Product Overview: ABB AF D242 A10 (3BHE023126R0010)
Product Description
The ABB AF D242 A10 (3BHE023126R0010) is a high-performance contactor designed for demanding industrial environments, offering advanced features like electronically controlled coils for optimal energy efficiency and operation across wide voltage ranges. With precise control, robust build, and compact design, this model ensures maximum uptime and performance in electrical distribution and motor control systems.
This contactor is ideal for applications requiring frequent switching of motors, resistive loads, and capacitive circuits. Its integration capability with automation systems and compliance with international standards makes it a preferred choice for industrial automation and power management systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | AF D242 A10 |
| Product Code | 3BHE023126R0010 |
| Rated Operational Voltage (Ue) | 1000 V AC |
| Control Voltage | 100-250 V AC/DC |
| Rated Control Circuit Voltage (Uc) | 100 … 250 V AC/DC |
| Rated Current (AC-3) | 250 A |
| Auxiliary Contacts | 1 NO + 1 NC |
| Mounting Type | DIN rail or screw mounting |
| Dimensions (H × W × D) | 165 mm × 120 mm × 145 mm |
| Weight | 2.4 kg |
| Electrical Durability | 1 million operations |
| Mechanical Durability | 10 million operations |
| Standards Compliance | IEC 60947-4-1, UL, CSA |
| Operating Temperature Range | -25°C to +60°C |
| Coil Consumption (Pick-up) | Approx. 5.5 W |
| Shock & Vibration Resistance | High resistance, suitable for rugged use |
Applications
-
Industrial motor control systems
-
HVAC systems
-
Pump control stations
-
Power distribution panels
-
Automation and control panels
-
Conveyor and material handling systems
-
Renewable energy systems (solar, wind)
-
Smart grid and energy management solutions
Key Advantages
-
Wide Control Voltage Range: Operates seamlessly on a broad voltage spectrum, reducing the need for coil variations.
-
Reduced Power Consumption: Electronic coil technology significantly lowers energy usage during operation.
-
Compact Design: Saves space in control panels while delivering high performance.
-
Robust Mechanical Design: High endurance ensures long life even in harsh environments.
-
Flexible Mounting Options: Suitable for various panel configurations.
Brand Information
-
Brand: ABB
-
Series: AF Series (Advanced Contactors with Electronic Coil Interface)
-
Product Line: Industrial Contactors
Related Models in the Same or Similar Series
| Model | Rated Current (AC-3) | Control Voltage | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| AF D210 A10 | 210 A | 100-250 V AC/DC | 160 × 110 × 140 | 2.2 |
| AF D185 A10 | 185 A | 100-250 V AC/DC | 155 × 105 × 135 | 2.1 |
| AF D265 A10 | 265 A | 100-250 V AC/DC | 170 × 125 × 150 | 2.5 |
| AF D300 A10 | 300 A | 100-250 V AC/DC | 180 × 130 × 155 | 2.8 |
| AF D205 A10 | 205 A | 100-250 V AC/DC | 158 × 108 × 138 | 2.3 |
Top 5 Popular Models from the Same Brand
| Model | Rated Current (AC-3) | Control Voltage | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| AF09-30-10 | 9 A | 24 V AC/DC | 85 × 45 × 92 | 0.3 |
| AF16-30-00 | 16 A | 100-250 V AC/DC | 86 × 45 × 96 | 0.4 |
| AF26-30-00 | 26 A | 100-250 V AC/DC | 90 × 55 × 100 | 0.6 |
| AF38-30-10 | 38 A | 100-250 V AC/DC | 98 × 60 × 105 | 0.7 |
| AF75-30-00 | 75 A | 100-250 V AC/DC | 125 × 75 × 120 | 1.2 |
FAQ – Frequently Asked Questions
Q1: What is the control voltage range of the AF D242 A10?
A1: The control voltage range is 100 to 250 V AC/DC, which makes it highly versatile across different systems.
Q2: Is the AF D242 A10 suitable for motor control applications?
A2: Yes, it is designed specifically for high-performance motor control under heavy load conditions.
Q3: Can this contactor be used in extreme temperature environments?
A3: Yes, it operates reliably in temperatures ranging from -25°C to +60°C.
Q4: What makes the AF series different from traditional contactors?
A4: The AF series features electronic coil control that reduces energy consumption and improves voltage tolerance.
Q5: Does this product meet international standards?
A5: Yes, it complies with IEC 60947-4-1 and has certifications for UL and CSA.
Q6: How many auxiliary contacts are included?
A6: It comes with one normally open (NO) and one normally closed (NC) auxiliary contact.
Q7: Is it easy to install the AF D242 A10?
A7: Yes, it supports both DIN rail and screw mounting for flexible installation.
Q8: What is the product’s mechanical lifespan?
A8: It has a mechanical durability of approximately 10 million operations.
Q9: How does the product perform in terms of noise and vibration?
A9: It is designed to resist shocks and vibrations, making it ideal for industrial settings.
Q10: Is it compatible with automation systems like PLCs?
A10: Absolutely. Its electronic coil and auxiliary options make it compatible with most PLC systems and smart automation.
