- Honeywell
- 900H32-0202
- Digital Output Module
- USA
- 137 x 35.6 x 137.16 mm
- 0.18 kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 23
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
Product Overview
The Honeywell 900H32-0202 Digital Output Module is an industrial 32-channel 24 VDC high-side digital output module used in the ControlEdge HC900 automation system.
It is designed to convert controller logic signals into discrete ON/OFF outputs used to drive field devices such as relays, solenoids, indicator lamps, and control circuits. This module is commonly applied in high-density output applications within process control and industrial automation systems.
It belongs to the HC900 modular I/O family and is optimized for reliable switching, fast response, and electrically isolated output groups.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Honeywell |
| Model | 900H32-0202 |
| Product Type | Digital Output Module |
| System Series | ControlEdge HC900 |
| Output Type | 24 VDC sourcing (high-side switching) |
| Output Channels | 32 channels |
| Channel Grouping | 2 isolated groups of 16 channels |
| Output Voltage Range | 10.5 – 32 VDC |
| Peak Voltage | 32 VDC |
| Output Current Capacity | Up to ~0.5 A per channel (typical HC900 rating) |
| Protection | Electronic current limiting and group-level overcurrent protection |
| Isolation | Galvanic isolation between channel groups |
| Switching Type | Solid-state switching |
| Response Time | Approximately 6 ms ON/OFF switching |
| Diagnostics | Channel status LEDs + module status indicators |
| Communication | Backplane communication with HC900 CPU |
| Power Supply | 24 VDC system supply |
| Installation Type | Rack-mounted I/O module |
| Operating Environment | Industrial automation systems |
| Dimensions | 137 × 35.6 × 137.16 mm |
| Weight | 0.18 kg |
Function and Working Principle
The 900H32-0202 module functions as a digital signal execution interface between the HC900 controller and field devices.
It is responsible for:
- Receiving output commands from the controller CPU
- Switching 24 VDC outputs ON or OFF based on logic execution
- Driving external devices such as relays, lamps, and actuators
- Providing electrical isolation between control system and field wiring
- Protecting outputs using electronic current limiting mechanisms
- Indicating real-time channel status via LEDs
Each output channel represents one discrete control point in the automation system.
System Role in Architecture
The Honeywell 900H32-0202 plays a field-level execution role in industrial automation systems.
It is typically used for:
- Machine start/stop control
- Relay and solenoid actuation
- Alarm and indicator systems
- Process interlock logic execution
- Industrial sequence control systems
It does not perform logic processing but executes commands from the central controller.
Industrial Applications
- Oil and gas processing plants
- Petrochemical refineries
- Power generation systems
- Chemical production facilities
- Water treatment systems
- Industrial manufacturing automation
- HVAC and utility control systems
Installation & Integration
Proper installation ensures reliable operation:
- Installed in Honeywell HC900 control racks
- Connected via system backplane interface
- Requires regulated 24 VDC power supply
- Mounted inside industrial control cabinets
- Wired to field devices via terminal blocks
- Configured during system commissioning
Compatible Components
- Honeywell HC900 CPU modules (C50, C70, C75 series)
- Digital input modules (DI counterparts)
- Analog I/O modules
- Field relays, solenoids, and actuators
- Industrial power supply units
- Rack and backplane systems
Recommended Alternative Models
| Model | Type | Application |
|---|---|---|
| 900H32-0101 | Same module variant | Similar output configuration |
| 900H32-0302 | Alternative revision | System compatibility variant |
| Relay output modules | Electromechanical type | Higher load switching |
| Remote I/O DO modules | Distributed architecture | Network-based systems |
| PLC digital output modules | Generic replacement | Modern automation systems |
Key Advantages
- High-density 32-channel output capability
- Fast and reliable ON/OFF switching
- Strong electrical isolation between channel groups
- Compact rack-mounted design
- Stable performance in harsh industrial environments
- Integrated diagnostics and protection features
- Compatible with HC900 architecture
FAQs
Q1: What is the main function of this module?
It converts controller commands into 24 VDC digital outputs.
Q2: What devices can it control?
Relays, solenoids, lamps, and other discrete field devices.
Q3: Does it perform logic control?
No, it only executes output commands from the CPU.
Q4: What type of output is it?
High-side (sourcing) 24 VDC digital output.
Q5: Why is it important?
It enables physical control of industrial equipment from the control system.
Conclusion
The Honeywell 900H32-0202 Digital Output Module is a high-density and reliable output component in HC900 automation systems. It ensures accurate and stable switching of field devices, forming a critical part of industrial control execution architecture.
