ABB DSAO 130A (3BSE018294R1) Product Overview

Product Introduction

The ABB DSAO 130A (3BSE018294R1) is a high-performance analog output module designed for industrial automation systems that require precise control and real-time signal transmission. As part of the DSAO Series, this module provides 16 analog output channels, offering exceptional flexibility and versatility for a variety of industrial applications. It is engineered to provide output signals in both voltage (0-10 V) and current (4-20 mA), allowing seamless integration with a wide range of field devices and control systems.

The DSAO 130A module excels in applications where signal precision and reliable data communication are critical. It is designed for use in machine control, process automation, and energy management systems, providing crucial output signals to control devices like actuators, motors, valves, and other industrial machinery. Its DIN rail mounting feature ensures it can be easily installed in standard industrial control panels, making it suitable for both compact and large-scale installations.

Product Parameters

Product Applications

The ABB DSAO 130A is ideal for various industrial applications requiring precise control and signal conversion. These include:

• Industrial Automation: The module provides analog outputs to control actuators, valves, and motors in automated systems, ensuring accurate movement and function.

• Process Control: It is extensively used in industries like chemical, oil & gas, and pharmaceuticals to control process variables with high accuracy.

• Machine Control: The module is used to control industrial machinery, offering real-time signal output to adjust operations in machine control systems.

• Energy Management: The DSAO 130A provides output signals to energy management devices, such as smart meters and power regulators, ensuring efficient energy consumption in industrial facilities.

• Building Automation: It is also applied in building management systems to control systems like HVAC and lighting through analog signal outputs.

Product Advantages

• High Precision Output: The DSAO 130A module supports 16 analog outputs, offering configurable voltage and current outputs for flexibility and adaptability in different applications.

• Real-Time Data Transfer: It supports 100 Mbps data transfer rate, ensuring that real-time communication with the control system is maintained.

• Compact Design: With DIN rail mounting, the DSAO 130A can be easily installed in control panels and is ideal for systems with limited space.

• Wide Operating Range: The module operates in temperatures ranging from -20°C to +60°C, making it suitable for both indoor and outdoor industrial installations.

• Low Power Consumption: It operates on a 24 V DC ± 20% power supply, contributing to energy efficiency while ensuring superior performance.

• Durable and Reliable: The IP20 protection rating ensures that the module is protected against dust and dirt, making it robust and long-lasting.

• Diagnostic LED Indicators: The built-in LED indicators for Power, Status, and Link make it easy to monitor and diagnose the system’s health.

Brand and Series

• Brand: ABB

• Series: DSAO Series

The DSAO Series is a range of analog output modules designed to provide reliable and precise signal output for various industrial systems. The DSAO 130A is part of this series, offering high flexibility, reliability, and performance for applications such as machine control, process automation, and energy management. The modules in the DSAO Series are known for their ability to support multiple signal outputs, fast data transfer, and integration with a wide range of industrial devices.

Related and Recommended Models

Here are five related models from the DSAO Series and five other popular ABB models:
