Product Overview
The ABB PM5675-2ETH (Part Number: 1SAP151500R0278) is a premium Processor Module from the ABB AC500 PLC platform. It is engineered for high-end industrial automation applications requiring exceptional processing performance, extensive memory capacity, and advanced communication capabilities.
The module features a powerful CPU with 160 MB program memory, an integrated 8 GB Flashdisk, dual Industrial Ethernet interfaces, serial communication, CAN bus connectivity, and an integrated LCD display. It is ideal for complex machine control, process automation, and large-scale distributed control systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | PM5675-2ETH |
| Part Number | 1SAP151500R0278 |
| Product Type | Processor Module |
| PLC Series | AC500 |
| Program Memory | 160 MB |
| Integrated Storage | 8 GB Flashdisk |
| User Memory (RAM) | Approximately 820,500 kB |
| Communication Interfaces | 2 × Industrial Ethernet |
| Serial Communication | RS232 / RS485 |
| Fieldbus | CAN |
| Display | Integrated LCD Display |
| Supply Voltage | 20.4–28.8 V DC |
| Rated Voltage | 24 V DC |
| Protection Rating | IP20 |
| Mounting Method | DIN Rail |
| Dimensions | 76 × 62 × 67.5 mm |
| Weight | 0.135 kg |
Function and Working Principle
The PM5675-2ETH serves as the central processing unit of an ABB AC500 PLC system. It continuously acquires field data, executes PLC programs at high speed, manages communication with industrial networks, and controls connected equipment in real time.
The integrated 8 GB Flashdisk provides additional storage for application data, recipes, logs, and firmware files, while the dual Ethernet interfaces support simultaneous communication with HMIs, SCADA systems, engineering workstations, and networked controllers.
Operating Sequence
- Field devices transmit input signals to the processor.
- The CPU scans and processes the incoming data.
- PLC logic and control algorithms are executed.
- Output commands are transmitted to field devices.
- Data is exchanged through Ethernet, serial, and CAN communication interfaces.
Key Features
- High-performance industrial processor
- 160 MB program memory
- Integrated 8 GB Flashdisk
- Approximately 820,500 kB user RAM
- Dual Industrial Ethernet interfaces
- RS232 / RS485 communication
- CAN fieldbus support
- Integrated LCD display
- Compact DIN rail installation
- Designed for complex automation systems
System Role
The PM5675-2ETH functions as the central controller within an ABB AC500 automation system, coordinating PLC execution, industrial communication, data storage, and system management.
Typical System Architecture
Sensors → PM5675-2ETH Processor Module → Ethernet / CAN Network → HMI / SCADA → Actuators
Industrial Applications
The PM5675-2ETH is widely used in:
- Factory automation
- Robotics
- Packaging machinery
- Material handling systems
- High-speed production lines
- Water and wastewater treatment
- Energy management systems
- Semiconductor manufacturing
- Process automation
- OEM machinery
Installation Guidelines
- Mount the processor securely on a DIN rail.
- Connect a regulated 24 V DC power supply.
- Wire field devices according to the application design.
- Configure Ethernet, RS232/RS485, and CAN communication parameters.
- Download the PLC application program before commissioning.
- Verify communication, diagnostics, and system operation before startup.
Compatible Components
The PM5675-2ETH is compatible with:
- ABB AC500 I/O Modules
- ABB Communication Modules
- ABB Human Machine Interfaces (HMI)
- SCADA Systems
- Industrial Ethernet Switches
- CAN Field Devices
- RS232 / RS485 Serial Devices
- ABB Automation Builder Software
Alternative Models
| Model | Description |
|---|---|
| PM5670-2ETH | Processor Module |
| PM5650-2ETH | Processor Module |
| PM5650-MC-KIT | Controller Kit |
| PM5670-MC-KIT | Controller Kit |
| PM5630-2ETH | Processor Module |
Advantages
- High-speed PLC execution
- Large 160 MB program memory
- Integrated 8 GB Flashdisk for data storage
- Dual Ethernet communication
- Flexible serial and CAN connectivity
- Integrated LCD display for diagnostics
- Compact and reliable DIN rail design
- Suitable for large-scale industrial automation
Frequently Asked Questions
What is the PM5675-2ETH used for?
It is used as the central Processor Module in ABB AC500 PLC systems for advanced industrial automation, machine control, and process applications.
How much memory does the module provide?
The processor includes 160 MB program memory, approximately 820,500 kB user RAM, and an integrated 8 GB Flashdisk.
Which communication interfaces are available?
The module supports dual Industrial Ethernet, RS232/RS485, and CAN communication.
Does the processor include onboard storage?
Yes. It features an integrated 8 GB Flashdisk for application files, data logging, and firmware storage.
How is the module installed?
The PM5675-2ETH is designed for DIN rail mounting and operates from a 24 V DC power supply.
Conclusion
The ABB PM5675-2ETH (1SAP151500R0278) Processor Module is one of the most advanced controllers in the ABB AC500 PLC family. Featuring 160 MB program memory, an integrated 8 GB Flashdisk, approximately 820,500 kB user RAM, dual Industrial Ethernet, RS232/RS485, CAN communication, and an integrated LCD display, it provides outstanding processing power, data storage capability, and communication flexibility for demanding industrial automation and machine control applications.
