Product Overview
The ABB PM5630-2ETH (Part Number: 3ABD00038893) is a high-performance Processor Module from the ABB AC500 PLC series. It integrates a powerful CPU, 8 MB memory, dual Industrial Ethernet interfaces, RS232/RS485 serial communication, CAN communication, and an integrated display into a compact controller designed for advanced industrial automation.
The module delivers high-speed PLC processing, reliable industrial networking, and flexible communication capabilities, making it suitable for machine automation, process control, and distributed control systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | PM5630-2ETH |
| Part Number | 3ABD00038893 |
| Product Type | Processor Module |
| PLC Series | AC500 |
| Program Memory | 8 MB |
| Communication Interfaces | 2 × Industrial Ethernet |
| Serial Interface | RS232/RS485 |
| Fieldbus Interface | CAN |
| Display | Integrated Display |
| Supply Voltage | 20.4–28.8 V DC |
| Rated Voltage | 24 V DC |
| Protection Rating | IP20 |
| Mounting Method | DIN Rail |
| Dimensions | 76 × 62 × 67.5 mm |
| Weight | 0.134 kg |
Function and Working Principle
The PM5630-2ETH serves as the central processing unit of an ABB AC500 PLC system. It continuously scans field inputs, executes PLC application programs, and controls connected devices according to user-defined logic.
Its dual Ethernet interfaces provide high-speed communication with HMIs, SCADA systems, engineering workstations, and industrial networks, while the RS232/RS485 and CAN interfaces enable communication with serial devices and fieldbus equipment. The integrated display simplifies diagnostics, monitoring, and maintenance.
Operating Sequence
- Field devices transmit input signals to the processor.
- The CPU scans and processes all input data.
- PLC application logic is executed in real time.
- Output commands are transmitted to connected equipment.
- Process data is exchanged through Ethernet, serial, or CAN communication interfaces.
Key Features
- High-performance embedded processor
- 8 MB program memory
- Dual Industrial Ethernet interfaces
- Integrated RS232/RS485 communication
- Built-in CAN interface
- Integrated diagnostic display
- High-speed real-time PLC execution
- Compact DIN rail installation
- Reliable industrial-grade performance
System Role
The PM5630-2ETH functions as the central controller within an ABB AC500 automation system, coordinating control logic, industrial communication, and process monitoring.
Typical System Architecture
Sensors → PM5630-2ETH Processor Module → Ethernet / Serial / CAN Network → HMI / SCADA → Actuators
Industrial Applications
The PM5630-2ETH is widely used in:
- Factory automation
- Machine control
- Packaging machinery
- Material handling systems
- Conveyor automation
- Water and wastewater treatment
- Energy management systems
- Building automation
- General industrial manufacturing
Installation Guidelines
- Install the processor on a standard DIN rail.
- Connect a regulated 24 V DC power supply.
- Wire field devices according to the application requirements.
- Configure Ethernet, serial, and CAN communication parameters.
- Download the PLC application program before commissioning.
- Verify communication and I/O operation before placing the system into service.
Compatible Components
The PM5630-2ETH is compatible with:
- ABB AC500 I/O Modules
- ABB Communication Modules
- ABB Human Machine Interfaces (HMI)
- SCADA Systems
- Industrial Ethernet Switches
- CAN Field Devices
- Serial Communication Devices
- ABB Automation Builder Software
Alternative Models
| Model | Description |
|---|---|
| PM5620-2ETH | Processor Module |
| PM5640-2ETH | High-Performance Processor Module |
| PM5650-2ETH | Advanced Processor Module |
| PM5082-T-2ETH | Processor Module |
| PM5072-T-2ETH | Processor Module |
Advantages
- High-speed PLC processing
- 8 MB program memory
- Dual Ethernet communication
- Integrated RS232/RS485 and CAN interfaces
- Built-in display for diagnostics
- Compact DIN rail design
- Reliable industrial operation
- Flexible communication options
- Easy programming and maintenance
Frequently Asked Questions
What is the PM5630-2ETH used for?
It is used as the central Processor Module in ABB AC500 PLC systems for industrial automation, machine control, and process management.
How much memory does the processor provide?
The module includes 8 MB of program memory.
Which communication interfaces are available?
It provides dual Industrial Ethernet, RS232/RS485, and CAN communication interfaces.
Does the processor include a display?
Yes. The PM5630-2ETH features an integrated display for diagnostics, monitoring, and system status indication.
What is the supply voltage?
The processor operates with a 20.4–28.8 V DC supply and has a 24 V DC rated voltage.
Conclusion
The ABB PM5630-2ETH (3ABD00038893) Processor Module is a compact and powerful controller for the ABB AC500 PLC platform. Featuring 8 MB program memory, dual Industrial Ethernet interfaces, RS232/RS485, CAN communication, an integrated display, and a compact DIN rail design, it provides reliable real-time control, flexible communication, and efficient performance for a wide range of industrial automation and process control applications.
