Product Overview & Description
The 3500/42 176449‑02 + 128229‑01 module constitutes a dual‑card system in a rack‑mounted rotating-machine protection platform. The front card (176449‑02) offers high‑precision signal conditioning from proximity, velocity, or acceleration sensors, enabling monitoring of radial vibration, axial displacement, shaft expansion, eccentricity, speed (via processed signals), and diagnostic modes like REBAM. The rear card (128229‑01) provides internal I/O termination for field wiring, dual 4–20 mA loop outputs per channel, and relay‑based alarm signals. The module is designed for hot‑swappable replacement, allowing maintenance without interrupting operation—ideal for critical/high‑uptime applications.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | 3500/42 176449‑02 + 128229‑01 |
| Brand | (omitted) |
| Series | 3500 Machinery Protection – Proximitor/Seismic Monitor |
| Type | Four‑channel proximitor/seismic condition monitor with internal I/O |
| Dimensions (mm) | Front card: ~241 × 24 × 99 mm; Rear card: ~241 × 24 × 99 mm |
| Weight (kg) | Front: ~0.40 kg; Rear: ~0.40 kg |
| Input Channels | Four differential channels (~10 kΩ input impedance) |
| Supported Sensors | Proximity (eddy-current), velocity, acceleration |
| Measured Parameters | Vibration, axial displacement, expansion, eccentricity, shaft diagnostics |
| Power Consumption | Approx. 7.7 W (24 V DC typical) |
| Outputs | Buffered analog; dual 4–20 mA loops per channel; alarm relays |
| Sensitivities | Displacement: ~3.94–7.87 mV/µm; Velocity: ~20 mV/(mm/s); Accel: ~10 mV/(m/s²) |
| Operating Range | –40 °C to +85 °C industrial duty |
| Mounting | Standard rack slot; hot‑swappable front & rear components |
Applications
Perfect for high‑reliability environments, this module supports real‑time condition monitoring of rotating machinery—turbines, generators, pumps, compressors. Its wide range of supported sensor types allows it to detect imbalance, misalignment, bearing degradation, or shaft movement. The internal dual 4–20 mA outputs link seamlessly into trending and recorder systems; relay outputs enable alarming. The hot‑swap capability ensures minimal downtime during maintenance, maintaining continuous protection.
Advantages
-
Versatile and comprehensive: Monitors multiple vibration domains within a single module.
-
Robust I/O integration: Dual 4–20 mA loops per channel and relay alarms enhance integration flexibility.
-
Hot‑swappable: Enables serving or replacing components without shutting down operations.
-
Compact and clean wiring: Internal termination keeps installations neat and accessible.
-
High accuracy: Supports multiple sensor types with reliable conditioning and signal fidelity.
-
Built for industry: Wide operating temperature range, vibration-resistant and reliable.
Related or Similar Series Models
| Model | Description | Inputs | Outputs |
|---|---|---|---|
| 3500/42 140734‑02 | Multi‑domain proximitor/seismic module | Displacement, velocity, accel. | Dual 4–20 mA, relays |
| 3500/42 135489‑01 | Module with internal safety barrier | Similar to above | Same |
| 3500/40 140734‑01 | Front-only displacement monitor | Displacement | Buffered analog output |
| 3500/42 138708‑01 | Shaft‑position I/O unit with internal termination | Shaft position | Buffered analog / logic outputs |
| 3500/22 138607‑01 | Temperature monitor for thermal monitoring | RTD/Thermocouple | Analog outputs |
Popular Models (Same Brand)
| Model | Description | Inputs | Outputs |
|---|---|---|---|
| 3500/22 | Temperature monitor (RTD or thermocouple) | Temperature sensors | Analog outputs |
| 3500/32 | Alarm relay module for general alarms | – | Relay outputs |
| 3500/33 | Multi-temperature monitoring module | Multiple thermal inputs | Analog outputs |
| 3500/50 | Tachometer/speed module | Speed sensor input | Digital / analog output |
| 3500/60 | Multifunction temperature module | Multiple thermal inputs | Analog outputs |
FAQ (10 Q&A)
-
Q: What types of sensors can be connected?
A: Proximity, velocity, and acceleration transducers. -
Q: How many channels does it support?
A: Four individually configurable measurement channels. -
Q: What outputs does each channel offer?
A: A buffered analog output plus a separate 4–20 mA loop. -
Q: What’s the module’s power requirement?
A: Approximately 7.7 W from a 24 V DC power supply. -
Q: Is it hot‑swappable?
A: Yes—both front and rear components can be replaced live. -
Q: What operating temperatures are supported?
A: From –40 °C up to +85 °C for industrial resilience. -
Q: Can it generate alarms?
A: Yes—it includes relay outputs for local alarming. -
Q: How is wiring handled?
A: All termination is internal, accessing the module from the back of the rack. -
Q: What is ReBAM?
A: Rolling‑Element Bearing Analysis Measurement—a fault‑detecting algorithm that the module supports. -
Q: What dimension/weight specs apply?
A: Each card is ~241 × 24 × 99 mm and ~0.40 kg in weight.
