- ABB
- 5SHY3545L0009
- IGCT Control Panel Module
- Sweden
- 233 mm x 115 mm x 35 mm
- 1.5kg
- 3BHB013085R0001
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 69
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| sales@plc-automations.com | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
📘 Product Overview
The 5SHY3545L0009 (3BHB013085R0001) is a high-performance IGBT gate driver unit widely used in industrial automation and high-power converter systems. Designed to meet the demanding standards of modern energy systems, this product combines robustness with precision. It ensures safe and reliable operation of power semiconductors in high-voltage applications. The module is an essential component in drive systems, facilitating optimal IGBT control and protection.
This specific driver is often found in medium voltage drives, traction systems, marine propulsion units, and heavy-duty industrial motors, enabling efficient switching and enhancing the lifespan of the entire system.
📊 Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 5SHY3545L0009 |
| Internal Code | 3BHB013085R0001 |
| Product Type | IGBT Gate Driver Unit |
| Application Voltage | Up to 4500 V |
| Gate Voltage | ±15 V typical |
| Control Supply Voltage | 15 V DC |
| Max Operating Temperature | -40°C to +85°C |
| Switching Frequency | Up to 2 kHz |
| Isolation Voltage | >10 kV |
| Communication Interface | Fiber-optic based |
| Dimensions (L x W x H) | 233 mm x 115 mm x 35 mm |
| Weight | 1.5 kg |
| Cooling Type | Natural air cooling / optional forced air |
| Mounting Style | Panel Mount |
| Compliance | CE, RoHS |
| Designed For | IGBT modules (e.g. 5SNA series) |
🛠️ Product Applications
-
Medium Voltage Drives
Enables precise and safe control of IGBT modules used in industrial motor drives. -
Railway Traction Systems
Ensures high-reliability operation in rolling stock power electronics. -
Renewable Energy Inverters
Supports large-scale solar and wind inverters requiring efficient gate control. -
Marine Propulsion Drives
Used in ship propulsion systems for reliable power switching. -
Industrial Automation
Supports factory systems, heavy-duty motors, and automation lines.
✅ Product Advantages
-
High Isolation Capability
Provides over 10 kV isolation, ensuring safety in high-voltage applications. -
Precision Control
Accurate gate voltage control ensures optimized IGBT switching behavior. -
Robust Construction
Built for durability in harsh industrial environments with wide temperature range. -
Easy Integration
Compact form factor and standardized interfaces allow easy system integration. -
Enhanced Safety Features
Includes desaturation protection, soft turn-off, and fault reporting mechanisms.
🏷️ Brand and Series
-
Brand: ABB
-
Series: IGBT Driver Series (often used with 5SNA series IGBTs)
-
Product Category: High-Voltage Gate Driver Units
🔁 Related Models (Same Series or Similar Function)
| Model | Gate Voltage | Application Voltage | Dimensions (mm) | Weight (kg) | Notes |
|---|---|---|---|---|---|
| 5SHY3545L0010 | ±15 V | Up to 4500 V | 233 x 115 x 35 | 1.5 | Upgraded version with diagnostics |
| 5SHY3545L0008 | ±15 V | Up to 3300 V | 210 x 110 x 35 | 1.3 | Compact form factor |
| 5SHX1060H0001 | ±15 V | Up to 4500 V | 250 x 120 x 40 | 1.8 | With integrated protection logic |
| 5SDF1045H0001 | ±15 V | 4500 V | 240 x 100 x 35 | 1.6 | Enhanced cooling model |
| 5STP33Q2800 | ±15 V | 2800 V | 190 x 90 x 30 | 1.2 | Compatible with older systems |
🔝 Popular Models (Same Brand – ABB)
| Model | Product Type | Voltage Rating | Dimensions (mm) | Weight (kg) | Notes |
|---|---|---|---|---|---|
| 5SNA1500E330305 | IGBT Module | 3300 V | 180 x 140 x 40 | 2.5 | High current IGBT module |
| 5SDF1060H0001 | IGBT Gate Driver | 4500 V | 250 x 110 x 40 | 1.7 | With fiber optic interface |
| 5SHY4045L0001 | Gate Driver | 4500 V | 220 x 115 x 35 | 1.4 | Older driver still in use |
| 5STP33Q2800 | Phase Control Thyristor | 2800 V | 190 x 90 x 30 | 1.2 | Thyristor for high power systems |
| 5SNA0805J650100 | IGBT Module | 6500 V | 200 x 150 x 50 | 3.2 | Ultra-high voltage application |
❓ FAQ (Q&A Format)
Q1: What is the primary function of the 5SHY3545L0009?
A1: It is an IGBT gate driver unit designed to control high-voltage IGBT modules in industrial power systems.
Q2: What kind of voltage isolation does this product offer?
A2: It provides isolation greater than 10 kV, which ensures safe operation in high-voltage environments.
Q3: Is the driver compatible with 5SNA series IGBT modules?
A3: Yes, it is specifically designed for compatibility with 5SNA IGBT modules.
Q4: What kind of environments is this product suitable for?
A4: It is suitable for industrial, railway, marine, and renewable energy environments.
Q5: Does it support fiber-optic communication?
A5: Yes, it uses fiber-optic input/output for safe and reliable signal transmission.
Q6: What cooling methods are supported?
A6: The unit supports natural air cooling, with optional forced air for higher heat dissipation.
Q7: How is the unit mounted?
A7: It is designed for panel mounting within control cabinets or enclosures.
Q8: What is the weight of the 5SHY3545L0009?
A8: The unit weighs approximately 1.5 kg.
Q9: Is this a standalone product or part of a system?
A9: It is part of a larger system, typically used with IGBT modules and power control systems.
Q10: What standards does the product comply with?
A10: It complies with CE and RoHS standards for safety and environmental compliance.
