Emerson KJ3002X1-BD1 12P1033X102 Terminal Module Unit
Product Introduction
The Emerson KJ3002X1-BD1 12P1033X102 Terminal Module Unit is a crucial component of Emerson’s DeltaV Series control systems, offering a compact and robust solution for process automation. Designed for high-performance applications, this terminal module integrates seamlessly into the DeltaV system, providing efficient data acquisition and signal processing for control systems in industrial automation.
This terminal module is designed to manage multiple input and output signals, ensuring that real-time process data is captured and transmitted reliably. The compact size of 107 x 41 x 105 mm and its lightweight build (0.5 kg) make it easy to install in space-constrained control panels. It plays an essential role in applications where precise data acquisition and signal handling are crucial for system integrity and performance.
Product Parameters
| Parameter | Value |
|---|---|
| Model | Emerson KJ3002X1-BD1 12P1033X102 |
| Module Type | Terminal Module Unit |
| Dimensions | 107 x 41 x 105 mm |
| Weight | 0.5 kg |
| Input/Output Type | Digital/Analog I/O |
| Power Supply | 24 V DC |
| Operating Temperature | -20°C to 60°C |
| Mounting Type | DIN Rail Mounting |
| Signal Types Supported | Voltage, Current, RTD, Thermocouple |
| Installation Type | Modular (DeltaV System) |
| Communication Interface | HART, Foundation Fieldbus |
| LED Indicators | Yes (for status and diagnostics) |
| Enclosure Rating | IP20 |
Applications
The Emerson KJ3002X1-BD1 12P1033X102 Terminal Module Unit is used in a variety of applications within industrial automation systems, particularly those that require high-accuracy and reliability. Key applications include:
-
Process Control Systems: Ideal for integrating with DeltaV control systems, providing high-quality data handling for critical process applications like temperature, pressure, and flow monitoring.
-
Oil and Gas: Used for controlling and monitoring oil rigs, refineries, and pipelines, ensuring optimal operation in harsh environmental conditions.
-
Pharmaceutical Manufacturing: The module is vital for maintaining precise control over the production process, where stringent regulatory standards demand high accuracy and traceability.
-
Power Generation: It plays a key role in power plants, monitoring and controlling critical parameters such as turbine speeds, temperature, and pressure.
-
Chemical Processing: With its rugged design and flexible communication capabilities, it’s well-suited for chemical production facilities requiring reliable data acquisition and control.
Advantages of the Emerson KJ3002X1-BD1 12P1033X102 Terminal Module Unit
-
Compact and Space-Efficient: Its small form factor of 107 x 41 x 105 mm and weight of just 0.5 kg make it ideal for installations where space is limited.
-
Flexible I/O Capabilities: Supports both digital and analog inputs and outputs, allowing it to be used in a wide range of applications, from basic control to complex monitoring systems.
-
Seamless Integration with DeltaV: Being part of the DeltaV Series, it integrates seamlessly with the entire DeltaV system, ensuring smooth communication and control across the system.
-
Wide Operating Temperature Range: With an operating range from -20°C to 60°C, it can function effectively in a variety of harsh industrial environments.
-
Reliable Communication Interfaces: Supports HART and Foundation Fieldbus communication protocols, ensuring compatibility with a broad range of field devices.
-
Diagnostic Capabilities: Equipped with LED indicators, it allows for easy monitoring of module status and quick identification of faults, reducing downtime and simplifying troubleshooting.
-
Rugged and Durable: The module’s IP20-rated enclosure ensures protection against dust and physical damage, enhancing its longevity and operational reliability in industrial settings.
-
Easy Installation: The DIN rail mounting design simplifies installation and ensures secure module positioning within control panels.
Brand Information
Emerson Electric is a global leader in providing technology and engineering solutions for industrial, commercial, and consumer markets. The DeltaV Series is Emerson’s flagship process automation solution, offering a scalable, reliable, and flexible control platform. The KJ3002X1-BD1 12P1033X102 Terminal Module Unit is part of this series and represents Emerson’s commitment to offering cutting-edge solutions for the automation industry.
DeltaV Series Related Models
Here are five related or similar models within the DeltaV Series:
| Model | Module Type | Weight | Dimensions (mm) | Signal Types | Power Supply |
|---|---|---|---|---|---|
| Emerson KJ3001X1-BD1 | Terminal Module Unit | 0.4 kg | 107 x 41 x 105 | Digital/Analog I/O | 24 V DC |
| Emerson KJ3002X1-BD2 | Terminal Module Unit | 0.5 kg | 107 x 41 x 105 | Voltage/Current/RTD | 24 V DC |
| Emerson KJ3001X1-BD2 | Terminal Module Unit | 0.4 kg | 107 x 41 x 105 | Thermocouple/Analog I/O | 24 V DC |
| Emerson KJ3002X1-BD3 | Terminal Module Unit | 0.55 kg | 107 x 41 x 105 | HART/Analog I/O | 24 V DC |
| Emerson KJ3002X1-BD4 | Terminal Module Unit | 0.5 kg | 107 x 41 x 105 | Digital I/O | 24 V DC |
Popular Models from Emerson Electric
Here are five other popular models from Emerson Electric:
| Model | Module Type | Weight | Dimensions (mm) | Signal Types | Power Supply |
|---|---|---|---|---|---|
| Emerson KJ4001X1-BA1 | Analog Output Module | 0.6 kg | 120 x 50 x 120 | Analog Output | 24 V DC |
| Emerson KJ4003X1-BA1 | Analog Input Module | 0.55 kg | 120 x 50 x 120 | Analog Input | 24 V DC |
| Emerson KJ5002X1-BA1 | Digital Output Module | 0.5 kg | 115 x 45 x 115 | Digital Output | 24 V DC |
| Emerson KJ5001X1-BA1 | Digital Input Module | 0.5 kg | 115 x 45 x 115 | Digital Input | 24 V DC |
| Emerson KJ6001X1-BA1 | Controller Module | 1.2 kg | 140 x 60 x 150 | Process Control | 24 V DC |
FAQ for Emerson KJ3002X1-BD1 12P1033X102 Terminal Module Unit
Q1: What is the weight of the Emerson KJ3002X1-BD1 12P1033X102 Terminal Module Unit?
A1: The module weighs 0.5 kg.
Q2: What is the power supply required for this terminal module?
A2: The module requires a 24 V DC power supply.
Q3: Can the KJ3002X1-BD1 be used in extreme temperatures?
A3: Yes, it has an operating temperature range from -20°C to 60°C, making it suitable for harsh environments.
Q4: How is the module mounted?
A4: The module is designed for DIN rail mounting, which simplifies installation.
Q5: What communication protocols does the KJ3002X1-BD1 support?
A5: The module supports HART and Foundation Fieldbus protocols for reliable communication with field devices.
Q6: What are the signal types supported by this terminal module?
A6: The module supports digital and analog I/O signals, including voltage, current, RTD, and thermocouple signals.
Q7: Is this module compatible with other Emerson DeltaV components?
A7: Yes, it integrates seamlessly with the DeltaV Series, ensuring smooth operation in large-scale automation systems.
Q8: Does the module have diagnostic capabilities?
A8: Yes, the module includes LED indicators for easy monitoring and diagnostics.
Q9: What is the enclosure rating of the module?
A9: The module has an IP20 enclosure rating, protecting it from dust and physical damage.
Q10: What are the dimensions of the KJ3002X1-BD1 terminal module?
A10: The module’s dimensions are 107 x 41 x 105 mm.
