Product Overview: AAI143‑H03 S1
The AAI143‑H03 S1 is a precision analog input module designed for Distributed Control Systems (DCS). It provides 16 isolated 4–20 mA input channels with built-in HART communication. The “H03” suffix indicates the inclusion of HART protocol plus the ISA G3 and widened temperature range (−20 °C to +70 °C), while “S1” denotes the standard module variant. Compact and robust, it’s ideal for demanding industrial environments.
Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | AAI143‑H03 S1 |
| Input Channels | 16 (fully isolated) |
| Signal Type | 4–20 mA (standard analog) |
| Withstand Voltage | 1,500 VAC (input to system, 1 minute) |
| Input Resistance (ON) | 270 Ω (20 mA) to 350 Ω (4 mA) |
| Input Resistance (OFF) | ≥ 500 kΩ |
| Accuracy | ±16 µA |
| Data Update Period | ~10 ms per channel |
| Transmitter Supply Voltage | ≥ 19 V @ 20 mA; ≤ 25.5 V @ 0 mA (limit ~25 mA) |
| Wiring Configuration | Individual channels selectable for 2‑wire or 4‑wire transmitters |
| Ambient Temperature Drift | ±16 µA per 10 °C |
| Power Consumption | ~230 mA @ 5 V DC; ~540 mA @ 24 V DC |
| HART Communication | Full support on each channel |
| Operating Temperature Range | −20 °C to +70 °C (G3 option) |
| Protection Level | Standard industrial ruggedness |
| Weight (kg) | 0.30 kg |
| External Dimensions | Approx. 107.5 × 32.8 × 130 mm |
Applications
Used in industrial process control systems across petrochemical plants, power generation, water treatment, and manufacturing. It excels where accurate analog input, digital diagnostics via HART, and moderate environmental ruggedness are needed. The wide-temperature rating makes it suitable for installations in cabinets exposed to temperature fluctuations.
Key Advantages
-
High Channel Density – 16 isolated inputs in a compact module.
-
Built-In HART – Seamlessly enables digital diagnostics alongside analog data.
-
Enhanced Environmental Tolerance – Operates reliably over −20 °C to +70 °C.
-
Strong Signal Integrity – 1.5 kV isolation protects against electrical interference.
-
Fast Data Response – ~10 ms update ensures current process visibility.
-
Wiring Flexibility – Mix 2‑wire and 4‑wire transmitter types across channels.
-
Industry-Proven Form Factor – Fits standard I/O racks with minimal space.
Related Models (Same Series or Similar)
| Model | Description | Highlight Feature | Weight (kg) |
|---|---|---|---|
| AAI143‑H03 S1 | HART-enabled input with G3 wide-temp rating | Current model with −20 °C to +70 °C | 0.30 |
| AAI143‑H00 S1 | HART-enabled input, standard temperature | Baseline HART model | 0.30 |
| AAI143‑H50 | HART-enabled input, standard temp | Classic style HART input | 0.30 |
| AAI143‑S53 | Standard analog input, G3 wide-temperature | Wide-temp analog only | 0.30 |
| AAI143‑H53 | HART + G3 wide-temp analog input | Combines HART with extended temperature | 0.30 |
Popular Models from the Same Brand
| Model | Function | Typical Use Case | Weight (kg) |
|---|---|---|---|
| AAI143‑H03 S1 | HART analog input (wide-temp) | Rugged, diagnostic-enabled monitoring | 0.30 |
| AAI543‑S00 | Analog output module | Driving analog control or indicators | ~0.40 |
| AAI141‑H00 | Non-isolated analog input | Cost-effective analog input solutions | 0.30 |
| ADV151‑P00 | Digital output module | Control outputs (e.g., relays or alarms) | ~0.30 |
| PW482‑10 | Power supply module | Power provisioning for DCS racks | ~0.50 |
Frequently Asked Questions (FAQ)
Q1: What does the “H03” suffix specify?
A1: It denotes full HART communication plus the ISA G3 option for wide-temperature (−20 °C to +70 °C).
Q2: Are the 16 channels isolated?
A2: Yes—each channel is isolated with 1,500 VAC withstand voltage to the system.
Q3: Can I wire 2‑wire and 4‑wire transmitters on the same module?
A3: Yes—each channel can be configured independently via pins.
Q4: What is the data refresh rate?
A4: Approximately 10 ms per channel, ensuring fast process visibility.
Q5: How accurate is its analog reading?
A5: ±16 µA accuracy, suitable for precise control loops.
Q6: Does it support remote diagnostics?
A6: Yes—HART communication allows in-line diagnostics without extra wiring.
Q7: What temperature conditions can it handle?
A7: It’s rated for operation from −20 °C to +70 °C under G3 option.
Q8: What are its physical size and weight?
A8: Dimensions are roughly 107.5 × 32.8 × 130 mm, and it weighs ~0.30 kg.
Q9: Is calibration required after installation?
A9: No—factory calibrated and ready for plug-and-play installation.
Q10: How much power does it consume?
A10: Around 230 mA @ 5 V DC or about 540 mA @ 24 V DC.
