Product Overview: AAI143‑H50 /A4S10
The AAI143‑H50 /A4S10 is a 16‑channel isolated analog input module for industrial DCS systems. It supports multiple signal types—including 4–20 mA, 1–5 V, and thermocouples—and offers integrated HART communication (“H”) for advanced device diagnostics. The /A4S10 suffix indicates a pressure-clamp terminal block with surge absorber for robust signal protection.
Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | AAI143‑H50 /A4S10 |
| Input Channels | 16, fully isolated |
| Supported Signals | 4–20 mA, 1–5 V, thermocouple |
| Accuracy | ± 0.1% of full scale |
| Input Resistance (ON) | 270 Ω at 20 mA to 350 Ω at 4 mA |
| Input Resistance (OFF) | ≥ 500 kΩ |
| Data Update Rate | ~10 ms per channel |
| Transmitter Supply Voltage | 19 V min (at 20 mA), ≤ 25.5 V (at 0 mA), 25 mA limit |
| Power Consumption | ~230 mA @ 5 V DC; ~540 mA @ 24 V DC |
| Withstand Voltage | 1,500 VAC (input to system, 1 min) |
| HART Communication | Enabled across all channels |
| Surge Absorber Terminal | Pressure clamp with built-in surge absorber (A4S10) |
| Operating Temp. Range | 0 °C to +60 °C |
| Weight | 0.30 kg |
| Dimensions (H × W × D) | 107.5 × 32.8 × 130 mm |
Applications
Designed for demanding industrial automation tasks, this module is ideal for petrochemical, power plant, water treatment, and factory control systems. Its HART integration allows for transmitter monitoring and calibration without additional wiring, while its surge protection ensures consistent signal reliability under electrical stress.
Key Advantages
-
Versatile Signal Support – Captures various sensor types in one platform.
-
High Accuracy – Maintains ± 0.1% precision for reliable control.
-
Fast Response – ~10 ms updates keep loops responsive.
-
Built-In HART Diagnostics – Access device health and calibration remotely.
-
Surge-Protected Signal Path – Pressure-clamp terminal blocks with absorber guard against spikes.
-
Robust Isolation – 1.5 kV withstand enhances safety and data integrity.
-
Compact & Lightweight – Easy to install in dense control racks.
Related Models (Same Series or Variants)
| Model | Description | Key Feature | Weight (kg) |
|---|---|---|---|
| AAI143‑H50 /A4S10 | Current model with surge protection | HART + surge-absorb anatomy | 0.30 |
| AAI143‑H50 /A4S00 | HART module with basic terminal block | No surge absorber | 0.30 |
| AAI143‑H50 /K4A00 | HART with KS cable adapter | Simplified wiring via KS interface | 0.30 |
| AAI143‑S50 /A4S10 | Non-HART with surge protection | Analog only, protected signal | 0.30 |
| AAI143‑H53 /A4S10 | HART + surge + wide temp rating | −20 °C to +70 °C capability | 0.30 |
Popular Yokogawa Modules (Same Brand)
| Model | Function | Common Usage | Weight (kg) |
|---|---|---|---|
| AAI143‑H50 /A4S10 | Protected analog input with HART | Core process monitoring | 0.30 |
| AAI543‑H50 /A4S00 | Protected analog output with HART | Driving analog field loops | ~0.40 |
| AAI141‑H50 /K4A00 | Non-isolated input with KS adapter | Entry-level HART input | ~0.30 |
| ADV151‑P50 | Digital output module | Control actuators and alarms | ~0.30 |
| PW482‑50 | Power module for I/O rack | Power supply for control cabinets | ~0.50 |
Frequently Asked Questions (FAQ)
Q1: What does the A4S10 option provide?
A1: It includes a terminal block with a built-in surge absorber for enhanced signal protection.
Q2: Is HART supported on all channels?
A2: Yes, integrated across all 16 channels.
Q3: What analog signal types are supported?
A3: Supports 4–20 mA, 1–5 V, and thermocouple inputs.
Q4: What accuracy does the module deliver?
A4: ± 0.1% of full scale for precise measurement.
Q5: How fast are the update intervals?
A5: Approximately 10 ms per channel.
Q6: What is the module’s isolation capability?
A6: Withstands 1,500 VAC between input and system for 1 minute.
Q7: What is the operating temperature range?
A7: Rated for 0 °C to +60 °C operation.
Q8: How heavy and how big is the module?
A8: Approximately 0.30 kg; dimensions are 107.5 × 32.8 × 130 mm.
Q9: What is the power requirement?
A9: Draws ~230 mA at 5 V DC or ~540 mA at 24 V DC.
Q10: Is the unit hot-swappable?
A10: Yes—it supports live replacement to minimize downtime.
