Product Overview
The ABB PM5032-R-ETH (Part Number: 1SAP123500R0072) is a high-performance Processor Module from the ABB AC500-eCo PLC family. It combines a powerful CPU, integrated digital I/O, and Industrial Ethernet connectivity into a compact controller, making it suitable for machine automation, process control, and industrial networking applications.
Designed for reliable real-time operation, the PM5032-R-ETH executes PLC programs, manages local and expansion I/O, and communicates with HMIs, SCADA systems, and other automation devices through its built-in Ethernet interface.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | PM5032-R-ETH |
| Part Number | 1SAP123500R0072 |
| Product Type | Processor Module |
| PLC Series | AC500-eCo |
| Program Memory | 2 MB |
| Digital Inputs | 12 × 24 V DC |
| Digital Outputs | 6 × Relay Outputs |
| Configurable I/O | 2 × 24 V DC Configurable I/O |
| Communication Interface | 1 × Industrial Ethernet |
| Expansion Slots | 2 Option Slots |
| Supply Voltage | 20.4–28.8 V DC |
| Protection Rating | IP20 |
| Mounting Method | DIN Rail |
| Dimensions | 135 × 74 × 82 mm |
| Weight | 0.268 kg |
Function and Working Principle
The PM5032-R-ETH serves as the central controller in an ABB AC500-eCo automation system. It continuously scans digital input signals, executes the user application program, and updates output devices according to the programmed control logic.
The integrated Ethernet interface enables communication with engineering software, HMIs, SCADA systems, and industrial networks, while the expansion slots allow additional functionality through optional communication or application modules.
Operating Sequence
- Digital input devices send signals to the processor.
- The CPU scans and processes all input data.
- PLC logic is executed in real time.
- Relay outputs and configurable outputs are updated.
- Process data is exchanged with supervisory systems via Ethernet.
Key Features
- High-performance embedded processor
- 2 MB program memory
- 12 integrated digital inputs (24 V DC)
- 6 integrated relay outputs
- 2 configurable 24 V DC I/O channels
- Built-in Industrial Ethernet communication
- Two expansion option slots
- Compact DIN rail installation
- Reliable real-time PLC performance
System Role
The PM5032-R-ETH functions as the central processing controller of an ABB AC500-eCo automation system, integrating control, communication, and local I/O into one compact module.
Typical System Architecture
Sensors → PM5032-R-ETH Processor Module → Ethernet Network → HMI / SCADA → Actuators
Industrial Applications
The PM5032-R-ETH is widely used in:
- Factory automation
- Machine control
- Packaging machinery
- Conveyor systems
- Material handling equipment
- Water and wastewater treatment
- Building automation
- Food and beverage processing
- General industrial manufacturing
Installation Guidelines
- Mount the processor on a standard DIN rail.
- Supply the module with a regulated 24 V DC power source.
- Connect field devices according to the wiring diagram.
- Connect the Ethernet interface for programming and network communication.
- Install optional expansion modules if additional functionality is required.
- Verify system configuration before commissioning.
Compatible Components
The PM5032-R-ETH is compatible with:
- ABB AC500-eCo Expansion I/O Modules
- ABB Communication Modules
- ABB Human Machine Interfaces (HMI)
- SCADA Systems
- Industrial Ethernet Switches
- ABB Automation Builder Software
- Remote I/O Devices
Alternative Models
| Model | Description |
|---|---|
| PM5012-T-ETH | Processor Module with Transistor Outputs |
| PM5012-R-ETH | Processor Module with Relay Outputs |
| PM5032-MC-KIT | Motion Controller Kit |
| PM5052-T-ETH | High-Performance Processor Module |
| PM564-T-ETH | Advanced PLC Processor Module |
Advantages
- High-speed real-time processing
- Integrated Ethernet communication
- Large 2 MB program memory
- Built-in digital inputs and relay outputs
- Flexible expansion through option slots
- Compact DIN rail installation
- Reliable industrial-grade operation
- Easy maintenance and programming
Frequently Asked Questions
What is the PM5032-R-ETH used for?
It is used as the central Processor Module for ABB AC500-eCo PLC systems, providing real-time control, communication, and integrated digital I/O.
How much program memory does it have?
The module includes 2 MB of program memory.
What onboard I/O does it provide?
It includes 12 digital inputs (24 V DC), 6 relay digital outputs, and 2 configurable 24 V DC I/O channels.
Does it support Ethernet communication?
Yes. It features an integrated Industrial Ethernet interface for communication with HMIs, SCADA systems, and engineering software.
Can the system be expanded?
Yes. The processor includes two option slots for additional communication or application modules.
Conclusion
The ABB PM5032-R-ETH (1SAP123500R0072) Processor Module is a compact and powerful controller for the AC500-eCo PLC platform. Featuring a 2 MB memory, 12 digital inputs, 6 relay outputs, 2 configurable I/O channels, integrated Industrial Ethernet, and two expansion slots, it provides a reliable and flexible solution for modern industrial automation, machine control, and process applications.
