Product Overview: AAI143‑H00 S2
The AAI143‑H00 S2 is a rugged, high-density analog input module designed for use in Distributed Control Systems (DCS). It features 16 isolated channels, each accepting 4–20 mA field signals and equipped with HART digital communication capability. The S2 designation signifies enhanced sealing—specifically, dust and splash resistance—enabling reliable operation in tougher local environments such as control rooms adjacent to active process areas.
Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | AAI143‑H00 S2 |
| Input Channels | 16 (fully isolated) |
| Input Signal Type | 4–20 mA |
| HART Communication | Yes—enabled on each channel |
| Isolation Voltage | 1,500 VAC (input to system, sustained 1 minute) |
| Input Accuracy | ±16 µA |
| Data Update Interval | Approximately 10 ms per channel |
| Transmitter Supply Voltage | ≥ 19 V (at 20 mA), ≤ 25.5 V (at 0 mA), max 25 mA per channel |
| Wiring Configuration | Individually configurable for 2‑wire or 4‑wire transmitters |
| Power Supply Draw | ~230 mA at 5 V DC; ~540 mA at 24 V DC |
| Stability / Temperature Drift | ±16 µA per 10 °C change |
| Operating Temperature | –20 °C to +60 °C |
| Protection Level | Enhanced dust and splash resistance (S2 variant rating) |
| Weight (kg) | 0.30 kg |
| External Size (approx.) | 107.5 × 32.8 × 130 mm |
Applications
This module is suited for industrial automation systems requiring robust analog data acquisition. The S2 variant, with its protective gasketing and sealing, makes it ideal for installation in semi-exposed control panels—such as those in chemical processing zones or near mechanical equipment—where dust, airborne particulates, or incidental moisture are present.
Key Advantages
-
Robust Environmental Protection – Dust and splash-resistant housing safeguards critical electronics.
-
HART Intelligent Input – Enables digital diagnostics and parameterization alongside analog reading.
-
High Channel Capacity – 16 fully isolated inputs in a compact form drastically reduces panel footprint.
-
Superior Signal Integrity – High isolation voltage prevents interference and ground-loop issues.
-
Fast Performance – ~10 ms update rate supports responsive automation and control loops.
-
Flexible Transmitter Setup – Every channel supports both 2‑wire and 4‑wire devices.
-
Lightweight and Compact – Simplifies cabinet integration and reduces rack load.
Brand & Series Information
Brand: Yokogawa
A global leader in industrial automation, recognized for precision, durability, and innovation.
Series: AAI143 analog input modules
This series supports high-density analog inputs for DCS applications, with variants for HART communication, wide temperature range, and sealed enclosures.
Related Models (Same Series or Compatible)
| Model | Description | Key Feature | Weight (kg) |
|---|---|---|---|
| AAI143‑H00 S2 | Analog input with HART, sealed | Dust/splash-resistant enclosure | 0.30 |
| AAI143‑H00 S1 | Analog input with HART, standard | Standard protection | 0.30 |
| AAI143‑H50 | HART-enabled input, basic design | Analog plus digital | 0.30 |
| AAI143‑S53 | Standard input, high temp rating | –20 °C to +70 °C capability | 0.30 |
| AAI143‑H53 | HART + high temp | High temp and digital diagnostics | 0.30 |
Popular Models from the Same Brand
| Model | Function | Typical Application | Weight (kg) |
|---|---|---|---|
| AAI143‑H00 S2 | Sealed analog/HART input module | Semi-exposed control environments | 0.30 |
| AAI543‑S00 | Analog output module | Driving control valves or indicators | ~0.40 |
| AAI141‑H00 | Non-isolated analog input module | Budget-friendly signal capture | 0.30 |
| ADV151‑P00 | Digital output module | Actuator control or alarms | ~0.30 |
| PW482‑10 | Power supply module | System power provisioning | ~0.50 |
Frequently Asked Questions (FAQ)
Q1: What level of environmental protection does the S2 variant offer?
A1: It includes enhanced sealing to resist dust ingress and splash exposure—suitable for semi-open panel environments.
Q2: Does this module include digital communication?
A2: Yes—HART protocol is supported on every channel for diagnostics and parameters.
Q3: Can I use both 2‑wire and 4‑wire transmitters?
A3: Yes—wiring options can be set individually per channel.
Q4: How resilient is the signal connection?
A4: Isolation up to 1,500 VAC prevents interference and protects system integrity.
Q5: How fast does it update channel readings?
A5: Approximately 10 ms per channel for real-time data responsiveness.
Q6: Is this module ready for hot environments?
A6: It operates reliably between –20 °C and +60 °C.
Q7: What is the module’s weight and form factor?
A7: Compact at roughly 107 × 33 × 130 mm and 0.30 kg—easy to mount in field enclosures.
Q8: Does it require post-install calibration?
A8: No—factory-calibrated and ready for use upon installation.
Q9: Can it handle ground loop issues?
A9: High isolation prevents ground loops and ensures clean analog data.
Q10: Is it suitable for control panels near processing equipment?
A10: Yes—the S2’s sealed design makes it well-suited to panels near dusty or splash-prone areas.
