1. Product Overview: 3500/05-01-03-00-00
A. Specifications
| Parameter | Details |
|---|---|
| Model | 3500/05-01-03-00-00 |
| Type | 19-slot rack assembly for 3500 Machinery Protection System |
| Dimensions (L×W×H) | 580 mm × 350 mm × 210 mm |
| Weight | Approx. 7.0 kg |
| Material | High-grade aluminum with steel reinforcements |
| Power Supply | Supports dual redundant power modules |
| Cooling | Passive convection cooling with ventilation slots |
| Indicators | Multi-color LED indicators for module health and system status |
| Mounting | Rack mount, panel mount, or bulkhead options |
| Environmental Ratings | Designed for harsh industrial environments with resistance to vibration, EMI, and temperature variations |
| Module Compatibility | Compatible with all standard 3500 series modules including vibration, temperature, and speed sensors |
B. Product Introduction
The 3500/05-01-03-00-00 is a 19-slot rack system designed for the 3500 Machinery Protection System, renowned for its robustness and versatility. It acts as the central chassis for housing multiple monitoring modules, providing reliable power distribution, communication pathways, and physical protection.
Engineered for challenging industrial environments, this rack assembly features reinforced aluminum construction and steel components to ensure mechanical strength and resistance to vibrations. Its passive cooling design reduces maintenance needs and improves system uptime. LED indicators on each slot provide real-time visual feedback on module status, simplifying troubleshooting and maintenance activities.
C. Applications
-
Power Generation Plants: Monitoring critical rotating machinery like turbines and generators.
-
Oil & Gas Industry: Supervising pumps, compressors, and safety-critical rotating equipment.
-
Chemical Plants: Tracking equipment condition to prevent unexpected downtime.
-
Water and Wastewater Facilities: Ensuring reliable pump and motor operation.
-
Mining and Metals: Monitoring heavy-duty machinery for early fault detection.
D. Advantages
-
Large Capacity: 19 slots allow extensive module integration, supporting complex monitoring configurations.
-
Rugged Build: Designed to withstand vibration, temperature extremes, and electromagnetic interference.
-
Modular Flexibility: Compatible with a wide range of 3500 series monitoring modules.
-
Intuitive Status Indicators: Multi-color LEDs provide quick, clear status insights for efficient maintenance.
-
Flexible Installation: Multiple mounting options adapt to various industrial setups.
-
Energy Efficient: Passive cooling eliminates the need for fans, lowering power consumption and maintenance.
E. Brand and Series
-
Brand: Bently Nevada
-
Series: 3500 Machinery Protection System
2. Recommended Models
A. Related Models in the Same Series
| Model | Slot Count | Weight (kg) | Key Features |
|---|---|---|---|
| 3500/05-01-01-00-00 | 14 | 5.0 | Standard 14-slot rack with durable construction |
| 3500/05-01-02-00-00 | 14 | 5.2 | 14-slot rack with enhanced EMI resistance |
| 3500/05-01-03-00-00 | 19 | 7.0 | Large 19-slot rack with passive cooling |
| 3500/05-01-03-CN-00 | 19 | 7.2 | 19-slot rack optimized for high electromagnetic compatibility |
| 3500/05-01-03-R0-00 | 19 | 7.0 | 19-slot rack with robust mechanical design |
B. Popular Models from the Same Brand
| Model | Application | Weight (kg) | Key Features |
|---|---|---|---|
| 3500/15-01-01-00 | Power Supply Module | 0.5 | Redundant power supply for system reliability |
| 3500/22-01-00 | Analog Input Module | 0.6 | Multi-signal input module |
| 3500/40-02-00 | Position Monitoring | 0.7 | Pump position and speed monitoring module |
| 3500/50-02-00 | Speed Monitoring Module | 0.8 | Monitors rotating machinery speed |
| 3500/94-01-00 | Operator Interface | 0.9 | Real-time status and data display module |
3. Frequently Asked Questions (FAQ)
Q1: What is the main purpose of the 3500/05-01-03-00-00 rack?
A: It serves as the main chassis for housing up to 19 monitoring modules in the 3500 Machinery Protection System, providing power and communication support.
Q2: What are the physical dimensions of this rack?
A: The rack measures 580 mm in length, 350 mm in width, and 210 mm in height.
Q3: How much does the rack weigh?
A: It weighs approximately 7.0 kilograms.
Q4: Does the rack support redundant power supplies?
A: Yes, it is designed to support dual redundant power modules for high system availability.
Q5: What type of cooling does the rack use?
A: The rack uses passive convection cooling with ventilation slots, eliminating the need for fans.
Q6: Can this rack operate in high-vibration environments?
A: Yes, it is built with reinforced materials to withstand harsh industrial vibrations.
Q7: How are module statuses indicated?
A: Each module slot has multi-color LEDs that indicate health and operational status.
Q8: Is this rack compatible with all 3500 series modules?
A: Yes, it supports all standard 3500 series monitoring modules.
Q9: What mounting options are available for this rack?
A: It can be mounted as a rack, panel, or bulkhead mount to suit various installation needs.
Q10: What industries commonly use this rack?
A: It is widely used in power generation, oil & gas, chemical plants, water treatment, and mining sectors.
