🧾 Product Overview: Honeywell 8C-SHEDA1 (51307186-175)
📌 Product Introduction
The Honeywell 8C-SHEDA1 is a specialized analog input module designed to provide high-precision data acquisition and signal conditioning for industrial process control systems. It belongs to Honeywell’s Series 8 automation platform, which is well-regarded for its robust performance, reliability, and scalability in complex industrial environments. The module handles multiple analog inputs and supports advanced diagnostics to maintain continuous operation and improve process safety.
⚙️ Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 8C-SHEDA1 (Part Number: 51307186-175) |
| Module Type | Analog Input Module |
| Input Channels | 16 analog inputs |
| Input Signal Types | Current (4-20 mA), Voltage (0-10 V) |
| Resolution | 16-bit A/D conversion |
| Accuracy | ±0.05% of full scale |
| Input Impedance | >100 kΩ (Voltage), 250 Ω (Current) |
| Power Supply | 24 VDC ±10% |
| Power Consumption | < 4 W |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 0% to 95% non-condensing |
| Vibration Resistance | 5 g, 10 Hz to 2 kHz |
| Shock Resistance | 50 g, 11 ms |
| Isolation Voltage | 1000 VAC RMS |
| Communication Interface | Series 8 backplane bus |
| Dimensions (W × H × D) | 100 mm × 160 mm × 25 mm |
| Weight | 0.48 kg |
🛠️ Applications
-
Process Control Systems: Accurate measurement of analog process variables such as temperature, pressure, and flow.
-
Safety Instrumented Systems (SIS): Reliable analog input for critical safety monitoring and shutdown processes.
-
Industrial Automation: Integration with control systems requiring high precision and robust data acquisition.
-
Remote Monitoring: Supports remote signal acquisition for centralized monitoring and diagnostics.
-
Environmental Control: Measurement of environmental parameters in industrial settings.
✅ Advantages
-
High Accuracy and Resolution: 16-bit conversion ensures precise analog data representation for critical process variables.
-
Wide Input Signal Compatibility: Supports both voltage and current input types, allowing versatile applications.
-
Robust Construction: Designed to withstand vibration, shock, and temperature extremes common in industrial environments.
-
Advanced Diagnostics: Provides detailed module health monitoring and fault detection to enhance uptime.
-
Compact and Modular: Fits into Honeywell’s Series 8 chassis for easy integration and scalability.
-
Low Power Consumption: Efficient design minimizes power needs, reducing operational costs.
🔄 Related Models in the Series 8 or Similar
| Model | Input Channels | Input Signal Type | Power Supply | Weight (kg) | Dimensions (mm) |
|---|---|---|---|---|---|
| 8C-SHEDA2 | 8 analog inputs | Current, Voltage | 24 VDC | 0.45 | 100 × 160 × 25 |
| 8C-SHEDA3 | 24 analog inputs | Current, Voltage | 24 VDC | 0.6 | 100 × 160 × 25 |
| 8C-SHEDA4 | 32 analog inputs | Current, Voltage | 24 VDC | 0.65 | 100 × 160 × 25 |
| 8C-SHEDA5 | 16 thermocouple inputs | Thermocouples | 24 VDC | 0.5 | 100 × 160 × 25 |
| 8C-SHEDA6 | 16 RTD inputs | RTDs (Resistance Temperature Detectors) | 24 VDC | 0.5 | 100 × 160 × 25 |
⭐ Popular Models from the Same Brand
| Model | Function | Channels | Power Supply | Weight (kg) | Dimensions (mm) |
|---|---|---|---|---|---|
| 8C-POIL51 | Digital Output Module | 32 | 24 VDC | 0.5 | 100 × 160 × 25 |
| 8C-PDZPA1 | Digital Input Module | 32 | 24 VDC | 0.5 | 100 × 160 × 25 |
| 8C-PDISA1 | Digital Input Module | 16 | 24 VDC | 0.4 | 100 × 160 × 25 |
| 8C-POIL31 | Digital Output Module | 24 | 24 VDC | 0.5 | 100 × 160 × 25 |
| 8C-SHEDA7 | Analog Input Module | 24 | 24 VDC | 0.6 | 100 × 160 × 25 |
🧠 Frequently Asked Questions (QA)
Q1: What type of input signals does the 8C-SHEDA1 support?
A1: It supports analog current (4-20 mA) and voltage (0-10 V) input signals.
Q2: How many input channels are available?
A2: The module offers 16 analog input channels.
Q3: What is the resolution of the analog-to-digital conversion?
A3: The module uses 16-bit A/D conversion for high precision.
Q4: What power supply is required for the module?
A4: A 24 VDC power supply with ±10% tolerance is required.
Q5: Can the 8C-SHEDA1 module operate in harsh industrial environments?
A5: Yes, it is designed to operate in temperatures from -40°C to +70°C and withstands shock and vibration.
Q6: What are the physical dimensions and weight of the module?
A6: Dimensions are 100 mm × 160 mm × 25 mm, weighing approximately 0.48 kg.
Q7: Is the module compatible with other Series 8 products?
A7: Yes, it integrates seamlessly into the Honeywell Series 8 chassis and bus system.
Q8: Does it offer diagnostic capabilities?
A8: Yes, advanced diagnostics provide module health status and fault detection.
Q9: What industries commonly use this module?
A9: Industries such as oil & gas, chemical processing, power generation, and manufacturing use it extensively.
Q10: How is the module connected to the control system?
A10: It connects via the Series 8 backplane bus system, allowing easy installation and communication.
