Product Overview
Product Name
Bently Nevada 3500/22 288055‑01 + 146031‑01
Series
3500 Series – Machinery Protection and Condition Monitoring System
Product Introduction
This dual-module offering within the 3500 Series enables advanced transient event recording and storage:
-
288055‑01 – A Transient Data Acquisition (TDA) module, designed to continuously monitor vibration inputs and selectively capture envelope or timewave data during abnormal events. It triggers on fault detection conditions.
-
146031‑01 – A High-speed Memory Module (HSM) that stores the captured transient event data into onboard memory for later retrieval and analysis.
Together, these modules form a critical toolkit for detecting and documenting rapid or transient vibration events, aiding post-event diagnostics and repair planning.
Applications
Typical use cases include:
-
Capturing vibration anomalies during startup, shutdown, impact events, or sudden load changes.
-
Recording detailed timewave signatures for condition monitoring and fault diagnosis.
-
Serving oil & gas compressors, steam/gas turbines, high-speed motors, and power generation equipment.
-
Used across industries such as petrochemical, power plants, marine propulsion, and heavy manufacturing.
Product Advantages
-
High-fidelity event capture, with selectable sample rates for accurate diagnostics.
-
Dedicated storage module, ensuring reliable retention of critical data.
-
Hot-swap functionality, enabling maintenance or replacement without downtime.
-
Rack-mountable form, fitting existing hardware layouts.
-
Granular insight into machine behavior, empowering predictive maintenance.
-
High durability design, suitable for tough industrial conditions.
-
Non-intrusive to continuous protection logic, maintaining system safety even during captures.
Technical Specifications
| Parameter | 288055‑01 (TDA Module) | 146031‑01 (Memory Module) |
|---|---|---|
| Function | Captures envelope/timewave on triggers | Stores event data for retrieval |
| Sampling Rate | Up to ~64 k samples/sec | N/A (storage only) |
| Memory Capacity | Event buffer | ~8 MB ring buffer |
| Hot-Swappable | Yes | Yes |
| Form Factor | Full-height rack module | Full-height rack module |
| Dimensions (HxWxD) | ~241 × 24 × 99 mm | ~241 × 24 × 99 mm |
| Weight (kg) | ~0.95 kg | ~0.95 kg |
| Power Consumption | ~5 W | ~3 W |
| Operating Temperature | –40 °C to +85 °C | –40 °C to +85 °C |
| Data Interface | Rack bus data path | Rack bus data path |
| Trigger Support | Event-driven capture | Storage and data preservation |
Related Models (Same Series / Related Functionality)
| Model | Function | Form Factor | Weight (kg) |
|---|---|---|---|
| 3500/22 138607‑01 | Transient Data Interface capturing vibration data | Full-height | ~0.9 kg |
| 3500/22 138610‑01 | Envelope-only transient data capture | Full-height | ~0.9 kg |
| 3500/22 138620‑01 | Expanded memory transient storage (~16 MB) | Full-height | ~1.0 kg |
| 3500/22M | Alternative transient data interface | Full-height | ~0.9 kg |
| 3500/20 125744‑02 | Rack Interface Module (RIM) | Full-height | ~0.9 kg |
Popular Models from the Same Brand
| Model | Function | Form Factor | Weight (kg) |
|---|---|---|---|
| 3500/40M | Proximitor / Vibration Monitor | Full-height | ~0.75 kg |
| 3500/60 | Temperature Monitoring Module | Full-height | ~0.8 kg |
| 3500/45 | Speed / Keyphasor Monitoring Module | Full-height | ~0.9 kg |
| 3500/65 | 16-Channel Temperature Monitoring Module | Full-height | ~0.85 kg |
| 3500/92 | Communication Gateway (Ethernet/Serial) | Full-height | ~0.7 kg |
FAQ
Q1: What does the 288055‑01 module do?
A1: It captures timewave or envelope data on fault triggers, such as rub detection or overspeed events.
Q2: What is the purpose of the 146031‑01 module?
A2: It stores the captured transient data, maintaining it for post-event review and analysis.
Q3: Can these modules be replaced while the system is running?
A3: Yes—both modules support hot-swapping, allowing maintenance without interruptions.
Q4: What size are these modules?
A4: Each is a full-height form factor approximately 241 mm tall, 24 mm wide, and 99 mm deep.
Q5: How much does each module weigh?
A5: Both modules weigh around 0.95 kg each.
Q6: What operating temperature range do they support?
A6: –40 °C to +85 °C, suitable for extreme industrial environments.
Q7: How much data can the memory module store?
A7: It offers roughly 8 MB of ring-buffer storage, enough for multiple event captures.
Q8: Is the sampling rate of the TDA module adjustable?
A8: Yes, it supports up to about 64,000 samples per second for detailed waveform capture.
Q9: Are these modules required together?
A9: The capture module can trigger data acquisition alone, but without the memory module, the data cannot be retained.
Q10: Will capturing events interfere with protective functions?
A10: No—event capture operates in parallel and does not disrupt real-time protection logic.
