Bently Nevada 330130-045-12-CN – Full Technical Overview
1. Brand and Series
- Brand: Bently Nevada
- Series: 3300 XL Proximity Transducer System
- Model: 330130-045-12-CN
- Product Type: Extension Cable Assembly
This model is part of the 3300 XL vibration monitoring platform, widely used for rotating machinery protection and condition monitoring in industrial environments such as power generation, oil & gas, and petrochemical industries.
2. Product Introduction
The 330130-045-12-CN is a 4.5-meter extension cable used in the 3300 XL eddy-current proximity transducer system.
It connects the proximity probe to the proximitor sensor, ensuring stable and accurate transmission of vibration and displacement signals from rotating machinery.
This model is designed for industrial applications requiring high reliability and long-term stability under harsh operating conditions.
The code structure indicates:
- 045 → 4.5-meter cable length
- 12 → Armored FluidLoc-style sealed configuration (enhanced protection design)
- CN → China-specific manufacturing or compliance variant
3. Product Parameters (Specification Table)
| Parameter | Details |
|---|---|
| Model | 330130-045-12-CN |
| Series | 3300 XL |
| Product Type | Extension Cable Assembly |
| System Structure | Probe + Extension Cable + Proximitor Sensor |
| Cable Length | 4.5 meters |
| Cable Type | Armored triaxial shielded cable |
| Signal Type | Eddy-current proximity signal |
| Measurement Function | Vibration / Shaft Position / Speed |
| Connector Type | Gold-plated industrial connectors |
| Operating Voltage | -17.5 Vdc to -26 Vdc |
| Capacitance | ~69.9 pF/m typical |
| Operating Temperature | -40°C to +85°C |
| System Compatibility | 3300 XL 8 mm probe system |
| Environmental Resistance | Oil, vibration, EMI resistant |
| Manufacturing Variant | CN regional version |
| Dimensions | ~205 × 224 × 33 mm |
| Weight (kg) | ~0.8 – 1.6 kg |
4. Product Applications
This extension cable is widely used in industrial rotating machinery monitoring systems, including:
- Steam turbines
- Gas turbines
- Centrifugal compressors
- Industrial pumps
- Power generators
- Petrochemical processing equipment
Typical monitoring functions:
- Shaft vibration measurement
- Axial displacement tracking
- Speed and phase reference (Keyphasor signals)
It is particularly suitable for environments requiring stable signal transmission over medium distances in harsh industrial conditions.
5. Product Advantages
Stable Signal Transmission
Triaxial shielding design reduces electromagnetic interference and ensures signal clarity.
Industrial Durability
Armored cable construction provides strong resistance to vibration and mechanical stress.
Oil and Fluid Resistance
Enhanced sealing design helps prevent contamination and fluid ingress.
Wide Environmental Adaptability
Operates reliably under temperature fluctuations and harsh industrial conditions.
High System Compatibility
Fully compatible with 3300 XL proximity probe systems.
Secure Connector Design
Gold-plated connectors ensure stable electrical contact and corrosion resistance.
Long Service Life
Designed for continuous operation in critical machinery monitoring systems.
6. Same Series / Related Models (5 Recommended)
| Model | Type | Cable Length | Function | Weight (kg) |
|---|---|---|---|---|
| 330130-040-12-CN | Extension Cable | 4.0 m | Vibration signal transmission | ~0.6–1.4 |
| 330130-045-11-00 | Extension Cable | 4.5 m | FluidLoc industrial version | ~0.8–2.0 |
| 330130-050-12-CN | Extension Cable | 5.0 m | Extended monitoring system | ~0.9–1.6 |
| 330130-020-12-CN | Extension Cable | 2.0 m | Compact machinery systems | ~0.4–1.0 |
| 330130-080-12-CN | Extension Cable | 8.0 m | Long-distance monitoring | ~1.0–2.5 |
7. Popular Models from Same Brand (5 Recommended)
| Model | Type | Function | Output | Weight (kg) |
|---|---|---|---|---|
| 330101-00-00-10-02-00 | Proximity Probe | Vibration sensing | Analog signal | ~0.5 |
| 330180-50-00 | Proximitor Sensor | Signal conditioning | 4–20 mA | ~1.0 |
| 3500/22M | Monitoring Module | Data processing | Digital output | ~2.0 |
| 3500/25 | Keyphasor Module | Speed reference | Pulse signal | ~2.0 |
| 1900/65A | Machinery Monitor | Compact system monitoring | Digital | ~1.5 |
9. FAQ (10 Q&A)
Q1: What is the main function of this cable?
A: It transmits vibration and displacement signals between the probe and monitoring system.
Q2: What does “045” represent in the model?
A: It indicates a 4.5-meter cable length.
Q3: What does “12-CN” mean?
A: It indicates armored configuration with a China-specific manufacturing or compliance variant.
Q4: What system is it compatible with?
A: It is compatible with the 3300 XL proximity transducer system.
Q5: What type of signal does it carry?
A: It carries eddy-current proximity sensor signals.
Q6: Can it be used in harsh environments?
A: Yes, it is designed for vibration, oil exposure, and industrial EMI conditions.
Q7: What industries use this cable?
A: Power generation, oil & gas, petrochemical, and heavy industry sectors.
Q8: Does it require recalibration after replacement?
A: No, it is fully interchangeable within the system.
Q9: What is the typical weight?
A: Approximately 0.8 to 1.6 kg depending on configuration.
Q10: Why is this cable important in monitoring systems?
A: It ensures stable and accurate transmission of critical machinery condition data for protection and diagnostics.
