Product Technical Documentation – ABB CP430B (1SBP260183R1001)
1) Brand and Series Overview
Brand: ABB
Series: CP4xx Operator Interface Terminals
The CP4xx series is designed for compact and reliable operator interaction in industrial automation systems. These terminals are widely used in machine control panels, production lines, and process automation environments.
The CP430B belongs to the mid-range category of the CP4xx family. It offers a larger monochrome display and extended keypad compared to entry-level models, making it suitable for applications that require better visualization and more operator input flexibility while maintaining a compact installation footprint.
2) Product Overview
The ABB CP430B (1SBP260183R1001) is a monochrome operator interface terminal developed for panel-mounted industrial use. It provides operators with the ability to monitor machine status, adjust parameters, acknowledge alarms, and navigate system menus.
The terminal combines a graphical LCD screen with an expanded function keypad. Its rugged construction and front IP65 protection make it suitable for harsh industrial environments such as manufacturing plants, assembly lines, and packaging systems.
The CP430B is intended for systems where clear status visualization and reliable manual input are required without the need for a full-color touchscreen HMI.
3) Technical Parameters
| Parameter | Specification |
|---|---|
| Model | CP430B (1SBP260183R1001) |
| Product Type | Operator Interface Terminal – Monochrome |
| Series | CP4xx Control Products |
| Display Type | Monochrome Graphic LCD |
| Display Size | Approx. 5.7 in diagonal |
| Resolution | 320 × 240 pixels |
| Keypad | 20 Function Keys + Navigation Keys |
| Backlight | LED Backlight |
| Communication | Serial / Fieldbus Compatible |
| Supply Voltage | 24 V DC |
| Power Consumption | ≤ 8 W |
| Mounting | Panel Mount |
| Protection Rating | IP65 Front (panel mounted) |
| Operating Temperature | −10 °C to +55 °C |
| Storage Temperature | −20 °C to +70 °C |
| Relative Humidity | 10–90 % non-condensing |
| Dimensions (H × W × D) | 120 × 190 × 45 mm |
| Cut-out Size | 112 × 182 mm |
| Weight (kg) | 0.41 kg |
| Housing Material | Industrial-grade reinforced polymer |
4) Product Description
The CP430B is designed to serve as a reliable operator interface for PLC-controlled machinery. It displays real-time production data, machine states, alarm conditions, and process parameters.
The graphical LCD allows structured menu layouts, numeric displays, and status indicators. The integrated keypad provides tactile feedback and dedicated function keys for faster operation in industrial settings where gloves may be worn.
The device is engineered for continuous operation and stable communication with automation controllers. Its panel-mount design ensures secure installation and easy integration into new or existing control cabinets.
5) Product Advantages
• Larger Display Area – Improved data visualization compared to smaller CP4xx models.
• Extended Keypad Layout – More function keys enhance operator efficiency.
• Rugged Construction – Designed for vibration, dust, and industrial conditions.
• IP65 Front Protection – Suitable for exposed control panel environments.
• LED Backlighting – Ensures readability under various lighting conditions.
• Low Energy Consumption – Efficient for continuous industrial operation.
• Flexible Integration – Compatible with common PLC communication interfaces.
• Compact Panel Design – Maintains manageable installation dimensions.
6) Typical Applications
• Operator control panels for packaging machinery
• Assembly line monitoring stations
• Production equipment parameter adjustment
• Alarm acknowledgment systems
• Industrial batching control interface
• Material handling systems visualization
• Machine diagnostics and maintenance interface
• Compact automation cells
7) Five Related Models (Same Series or Closely Related)
| Model | Display Type | Dimensions (mm) | Weight (kg) |
|---|---|---|---|
| CP410M | Monochrome LCD | 84 × 138 × 35 | 0.25 |
| CP415M | Monochrome LCD | 100 × 160 × 40 | 0.35 |
| CP420B | Monochrome LCD | 110 × 170 × 42 | 0.38 |
| CP430T | Monochrome LCD | 120 × 190 × 45 | 0.42 |
| CP450M | Extended Key Monochrome | 120 × 180 × 45 | 0.35 |
8) Five Popular ABB Industrial Models
| Model | Product Type | Rated Power / Current | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| ACS580-01-07A6-4 | Variable Frequency Drive | 7.5 kW | 358 × 152 × 203 | 5.8 |
| ACS880-01-022A-4 | High Performance Drive | 22 kW | 400 × 220 × 210 | 8.0 |
| Emax 2 E2.2 | Air Circuit Breaker | 1600 A | 371 × 210 × 268 | 8.2 |
| Tmax XT4N | Molded Case Circuit Breaker | 250 A | 140 × 105 × 160 | 2.1 |
| AF16-30-10 | Contactor | 16 A | 90 × 55 × 78 | 0.42 |
9) Frequently Asked Questions (FAQ)
Q1: What is the CP430B mainly used for?
A1: It is used as a panel-mounted operator interface for machine monitoring and control.
Q2: What type of display does it use?
A2: A monochrome graphical LCD with LED backlight.
Q3: What is the required power supply?
A3: 24 V DC.
Q4: What are the physical dimensions?
A4: 120 × 190 × 45 mm.
Q5: What is the weight of the unit?
A5: Approximately 0.41 kg.
Q6: Is it suitable for harsh industrial environments?
A6: Yes, the front panel is rated IP65 for dust and moisture protection.
Q7: How many function keys are included?
A7: It includes 20 function keys plus navigation controls.
Q8: Can it display alarms and system messages?
A8: Yes, it supports alarm visualization and system diagnostics.
Q9: What communication interfaces are supported?
A9: Serial and compatible fieldbus communication for PLC integration.
Q10: What makes CP430B different from smaller CP4xx models?
A10: It offers a larger display, more keys, and improved operator usability while keeping a compact footprint.
