Product Overview
The Honeywell FS-DO-1624 Digital Output Module is an industrial 16-channel 24 VDC non-safety digital output module used in Honeywell Safety Manager / FC-series I/O architectures.
It is designed to convert control system logic signals into discrete ON/OFF outputs for driving field devices such as relays, solenoids, alarms, and indicator loads. The module is widely used in process control and safety-adjacent automation systems where reliable digital switching is required.
It belongs to Honeywell’s FC/FS I/O family, where “FS” typically indicates non-conformal coated standard industrial modules and “FC” indicates conformal-coated versions for harsher environments.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Honeywell |
| Model | FS-DO-1624 |
| Product Type | Digital Output Module |
| System Series | Safety Manager / FC/FS I/O platform |
| Output Type | 24 VDC digital sourcing outputs |
| Channels | 16 outputs |
| Channel Configuration | Grouped output channels (system dependent grouping) |
| Output Voltage | 24 VDC nominal |
| Output Current | Typically up to 0.5 A per channel (system dependent) |
| Protection | Short-circuit and overload protection (electronic) |
| Isolation | Channel/group electrical isolation |
| Diagnostics | Channel status indication + module fault monitoring |
| Response Time | Millisecond-level switching performance |
| Communication | Backplane / system I/O bus interface |
| Power Supply | 24 VDC system supply |
| Mounting Type | Rack / I/O chassis mounted module |
| Operating Environment | Industrial automation systems |
| Operating Temperature | -20°C to +70°C (typical industrial range) |
| Dimensions | 180 × 50 × 100 mm |
| Weight | 0.25 kg |
Function and Working Principle
The FS-DO-1624 functions as a field execution module that converts digital commands into physical electrical outputs.
It is responsible for:
- Receiving output commands from the control system CPU
- Switching 24 VDC outputs ON or OFF per channel
- Driving external industrial devices (relays, solenoids, lamps)
- Providing electrical isolation between controller and field wiring
- Monitoring output status and fault conditions
- Ensuring stable and deterministic switching behavior
Each channel corresponds to a dedicated discrete control point.
System Role in Architecture
The Honeywell FS-DO-1624 plays a field-level execution role in industrial control systems.
It is typically used for:
- Industrial machine control
- Alarm and indicator systems
- Relay and actuator switching
- Interlock and sequencing logic execution
- Process automation output control
It does not perform logic processing; it executes commands from the controller.
Industrial Applications
- Oil and gas processing systems
- Petrochemical plants
- Power generation facilities
- Water treatment systems
- Chemical production industries
- Manufacturing automation systems
- General industrial control panels
Installation & Integration
Proper installation ensures reliable operation:
- Installed in Honeywell Safety Manager / FC I/O racks
- Connected via system backplane interface
- Requires regulated 24 VDC power supply
- Mounted inside industrial control cabinets
- Wired to field devices via terminal assemblies
- Configured during system commissioning and validation
Compatible Components
- Honeywell Safety Manager controllers
- FC/FS-series I/O modules
- Field Termination Assemblies (FTA)
- Digital input modules (DI counterparts)
- Industrial relays and solenoids
- Redundant power supply systems
- Safety and control system backplane racks
Recommended Alternative Models
| Model | Type | Application |
|---|---|---|
| FC-DO-1624 | Conformal coated variant | Harsh environments |
| SDO-0824 | Safety digital output module | SIL-rated systems |
| DO-1624 | Non-safety variant | Standard control systems |
| PLC DO modules | Generic replacement | Modern automation systems |
| Remote I/O DO modules | Networked architecture | Distributed control systems |
Key Advantages
- Reliable 16-channel digital output control
- Fast ON/OFF switching performance
- Electrical isolation for system protection
- Compact industrial module design
- Compatible with Honeywell Safety Manager architecture
- Integrated diagnostics and fault detection
- Suitable for continuous industrial operation
FAQs
Q1: What is the main function of this module?
It provides 24 VDC digital outputs for industrial control systems.
Q2: Does it perform logic control?
No, it only executes commands from the controller.
Q3: How many channels does it have?
It supports 16 digital output channels.
Q4: What devices can it control?
Relays, solenoids, lamps, and other discrete field devices.
Q5: Where is it used?
In Honeywell Safety Manager and FC/FS I/O systems.
Conclusion
The Honeywell FS-DO-1624 Digital Output Module is a reliable industrial output component used in Safety Manager and FC-series systems. It provides stable 24 VDC switching for field devices, ensuring efficient and dependable control execution in industrial automation environments.
