The Bently Nevada 3500/05-01-02-02-00-01 is a 3500/05 System Rack used as the core hardware structure for the Bently Nevada 3500 series machinery protection system. This rack provides the physical mounting platform and internal electrical interconnections required for monitoring modules used in industrial equipment protection systems.
In critical industrial applications, reliable condition monitoring is essential to ensure safe and efficient operation of rotating machinery. The 3500/05 rack supports the installation of multiple monitoring modules, allowing engineers to configure a complete system for vibration monitoring, shaft position measurement, and equipment diagnostics.
With its standard 19-inch rack format and capacity for 14 modules, this rack offers a flexible and scalable solution for building advanced machinery protection systems used across various industrial sectors.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model | 3500/05-01-02-02-00-01 |
| Product Type | 3500/05 System Rack |
| System Platform | Bently Nevada 3500 Machinery Protection System |
| Rack Standard | 19-inch rack format |
| Module Capacity | 14 monitoring module slots |
| Rack Function | Installation and integration of monitoring modules |
| Mounting Type | Rack-mounted installation |
| System Compatibility | Compatible with Bently Nevada 3500 series modules |
| Weight | 4.5 kg |
| Application Environment | Industrial machinery monitoring systems |
Product Overview
The 3500/05 system rack provides the structural and electrical foundation required for the operation of Bently Nevada’s 3500 monitoring system. It allows multiple modules to be installed within a single rack while ensuring communication and power distribution through an integrated backplane.
Each monitoring module inserted into the rack connects to the internal backplane, enabling reliable data exchange between modules. This architecture allows the monitoring system to collect machine health data from various sensors and deliver accurate diagnostics for equipment protection.
Typical modules installed in the rack include vibration monitoring modules, relay output modules, communication interfaces, and power supply units. Together, these components create a comprehensive machinery protection platform capable of monitoring critical operating parameters of rotating equipment.
Because of its modular architecture, the rack can easily be expanded or customized depending on the monitoring requirements of specific industrial systems.
Applications
Turbine Protection Systems
Provides the rack infrastructure for vibration and displacement monitoring modules used in turbine protection systems.
Compressor Monitoring Platforms
Supports monitoring modules used to track vibration and rotational parameters in compressors.
Power Generation Facilities
Installed in generator monitoring systems that supervise rotating equipment health.
Oil and Gas Processing Plants
Forms the hardware base of machinery protection systems used in pumps and compressors.
Industrial Equipment Monitoring
Used in predictive maintenance systems to identify mechanical faults through vibration analysis.
Advantages
Modular Monitoring Platform
Supports multiple monitoring modules for flexible system configuration.
Standard Industrial Rack Format
The 19-inch rack design allows easy integration into standard industrial cabinets.
Expandable System Capacity
Fourteen module slots provide scalability for complex monitoring systems.
Reliable Internal Backplane
Ensures stable communication and power distribution between installed modules.
Industrial Durability
Designed to operate reliably in demanding industrial environments.
Compatible Monitoring Modules
The 3500/05 rack works with multiple modules that together form the Bently Nevada 3500 condition monitoring system.
| Module | Module Type | Function |
|---|---|---|
| 3500/15 | Power Supply Module | Provides system power |
| 3500/22M | Data Interface Module | Enables communication with monitoring software |
| 3500/25 | Keyphasor Module | Provides shaft rotational reference |
| 3500/42M | Proximitor/Seismic Monitor | Monitors vibration and displacement |
| 3500/32M | Relay Module | Provides alarm and shutdown outputs |
These modules enable a complete machinery protection and vibration monitoring system.
Recommended Alternative Models
For similar industrial monitoring rack applications, the following models are commonly used.
| Model | Product Type | Application | Key Feature |
|---|---|---|---|
| Bently Nevada 3500/05-01-01 | System Rack | Machinery monitoring | Standard rack configuration |
| Bently Nevada 3500/05-01-02 | System Rack | Equipment protection systems | Flexible installation |
| Bently Nevada 3500/05-01-02-00-00 | System Rack | Monitoring systems | Modular architecture |
| Bently Nevada 3500/05-01-02-01-00-00 | System Rack | Industrial monitoring | Extended configuration |
| Bently Nevada 3500 Monitoring Rack | Rack Platform | Condition monitoring systems | High compatibility |
Technical FAQs
What is the function of the Bently Nevada 3500/05 system rack?
The rack provides the structural frame and electrical connections required for installing monitoring modules within the 3500 machinery protection system.
How many modules can be installed in this rack?
The rack supports up to 14 monitoring modules, allowing flexible configuration for different monitoring applications.
Where is this rack typically used?
It is commonly installed in industrial control cabinets used for vibration monitoring and machinery protection systems.
Why is the rack important in the monitoring system architecture?
The rack organizes system modules, distributes electrical power, and enables communication between components of the monitoring platform.
