- Honeywell
- MC-TAIH53 51309138-275
- High-Level Analog Input Module
- USA
- 137 x 51 x 151 mm
- 0.3 kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 22
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
Product Overview
The Honeywell MC-TAIH53 (Part No. 51309138-275) is a high-level analog input Field Termination Assembly (FTA) used in Honeywell Experion PKS and Series C distributed control systems (DCS).
It is designed to receive and condition multiple 4–20 mA analog signals from field instruments such as pressure transmitters, flow meters, temperature sensors, and level transmitters. The module ensures accurate signal transmission from field devices to the control system for real-time process monitoring and control.
This model is widely used in high-density industrial analog input applications where reliability, signal integrity, and structured wiring are required.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Honeywell |
| Model | MC-TAIH53 |
| Part Number | 51309138-275 |
| Product Type | High-Level Analog Input FTA |
| System Series | Experion PKS / Series C I/O architecture |
| Input Channels | 16 analog input channels |
| Signal Type | 4–20 mA high-level analog inputs |
| Wiring Style | Screw terminal field wiring |
| Signal Conditioning | Built-in input protection and filtering |
| Isolation | Channel/system isolation (system dependent) |
| Diagnostics | Channel status and module health monitoring |
| Compatibility | MU-PAIH03 / MC-PAIH03 I/O processors |
| Redundancy Support | Supported in redundant I/O configurations |
| Operating Environment | Industrial control systems |
| Operating Temperature | -40°C to +85°C (industrial-grade range) |
| Dimensions | 137 × 51 × 151 mm |
| Weight | 0.3 kg |
Function and Working Principle
The MC-TAIH53 functions as a signal interface between field transmitters and the DCS control system.
It is responsible for:
- Receiving 4–20 mA analog signals from field devices
- Providing signal termination and protection
- Conditioning signals for accurate system interpretation
- Transmitting signals to I/O processors (MC/MU series)
- Supporting high-density analog signal acquisition
- Maintaining signal stability in electrically noisy environments
It does not perform control logic; it ensures accurate and stable signal acquisition.
System Role in Architecture
The Honeywell MC-TAIH53 plays a front-end signal acquisition role in industrial automation systems.
It is typically used for:
- Process variable monitoring (pressure, flow, temperature)
- Refinery and petrochemical control loops
- Power generation instrumentation systems
- Water treatment monitoring systems
- Distributed analog input architectures
It acts as the interface between field instrumentation and control system processing units.
Industrial Applications
- Oil and gas production systems
- Petrochemical and refinery plants
- Power generation stations
- Chemical processing industries
- Water and wastewater treatment facilities
- Industrial automation monitoring systems
Installation & Integration
Proper installation ensures reliable operation:
- Installed inside Experion PKS control cabinets
- Connected to field transmitters via analog wiring
- Interfaces with MC/MU series I/O processors
- Requires proper grounding and shielding for analog signals
- Configured using Honeywell system engineering tools
- Used with loop-powered or externally powered transmitters
Compatible Components
- Honeywell Experion PKS controllers
- MC-PAIH03 / MU-PAIH03 I/O processors
- Field transmitters (4–20 mA devices)
- Field Termination Assemblies (FTAs)
- Analog signal conditioning modules
- Distributed control system backplane modules
Recommended Alternative Models
| Model | Type | Application |
|---|---|---|
| MC-TAIH13 | Analog input FTA | Alternate configuration |
| MC-TAIH03 | Standard variant | Same architecture family |
| MC-TAIH54 | Enhanced version | Improved functionality |
| Universal I/O modules | Flexible replacement | Modern DCS systems |
| Remote analog I/O systems | Network-based architecture | Distributed control systems |
Key Advantages
- High-density 16-channel analog input capability
- Reliable 4–20 mA signal handling
- Strong industrial noise immunity
- Compact and lightweight FTA design
- Compatible with Honeywell Experion PKS systems
- Supports redundant I/O configurations
- Stable long-term industrial operation
FAQs
Q1: What is the main function of this module?
It receives and conditions analog signals from field transmitters.
Q2: What signal type does it support?
Primarily 4–20 mA high-level analog inputs.
Q3: Does it perform control functions?
No, it only handles signal acquisition and conditioning.
Q4: How many channels does it support?
Typically 16 analog input channels.
Q5: Where is it used?
In Honeywell Experion PKS distributed control systems.
Conclusion
The Honeywell MC-TAIH53 (51309138-275) High-Level Analog Input Module is a reliable industrial signal interface component in Honeywell DCS architectures. It provides accurate acquisition and conditioning of analog process signals, ensuring stable monitoring and dependable operation in industrial automation environments.
