Product Description
The SDCS‑CON‑F01 (3ADT316500R1501) is a central control board in ABB’s DCS series (e.g., DCS550 drive systems). It handles system logic operations, I/O coordination, communication interface management, parameter storage, and monitoring.
In a drive system, this board sits in the central rack, collecting signals from measurement modules, power modules, and communication modules, processing them, and issuing control commands to subsystems. It is designed for industrial automation environments with high temperature/humidity requirements, variable loads, and high reliability.
The control board supports real-time control tasks (speed control, torque control, fault monitoring), multiple communication interfaces (like RS‑485 or Ethernet), and extensive diagnostics, ensuring precise and maintainable control of the drive system.
Technical Specifications
| Parameter | Description |
|---|---|
| Model | SDCS‑CON‑F01 (3ADT316500R1501) |
| Brand | ABB |
| Series | DCS Control Modules (e.g., DCS550 drive system) |
| Function | Control logic and interface board: manages I/O, communication, parameters, and system monitoring |
| Input Voltage | 24 V DC (logic supply) |
| Digital Inputs | 16 channels (typical) |
| Digital Outputs | 16 channels (typical) |
| Communication Ports | Ethernet, RS‑485 (typical) |
| Operating Temperature | ‑40 °C to +70 °C |
| Mounting | Plug-in board, installed in drive cabinet |
| Weight | ~0.34 kg |
| Dimensions (L×W×H) | ~215 mm × 150 mm × 35 mm |
| Protection Rating | IP20 (internal cabinet installation only) |
| Typical Use | Drive system control board, logic processing, communication bridge, parameter storage |
Applications
The SDCS‑CON‑F01 is used in high-reliability, high-precision industrial automation drives:
-
DCS550 series DC drive systems: central module coordinating subunit operation.
-
Steel, metallurgical, and mining industries: large motor drives, rolling mills, tailings conveyors.
-
Pulp & paper, chemical processes: centralized control of multiple drives.
-
Marine and offshore applications: ship propulsion, tugs, drilling platform auxiliary drives.
-
System upgrades: replace legacy control units with modular boards for maintainability and intelligence.
It handles real-time signal processing, fault monitoring, command dispatching, and communication bridging, ensuring stable operation and reduced downtime.
Advantages
-
High Reliability: Industrial-grade design, wide temperature tolerance, long-life components.
-
Modular Structure: Plug-in design for easy replacement and upgrades.
-
Flexible Communication: Multiple interface support for PLC/SCADA or field integration.
-
Compact and Lightweight: Saves cabinet space and reduces installation load.
-
Advanced Diagnostics: Built-in monitoring, logic error alerts, system health visibility.
-
Series Compatibility: Fits ABB DCS modules, simplifying system planning.
-
Lower Total Cost of Ownership: Reduces failures, improves maintenance efficiency.
-
Future Expandable: Supports system upgrades, remote monitoring, and smart maintenance.
Brand
ABB – Global industrial automation and drive technology supplier with strong reputation for reliability, compatibility, and maintainability. SDCS‑CON‑F01 reflects ABB’s expertise in modular control hardware.
Series
DCS Control Modules Series: Includes control logic boards (CON), communication boards (COM), measurement/conversion boards (AMC), and bus adapter boards (BAB). SDCS‑CON‑F01 is part of the CON series, handling core logic and system integration.
Related Models (Same Series / Similar)
| Model | Description | Typical Voltage/System | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| SDCS‑CON‑2 | Early control logic board | 24 V DC | ~215×150×35 | ~0.47 |
| SDCS‑CON‑2A | Variant control logic board | 24 V DC | ~215×150×35 | ~0.41 |
| SDCS‑CON‑2B | Improved version control board | 24 V DC | ~215×150×35 | ~0.49 |
| SDCS‑AC‑CON‑2 | AC conversion & interface board | 24 V DC | ~210×150×35 | ~0.45 |
| SDCS‑AMC‑DC‑2 | Analog/digital measurement board | 24 V DC | ~215×150×35 | ~0.47 |
Popular ABB Models (Other Products)
| Model | Type | Application | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| ACS880‑01‑07A6‑3 | AC drive | Industrial automation, heavy machinery | 390×260×160 | ~5.2 |
| DCS800‑S01‑0045‑05 | DC drive controller | Heavy industrial DC drive systems | 480×300×200 | ~7.6 |
| ACS580‑01‑025A‑4 | Frequency converter | HVAC, water treatment, conveyors | 380×250×180 | ~5.8 |
| ACS355‑03E‑04A7‑2 | Compact AC drive | Light automation, packaging, OEM | 200×90×180 | ~2.5 |
| ACS150‑03E‑07A5‑4 | Micro AC drive | Small motors, fans, OEM applications | 180×75×160 | ~2.1 |
