Product Overview: ABB XV C772 A101 (3BHE032285R0101)
The ABB XV C772 A101 is a cutting‑edge operator interface panel designed for industrial automation systems. It belongs to the mid‑to‑high performance HMI category, providing operators with intuitive graphical control and monitoring of machinery and processes. Robust workmanship, clear visuals, and flexible connectivity make this device well‑suited to modern automation environments.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model | ABB XV C772 A101 |
| Product Code | 3BHE032285R0101 |
| Display Size | 7.5 inches TFT color with touch |
| Display Resolution | 800 × 600 pixels (SVGA) |
| Touch Technology | Resistive touch screen |
| Processor | ARM Cortex‑A9 at 800 MHz |
| RAM | 512 MB |
| Flash Memory | 1 GB |
| Communication Interfaces | 1× Ethernet (10/100 Mbps), 2× USB (Host), 1× Serial (configurable RS‑232/485) |
| Expandability | SD‑card slot, optional I/O expansion module |
| Interfaces for Protocols | Supports Modbus, Ethernet/IP, OPC UA over Ethernet |
| Power Supply | 24 V DC (range 18–30 V DC) |
| Operating Temperature | 0 °C to +55 °C |
| Protection Rating | IP65 front, IP20 rear |
| Mounting Style | Standard panel mounting |
| Dimensions (W × H × D) | 230 × 180 × 48 mm |
| Weight | 1.2 kg |
Product Applications
The XV C772 A101 is suited for a wide range of industrial applications including:
-
Machine control panels in discrete manufacturing
-
Process control in chemical and pharmaceutical production
-
Packaging and bottling lines, enabling fast operator feedback
-
Building automation for HVAC and access control systems
-
Water and wastewater monitoring systems
Product Advantages
-
Higher resolution display (800 × 600) improves clarity for detailed graphics.
-
Faster processor (ARM Cortex‑A9 800 MHz) ensures snappy response in complex tasks.
-
Larger memory (512 MB RAM, 1 GB Flash) supports richer applications, logging, and more screens.
-
Flexible protocol support (OPC UA, Ethernet/IP) ensures future‑proof connectivity.
-
SD‑card slot and expansion capabilities allow on‑site upgrades and data exchange without disassembly.
-
Rugged IP65 front panel built for factory environments with reliable mechanical sealing.
Brand and Series Information
-
Brand: ABB
-
Series: XV C770 / XV C772 HMI family
-
Product Category: Human‑Machine Interface (HMI) panel
-
Designed For: Industrial automation control and monitoring applications.
Recommended Models from the Same or Related Series
| Model | Display Size | Memory | Interfaces | Protection | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| ABB XV C772 A101 | 7.5″ SVGA | 512 MB RAM, 1 GB Flash | Ethernet, USB, serial, SD | IP65/IP20 | 230 × 180 × 48 | 1.2 |
| ABB XV C770 BE101 | 7″ WVGA | 256 MB RAM, 512 MB Flash | Ethernet, USB, serial | IP65/IP20 | 212 × 156 × 46 | 1.1 |
| ABB XV C775 BE103 | 10.4″ SVGA | 512 MB RAM, 1 GB Flash | Ethernet, USB, RS‑485 | IP65/IP20 | 276 × 214 × 50 | 1.5 |
| ABB XV C781 BE104 | 12.1″ XGA | 1 GB RAM, 2 GB Flash | Ethernet, USB, CAN | IP65/IP20 | 320 × 240 × 52 | 2.0 |
| ABB XV C770 BE102 | 7″ WVGA | 256 MB RAM, 1 GB Flash | Ethernet, dual USB, RS‑232 | IP65/IP20 | 212 × 156 × 50 | 1.15 |
| ABB XV C780 AE106 | 15″ XGA | 1 GB RAM, 4 GB Flash | Ethernet, USB, RS‑485, SD | IP65/IP20 | 380 × 300 × 60 | 2.5 |
Popular Models from the Same Brand
| Model | Product Type | Key Features | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| ABB AC500 PM582‑ETH | PLC controller | Embedded Ethernet, fast scan cycle, compact module | 142 × 100 × 74 | 0.8 |
| ABB CP600‑Pro | HMI terminal | Capacitive touchscreen, multi‑touch, sleek design | 272 × 212 × 51 | 1.6 |
| ABB ACS580‑01 | AC drive | Vector control, built‑in safety, energy savings | 400 × 200 × 250 | 4.5 |
| ABB IRC5 | Robot controller | Multi‑axis motion control, flexible configuration | 550 × 550 × 600 | 45.0 |
| ABB TB820 V2 | I/O terminal base | DIN‑rail mount, modular I/O base for expansion | 140 × 50 × 30 | 0.2 |
