1. Product Overview

The ABB AI581-S/AI581-S-XC (Part Number: 1SAP282000R0001) is a high-performance analog input module designed for industrial automation systems. This module is part of ABB’s S800 I/O system and is used for acquiring voltage and current signals from external sensors and devices, converting these analog signals into digital data for processing by control systems.

The AI581-S is a flexible and robust solution for measuring and monitoring analog inputs in environments requiring high accuracy and reliability. It supports a wide range of applications, including process control, machinery monitoring, and building automation. With its easy integration into ABB’s automation systems, this product ensures precise and real-time data acquisition, essential for efficient and accurate control.

The AI581-S-XC variant offers enhanced features with extended capabilities and certifications for specific industrial requirements.

2. Product Specifications

3. Product Description

The ABB AI581-S is an advanced analog input module designed for high-performance data acquisition in industrial automation systems. It supports up to 16 input channels, capable of processing both voltage signals (0–10 V) and current signals (4–20 mA), with 16-bit resolution for accurate data conversion. With a sampling rate of 250 Hz per channel, this module ensures real-time data collection from various industrial sensors, such as temperature sensors, pressure transmitters, and flow meters.

The AI581-S integrates seamlessly into ABB’s automation systems and is particularly well-suited for process control, machine control, and environmental monitoring. It features Modbus TCP and Ethernet/IP communication protocols, allowing easy integration with SCADA systems and other networked automation equipment.

The AI581-S-XC model offers additional features and extended certifications for use in specific applications where greater environmental resilience or safety compliance is required.

Key Features:

• Multiple Input Types: The AI581-S supports voltage (0–10 V) and current (4–20 mA) inputs, making it versatile for a wide range of sensor applications.

• High Precision: With 16-bit resolution, the AI581-S ensures accurate signal conversion, providing reliable data for industrial control systems.

• Real-Time Data Acquisition: The 250 Hz sampling rate enables fast, real-time data collection, critical for many industrial applications.

• Wide Operating Range: It operates in environments with temperatures ranging from -25°C to +70°C, making it suitable for a wide range of industrial conditions.

• Easy Integration: The module supports Modbus TCP and Ethernet/IP communication protocols, facilitating seamless integration into existing automation networks.

• Durable Design: The DIN rail mounting and IP20 protection make the AI581-S durable and easy to install in control cabinets.

4. Product Applications

The ABB AI581-S is used in a variety of industrial applications where accurate and reliable analog signal acquisition is needed. Some of the common uses include:

• Process Control: Used for acquiring signals from temperature, pressure, and flow sensors to monitor and control industrial processes in manufacturing plants, chemical processes, and other industries.

• Machine Control: In machine automation, the AI581-S can monitor inputs from devices such as motors, pumps, and actuators, ensuring optimal performance and efficiency.

• Building Automation: In HVAC systems, lighting control, and energy management, the AI581-S is used to collect data from environmental sensors, ensuring efficient building operation.

• Environmental Monitoring: It is used to monitor environmental parameters such as air quality, humidity, and pollution levels, particularly in industrial or outdoor environments.

• Test and Measurement Systems: The AI581-S is ideal for laboratory equipment, test benches, and calibration systems that require precise analog data acquisition.

5. Product Advantages

The ABB AI581-S offers several key advantages:

• High Precision and Accuracy: With 16-bit resolution and a sampling rate of 250 Hz, the AI581-S ensures high-precision data acquisition and real-time monitoring of industrial processes.

• Wide Input Compatibility: It supports both voltage and current inputs, making it flexible enough for various sensor applications.

• Easy Integration: The support for Modbus TCP and Ethernet/IP makes it easy to integrate the AI581-S with existing control systems, providing seamless data communication.

• Compact and Durable: The AI581-S has a DIN rail mounting design for space-saving installation, with a wide operating temperature range of -25°C to +70°C, ensuring reliability in harsh industrial environments.

• Enhanced Certification (AI581-S-XC): The AI581-S-XC version offers extended certifications, making it ideal for use in specialized applications that require additional environmental or safety compliance.

6. Brand and Product Series

The AI581-S is part of ABB’s S800 I/O System, a comprehensive range of input/output modules designed for industrial automation. These modules are known for their reliable performance, flexibility, and scalability, making them ideal for various control applications in industries such as process control, manufacturing, building automation, and energy management.
