Product Overview: ABB EI813F (3BDH000022R1)
Product Introduction
The ABB EI813F (3BDH000022R1) is a digital input module specifically designed for use within industrial automation systems, particularly in process control and safety instrumented systems. This module is engineered to provide highly reliable and safe digital input signals, which are essential for accurate and timely monitoring of industrial processes.
Designed with a focus on high integrity and safety, the EI813F supports robust signal processing with advanced diagnostics, making it suitable for critical applications that require precise input detection and fault tolerance. Its modular design allows for easy integration into control cabinets, optimizing space and installation time.
Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | 3BDH000022R1 (EI813F) |
| Type | Digital Input Module |
| Number of Channels | 16 |
| Input Voltage | 24 V DC nominal (19.2 – 32 V DC) |
| Input Type | Digital, 2-wire current loop inputs |
| Input Current | Approximately 6 mA per channel |
| Diagnostics | Line monitoring, short/open detection |
| High Integrity Level | SIL3 certified according to IEC 61508 |
| Dimensions (mm) | 45 (W) x 119 (H) x 102 (D) |
| Weight (kg) | 0.18 |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Mounting | DIN rail or panel mount |
| Protection Rating | IP20 |
| Compliance | CE, UL, IEC 61131-2 |
Product Applications
-
Process Automation: Monitoring input signals in chemical, petrochemical, and pharmaceutical industries for safe operation.
-
Safety Instrumented Systems (SIS): Reliable detection of digital signals critical for safety functions.
-
Factory Automation: Input processing for machinery control and automation lines.
-
Energy Sector: Monitoring digital inputs in power plants and grid automation.
-
Building Management Systems: Collecting digital status signals from various control points.
Product Advantages
-
High Safety Integrity: SIL3 certification ensures the module meets the highest safety standards for critical process control.
-
Advanced Diagnostics: Enables quick fault detection including line breaks and short circuits, minimizing downtime.
-
Robust Design: Suitable for harsh industrial environments with temperature and vibration resilience.
-
Modular and Compact: Space-saving design with easy installation and replacement.
-
Wide Compatibility: Compatible with a range of automation controllers and systems.
-
Reliable Signal Processing: Minimizes false signals and ensures accurate status monitoring.
-
Comprehensive Testing: Subject to rigorous quality and safety testing for dependable operation.
Brand Information
| Brand Name | ABB |
|---|---|
| Overview | A global leader in electrification and automation technology |
| Industry | Industrial automation, power systems, robotics |
| Global Reach | Worldwide presence with extensive technical support |
Product Series
| Series Name | EI Series (Digital Input Modules) |
|---|---|
| Overview | High integrity digital input modules for safety-critical automation systems |
| Key Features | SIL3 certified, advanced diagnostics, 16 channels, compact design |
| Typical Applications | Safety instrumented systems, process automation, industrial controls |
Recommended Models From the Same Series or Related
| Model | Number of Channels | Input Type | Dimensions (mm) | Weight (kg) | Safety Level |
|---|---|---|---|---|---|
| EI813E (3BDH000021R1) | 16 | Digital, 2-wire current loop | 45 x 119 x 102 | 0.18 | SIL3 |
| EI813G (3BDH000023R1) | 16 | Digital, 2-wire current loop | 45 x 119 x 102 | 0.18 | SIL3 |
| EI815F (3BDH000026R1) | 32 | Digital, 2-wire current loop | 90 x 119 x 102 | 0.36 | SIL3 |
| EI810B (3BDH000018R1) | 8 | Digital, 2-wire current loop | 45 x 60 x 102 | 0.10 | SIL2 |
| EI817F (3BDH000028R1) | 64 | Digital, 2-wire current loop | 180 x 119 x 102 | 0.70 | SIL3 |
Recommended Popular Models From the Same Brand
| Model | Type | Number of Channels | Dimensions (mm) | Weight (kg) | Application Focus |
|---|---|---|---|---|---|
| AI870 (3BSE013547R1) | Analog Input Module | 8 | 45 x 119 x 102 | 0.25 | High precision analog signals |
| CI867 (3BSE043660R1) | Communication Interface | – | 140 x 110 x 45 | 0.38 | Network connectivity |
| DO880 (3BSE028603R1) | Digital Output Module | 16 | 45 x 119 x 102 | 0.20 | High integrity digital outputs |
| AI871 (3BSE013548R1) | Analog Input Module | 16 | 90 x 119 x 102 | 0.35 | Process analog measurement |
| EI810 (3BSE028598R1) | Digital Input Module | 8 | 45 x 60 x 102 | 0.10 | Digital signal input |
FAQ (Frequently Asked Questions)
Q1: What type of inputs does the EI813F module accept?
A1: The EI813F accepts 2-wire current loop digital inputs at 24 V DC nominal.
Q2: How many channels does the EI813F have?
A2: It provides 16 digital input channels.
Q3: What safety certification does this product have?
A3: It is certified for SIL3 according to IEC 61508, suitable for safety instrumented systems.
Q4: What are the physical dimensions and weight of the EI813F?
A4: Dimensions are 45 mm (W) x 119 mm (H) x 102 mm (D), and it weighs about 0.18 kg.
Q5: Can the module be mounted on a DIN rail?
A5: Yes, it supports both DIN rail and panel mounting.
Q6: What diagnostics are available on this module?
A6: It offers line monitoring with short and open detection to ensure signal integrity.
Q7: What is the operating temperature range?
A7: The module operates reliably between 0°C and +55°C.
Q8: Is the EI813F compatible with standard industrial controllers?
A8: Yes, it is compatible with most common automation controllers and systems.
Q9: How does this module improve system safety?
A9: Through its SIL3 certification and advanced diagnostics, it ensures high reliability in critical control systems.
Q10: What is the typical application environment for the EI813F?
A10: It is used in process automation, safety systems, and industrial control environments requiring high safety integrity.
