1. Product Introduction: Bently Nevada 3500/62 136483‑01
The 3500/62 (Part Number 136483‑01) is a Discrete Input / Discrete Output (I/O) Module in the 3500 Machinery Protection System. Its principal function is to interface the protection system rack with external digital (binary) signals—accepting discrete inputs (status, logic, fault signals, trip signals) and providing discrete outputs (alarm status, relay commands, interlocks).
By bridging real-world digital signals and the 3500 system’s protection logic, the 3500/62 module enables flexible control, monitoring, and integration of auxiliary systems, shutdown logic, and interlock schemes. It plays a pivotal role in automating protective actions and providing system-level coordination in a machinery protection environment.
2. Technical Specifications
| Parameter | Typical / Nominal Value |
|---|---|
| Model | 3500/62 136483‑01 |
| Discrete Input Channels | 16 inputs (isolated contacts or voltage logic) |
| Input Types Supported | Dry contact, open collector, logic voltage signals |
| Discrete Output Channels | 16 outputs (isolated, relay‑drive compatible) |
| Output Types Supported | Logic level, relay driver capability |
| Signal Isolation | Galvanic isolation between channels and backplane |
| Response Time | ~10 ms typical (input → output) |
| Buffering / Latching | Configurable latching, buffering, de-bounce |
| Power Consumption | ≈ 6 W |
| Operating Temperature Range | –30 °C to +65 °C |
| Storage Temperature Range | –40 °C to +85 °C |
| Humidity Tolerance | Up to 95% non-condensing |
| Mounting / Rack Interface | Full‑height slot in 3500 Series rack |
| Dimensions (L × W × H) | 241.3 mm × 24.4 mm × 99.1 mm |
| Weight | 0.30 kg |
3. Applications
The 3500/62 136483‑01 module is applied wherever digital (binary) interactions between protection logic and external systems are needed. Key use cases include:
-
Receiving start/stop commands, system enable/disable status from external control systems
-
Accepting “fault” signals from external sensors or machine controllers
-
Dispatching relay trigger signals, trip outputs, or interlock commands to machinery or protective devices
-
Integrating emergency shutdown logic, permissives, and alarm logic
-
Interfacing with SCADA/DCS systems for status supervision
-
Coordinating multi-module or multi-loop protection strategies
Typical industrial settings include power plants, petrochemical complexes, refineries, heavy manufacturing, and rotating machine control centers.
4. Advantages & Key Features
-
High Channel Count I/O: Provides robust 16 input and 16 output binary channels
-
Galvanic Isolation: Prevents cross-talk and improves signal integrity
-
Fast Response: Low latency (~10 ms) from input to output for critical protective actions
-
Configurable Logic: Supports latching, de‑bounce, buffering, and custom switching logic
-
Seamless System Integration: Works natively within the 3500 rack and logic environment
-
Compact & Modular: Fits standard 3500 rack footprint
-
Industrial Ruggedness: Broad temperature range and humidity tolerance
-
Versatile Interfacing: Compatible with relay drivers and logic-level equipment
5. Brand & Series
-
Brand: Bently Nevada
-
Series / Platform: 3500 Machinery Protection System
The 3500 Series is a modular condition monitoring and protection architecture widely used in industrial environments for rotating machinery.
6. Related / Alternative Models (Same Series or Functional Adjacent)
Here are five models in or adjacent to the 3500 series (same or complementary functions):
| Model | Function / Role | Input / Output Type | Channels / Capacity | Dimensions / Weight |
|---|---|---|---|---|
| 3500/62 136483‑01 | Discrete I/O module (this one) | Binary inputs & outputs | 16 in / 16 out | 241.3 × 24.4 × 99.1 mm, 0.30 kg |
| 3500/22M | Communication / Gateway module | Ethernet, serial, digital I/O | System interface | Standard rack, ~0.80 kg |
| 3500/50 | Process / Analog Input module | Voltage, current, temperature signals | 8 analog inputs | Rack footprint, ~0.25 kg |
| 3500/40M | Proximity / Displacement monitor | Proximity sensors | 4 channels | Rack format, ~0.73 kg |
| 3500/94M | Local display / monitor interface | VGA / user display | — | Rack size, ~0.82 kg |
These modules allow a comprehensive protection system combining discrete logic, analog processing, communication, and measurement.
7. Popular Models from the Same Brand
Here are five widely used modules from the Bently Nevada / 3500 family (or complementary systems):
| Model | Role / Application | Input / Output Type | Channels / Features | Dimensions / Weight |
|---|---|---|---|---|
| 3500/22M | Communication / Gateway Interface | Ethernet, serial, digital I/O | System node | Rack size, ~0.80 kg |
| 3500/42M | Vibration + Proximity Monitor | Proximity & vibration sensors | 2 or 4 channels | Rack footprint, ~0.75 kg |
| 3500/60 | Temperature Monitoring Module | RTDs, thermocouples | 6 temperature channels | Rack format, ~0.74 kg |
| 3500/50 | Process / Analog Input Module | Voltage, current signals | 8 channels | Rack size, ~0.25 kg |
| 3500/94M | Local Display / Interface | VGA / user interface | — | Rack size, ~0.82 kg |
8. FAQ — 10 Questions & Answers (Q&A Format)
Q1: What is the function of the 3500/62 module?
A1: It acts as a discrete I/O interface, receiving binary inputs and driving binary outputs for protection logic integration.
Q2: How many discrete input channels does it support?
A2: It supports 16 discrete input channels.
Q3: How many discrete outputs are available?
A3: It provides 16 discrete output channels.
Q4: What types of input signals can it accept?
A4: It accepts dry contact, open-collector, or logic-level voltage signals.
Q5: Are the I/O channels isolated?
A5: Yes, the module provides galvanic isolation between channels and the backplane.
Q6: What is its response time?
A6: The typical input-to-output latency is about 10 milliseconds.
Q7: Can outputs be latched or buffered?
A7: Yes, the module supports configurable latching, buffering, and de‑bounce logic.
Q8: What are its physical dimensions and weight?
A8: Dimensions: 241.3 mm × 24.4 mm × 99.1 mm; Weight: approximately 0.30 kg.
Q9: What is the operating temperature range?
A9: It operates between –30 °C and +65 °C, with storage from –40 °C to +85 °C.
Q10: Where is this module typically used?
A10: It is used in industrial protection systems to interface control logic, trip circuits, interlocks, and status monitoring systems.
