable operation. Before purchasing or replacing this separator, confirm the complete part reference and compressor compatibility using the equipment model and serial number.
