Product Overview & Description
The 3500/42M 140734‑02 + 128229‑01 module is a dual-card configuration in a rack-mounted machinery protection system designed to monitor proximity (displacement) and seismic (vibration) signals. The 140734‑02 front card performs signal conditioning from proximity and seismic transducers, measuring parameters such as radial vibration, axial displacement, differential expansion, eccentricity, acceleration, velocity, shaft absolute position, and circular acceptance region. The 128229‑01 rear card provides an internal I/O interface with built‑in terminations for straightforward field wiring, alongside configurable user-programmable alarms based on the conditioned signals.
This module is engineered for industrial robustness—supporting rack integration, high accuracy, and simplified installation, making it well-suited for protecting rotating machinery like turbines, compressors, pumps, and motors in critical environments.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | 3500/42M 140734‑02 + 128229‑01 |
| Brand | (omitted) |
| Series | 3500 Machinery Protection – Proximitor/Seismic Monitor |
| Type | 4‑channel proximitor/seismic monitor with internal‑termination I/O |
| Dimensions (mm) | Front card: ~165 × 133 × 85 mm; Rear I/O card: standard 3500 rear size |
| Weight (kg) | Front card: ~1.0 kg; Rear card: ~0.3 kg |
| Input Channels | Four channels accepting proximity and seismic transducer inputs (~10 kΩ) |
| Sensor Compatibility | Eddy‑current proximity, acceleration, velocity probes |
| Measured Parameters | Vibration, displacement, expansion, eccentricity, acceleration, velocity, shaft absolute, circular acceptance |
| Power Consumption | Less than 10 W |
| Outputs | Buffered analog, 4–20 mA recorder outputs; digital or relay alarm outputs |
| Input/Output Range | Input: 0–5 V or 4–20 mA; Output: corresponding ranges |
| Communication Interface | RS‑485 Modbus RTU; optional Ethernet/IP |
| Operating Temperature | –40 °C to +70 °C (some rating up to +85 °C) |
| Humidity Range | Up to 95 % non‑condensing |
| Construction | Rugged stainless steel, compact form factor, IP-rated enclosure |
| Mounting | Rack-mount, integrates with standard 3500 Series frameworks |
Applications
This module is ideal for industrial real-time monitoring of rotating machinery such as turbines, generators, compressors, and pumps. It tracks displacement, vibration, velocity, and acceleration through proximity and seismic sensors, enabling early detection of misalignment, imbalance, bearing wear, and thermal expansion. Its compact design and automated alarm capabilities allow seamless integration into control systems, DCS, and predictive-maintenance architectures. The internal termination simplifies wiring, reducing installation time in high-volume or hazardous areas.
Advantages
-
Full-spectrum monitoring: Covers key parameters—vibration, displacement, acceleration, velocity—all in one module.
-
Accurate and reliable: Low-power design (<10 W), supports 4–20 mA outputs for precise recording and trending.
-
Compact yet robust: Stainless steel build ensures durability; IP-rated enclosure protects from dust and moisture.
-
Simplified installation: Internal termination reduces complexity and improves signal clarity.
-
Flexible interfacing: Analog, digital (Modbus RTU, Ethernet/IP), and alarm outputs support versatile integration.
-
Wide operating range: Operates reliably in –40 °C to +70/85 °C environments with high humidity tolerance.
Related Models (Same Series or Similar)
| Model | Description | Dimensions (mm) | Weight (kg) |
|---|---|---|---|
| 3500/42M + 128240‑01 | Proximitor/seismic with external I/O termination | Similar front + external rear | ~1.0 + ~0.3 |
| 3500/42M 135489‑01 | With internal barrier I/O (Prox/Accel) | Similar | Similar |
| 3500/40M 140734‑01 | Proximity-only front monitor | Compact | ~1.0 |
| 3500/42M 138708‑01 | Shaft absolute I/O module, internal terminations | Standard rear size | ~0.3 |
| 3500/42M 140471‑01 | Prox/Velom I/O with internal terminations | Standard rear size | ~0.3 |
Popular Models (Same Brand)
| Model | Description | Dimensions (mm) | Weight (kg) |
|---|---|---|---|
| 3500/22M | Transient data interface (waveform capture) | Standard front size | ~0.9 |
| 3500/32M | Alarm relay module (4-channel) | Standard front size | ~0.9 |
| 3500/33 | Temperature monitoring (RTD/Thermocouple) | Standard front size | ~0.9 |
| 3500/50M | Tachometer/speed detection | Standard front size | ~0.9 |
| 3500/60 | Multi-channel temperature module | Standard front size | ~0.9 |
FAQ (10 Q&A)
-
Q: What does the front card (140734‑02) do?
A: It conditions signals from proximity and seismic transducers, measuring vibration, displacement, acceleration, and more. -
Q: What is the function of the rear card (128229‑01)?
A: It provides internal termination for wiring, alarm outputs, and interfaces with the rack backplane. -
Q: What parameters can it monitor?
A: Radial vibration, axial displacement, expansion, eccentricity, acceleration, velocity, shaft absolute position, circular acceptance region. -
Q: What are the operating voltage and power usage?
A: Operates on 24 V DC, consuming less than 10 W. -
Q: What environmental conditions can it endure?
A: It functions between –40 °C to +70 °C (some ratings to +85 °C) and up to 95 % non-condensing humidity. -
Q: What outputs are available?
A: Buffered transducer outputs, 4–20 mA recorder outputs, alarm outputs, and digital communication (e.g., Modbus RTU or Ethernet/IP). -
Q: What is the physical size?
A: Front card approximately 165 × 133 × 85 mm; rear card standard size in the 3500 series rack. -
Q: What is its construction like?
A: Compact stainless steel enclosure, designed for IP protection and industrial longevity. -
Q: How does it simplify installation?
A: With internal I/O termination, wiring is quicker and cleaner, reducing installation errors. -
Q: Can it alert operators automatically?
A: Yes—it compares processed signals against user-defined thresholds and triggers alarms through relay or digital outputs.
