Product Overview & Description
The 3500/42M 140734‑02 + 135489‑01 is a dual‑module, rack‑mounted protection monitor engineered for rotating machinery health surveillance. The 140734‑02 front card manages signal conditioning from proximity and seismic transducers, capturing metrics like radial vibration, axial (thrust) displacement, differential expansion, eccentricity, acceleration, velocity, shaft absolute position, REBAM diagnostics, and circular acceptance region. The 135489‑01 rear card offers internal termination with safety barriers, streamlined field wiring, and alarm relay integration—all while maintaining hot‑swap capability for maintenance without interrupting system operation.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | 3500/42M 140734‑02 + 135489‑01 |
| Brand | (omitted) |
| Series | 3500 Machinery Protection – Proximitor/Seismic Monitor |
| Type | Four‑channel proximitor/seismic module with internal‑barrier I/O |
| Dimensions (mm) | Front card: ~165 × 133 × 85 mm (≈16 × 13 × 9 cm); Rear card: standard 3500 rear-module depth (≈160 mm) |
| Weight (kg) | Front: ~1.0 kg; Rear: ~0.3 kg |
| Input Channels | Four differential channels (~10 kΩ) for proximity, acceleration, and velocity sensors |
| Measured Parameters | Radial vibration, thrust position, differential expansion, eccentricity, acceleration, velocity, REBAM diagnostics, shaft position, circular acceptance region |
| Power Consumption | ~7.7 W at 24 V DC rack power (typical) |
| Outputs | Buffered analog outputs (~550 Ω), dual 4–20 mA loops, programmable alarm relays |
| Filtering/Sensitivity | Supports radial vibration sensitivity ~3.94 mV/µm (100 mV/mil) or ~7.87 mV/µm (200 mV/mil) |
| LED Indicators | Status (OK), TX/RX communication, Bypass |
| Operating Range | –40 °C to +85 °C (typical industrial grade) |
| Certifications | Meets industrial vibration‑monitoring standards (e.g., API 670) |
| Mounting | Rack‑mounted; hot‑swappable front and rear modules |
Applications
Suited for safeguarding critical rotating machinery such as turbines, compressors, pumps, and generators, this module enables real‑time monitoring of a wide array of mechanical parameters. Its multi‑sensor capability allows detection of early mechanical faults like misalignment, imbalance, bearing deterioration, or thermal expansion trends. The rear card’s built‑in safety barriers make it ideal for hazardous and demanding environments. Hot‑swap functionality and flexible analog outputs simplify integration into DCS, SCADA, and predictive maintenance frameworks.
Advantages
-
Comprehensive diagnostics: Merges displacement, vibration, acceleration, velocity, and advanced bearing diagnostics into a single module.
-
High fidelity: Low-power design paired with clean, noise‑resilient outputs ensures accuracy and signal integrity.
-
Service without downtime: Enables live maintenance through hot‑swappable design.
-
Enhanced safety and wiring: Internal barrier I/O reduces wiring complexity and enhances safety.
-
Flexible outputs: Rich blend of analog, relay, and buffered outputs to suit diverse control systems.
-
Robust resilience: Built for industrial extremes with high-temperature tolerance and sturdy construction.
Related Models (Same Series or Related)
| Model | Description | Dimensions (mm) | Weight (kg) |
|---|---|---|---|
| 3500/42M + 128229‑01 | Proximitor/Seismic monitor with internal I/O termination | Similar front + ~160 mm rear | ~1.0 + ~0.2 |
| 3500/42M + 128240‑01 | Same monitor with external I/O termination | Similar | Comparable |
| 3500/40M 140734‑01 | Proximity-only front card | Similar front only | ~1.0 |
| 3500/42M 138708‑01 | Shaft absolute output module with internal I/O | Standard rear size | ~0.3 |
| 3500/42M 140471‑01 | Proximity/velocity I/O module internal termination | Standard | ~0.3 |
Popular Models (Same Brand)
| Model | Description | Dimensions (mm) | Weight (kg) |
|---|---|---|---|
| 3500/22M | Transient data interface (waveform capture) | Standard front size | ~0.9 |
| 3500/32M | Four-channel relay alarm module | Standard front size | ~0.9 |
| 3500/33 | Temperature monitor (RTD/Thermocouple inputs) | Standard front size | ~0.9 |
| 3500/50M | Tachometer (speed) detection module | Standard front size | ~0.9 |
| 3500/60 | Multifunction temperature monitoring module | Standard front size | ~0.9 |
FAQ (10 Q&A)
-
Q: What functions does the front card 140734‑02 cover?
A: It processes proximity, vibration, acceleration, and speed inputs to derive rotating machinery metrics like radial vibration, shaft position, and REBAM diagnostics. -
Q: What role does the rear card 135489‑01 serve?
A: It delivers safe, internal termination, harnessing field wiring and integrating alarm relay outputs while preserving hot‑swap functionality. -
Q: How many channels are supported?
A: Four fully programmable independent channels. -
Q: What is the operating temperature range?
A: –40 °C to +85 °C, suitable for extreme industrial conditions. -
Q: How much power does the unit draw?
A: Approximately 7.7 W from the 24 V DC rack. -
Q: What is the displacement sensor sensitivity?
A: Typical range is about 3.94 mV/µm or 7.87 mV/µm. -
Q: Is it serviceable without shutdown?
A: Yes—the entire module supports hot‑swap replacement. -
Q: What outputs are available?
A: Buffered transducer outputs, dual 4–20 mA loops, and relay alarm outputs. -
Q: Can it monitor multiple diagnostic types?
A: Yes—vibration, displacement, acceleration, velocity, shaft health, and bearing condition analysis. -
Q: How does it help maintenance?
A: Programmable alarm thresholds and outputs allow early fault detection and integration with maintenance systems.
