ABB PU516 3BSE013064R1 – Comprehensive Technical Overview and Product Specification Guide
1. Product Identification
Product Model: ABB PU516
Part Number: 3BSE013064R1
Brand: ABB
Series: Advant OCS
Product Type: Industrial Operator Interface Terminal
Category: Human-Machine Interface (HMI) Module
2. Product Introduction
The ABB PU516 3BSE013064R1 is a large-format operator interface terminal developed for advanced industrial automation systems. It is part of the Advant OCS distributed control platform and is designed to provide operators with enhanced visualization and interactive control capabilities.
The PU516 expands upon earlier PU51x series models by offering a larger display area and higher graphical resolution, enabling clearer process monitoring and improved alarm management. It serves as a central visualization device in control rooms, plant floors, and automation cabinets where real-time data interpretation and control interaction are essential.
Built for reliability, the PU516 supports continuous industrial operation. Its hardware architecture ensures stable communication with control processors and I/O subsystems, making it suitable for integration into complex automation infrastructures.
3. Technical Specifications
Electrical, Display and Mechanical Parameters
| Parameter | Specification |
|---|---|
| Model | PU516 |
| Part Number | 3BSE013064R1 |
| Series | Advant OCS Operator Interface |
| Display Type | Industrial TFT LCD |
| Display Size | 15 inch |
| Resolution | 1024 × 768 pixels |
| Touch Interface | Resistive Touchscreen |
| Processor | Embedded Industrial CPU |
| System Memory | 32 MB (approx.) |
| Flash Storage | 64 MB (approx.) |
| Power Supply | 24 V DC |
| Input Voltage Range | 19–30 V DC |
| Power Consumption | Approx. 35 W |
| Communication Interfaces | Serial Bus / System Bus / Field Communication Ports |
| Mounting Type | Panel or Rack Mount |
| Protection Rating | IP20 |
| Operating Temperature Range | 0°C to +55°C |
| Storage Temperature Range | –20°C to +70°C |
| Relative Humidity | 5–95% non-condensing |
| Dimensions (W × H × D) | 380 × 285 × 80 mm |
| Weight (kg) | 4.2 kg |
4. Product Applications
The PU516 operator terminal is used in industrial sectors where process transparency and reliable human-machine interaction are required.
Typical applications include:
• Centralized process control rooms.
• Power generation monitoring systems.
• Oil and gas production facilities.
• Chemical and petrochemical processing plants.
• Water and wastewater treatment systems.
• Mining and heavy industrial automation.
• Pharmaceutical and food manufacturing production lines.
• Distributed batch processing control systems.
The 15-inch display makes it especially suitable for operations requiring simultaneous visualization of multiple process screens, trend charts, and alarm summaries.
5. Product Advantages
Large High-Resolution Display
The 15-inch 1024 × 768 resolution screen enhances process clarity, enabling better situational awareness.
Industrial Touch Capability
Resistive touchscreen supports precise input even when operators wear gloves.
Reliable 24V DC Operation
Compatible with standard industrial power supplies, ensuring stable electrical integration.
Enhanced Memory Capacity
Improved memory and storage compared to earlier PU51x models allow smoother graphical performance.
Flexible Integration
Designed for seamless communication with control processors and distributed I/O modules.
Robust Industrial Construction
Durable housing supports long-term deployment in industrial environments.
Efficient Space Utilization
Panel or rack mounting allows adaptable installation in control cabinets.
Long Operational Lifecycle
Engineered for continuous operation in demanding process industries.
6. Recommended Models from the Same Series or Related Family
Below are five related models from the Advant OCS operator interface family.
| Model | Display Size | Resolution | Power Supply | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| PU514 | 10.4 inch | 640 × 480 | 24 V DC | 260 × 180 × 65 | 2.4 kg |
| PU514A | 10.4 inch | 800 × 600 | 24 V DC | 260 × 180 × 65 | 2.5 kg |
| PU515 | 12.1 inch | 800 × 600 | 24 V DC | 300 × 225 × 70 | 3.0 kg |
| PU516 | 15 inch | 1024 × 768 | 24 V DC | 380 × 285 × 80 | 4.2 kg |
| PU518 | 17 inch | 1280 × 1024 | 24 V DC | 430 × 350 × 90 | 5.8 kg |
7. Five Popular Automation Models from the Same Brand
Below are five widely used automation modules commonly deployed in industrial control systems.
| Model | Type | Power Supply | Dimensions (mm) | Weight (kg) | Application |
|---|---|---|---|---|---|
| AC800M | Modular Controller | 24 V DC | 140 × 180 × 120 | 1.2 kg | Distributed control CPU |
| PM856 | Processor Module | 24 V DC | 120 × 150 × 90 | 0.9 kg | Automation processor |
| CI870 | Communication Interface | 24 V DC | 120 × 150 × 90 | 0.8 kg | Field network communication |
| AI820 | Analog Input Module | 24 V DC | 120 × 150 × 80 | 0.6 kg | Signal acquisition |
| DI820 | Digital Input Module | 24 V DC | 120 × 150 × 80 | 0.6 kg | Discrete signal input |
8. Frequently Asked Questions (FAQ)
Q1: What is the main purpose of the PU516?
A: It functions as an operator interface terminal for monitoring and controlling industrial automation systems.
Q2: Which series does this model belong to?
A: It belongs to the Advant OCS distributed control interface family.
Q3: What is the screen size of the PU516?
A: The device features a 15-inch industrial display.
Q4: What resolution does the screen provide?
A: The resolution is 1024 × 768 pixels.
Q5: What power supply is required?
A: It operates on 24 V DC industrial power.
Q6: Is it suitable for continuous operation?
A: Yes, it is engineered for stable 24/7 industrial operation.
Q7: What is the approximate weight of the unit?
A: The unit weighs approximately 4.2 kg.
Q8: What mounting options are available?
A: It supports panel or rack mounting in control cabinets.
Q9: Can it integrate with controller modules and I/O units?
A: Yes, it is designed for integration within distributed control architectures.
Q10: What industries typically use this product?
A: Power, oil & gas, chemical processing, mining, manufacturing, and utilities.
