Product Overview: AAI143‑H00/A4S00
The AAI143‑H00/A4S00 is an isolated analog input module engineered for use within industrial distributed control systems. It supports 16 channels of 4–20 mA inputs, with the “H00” portion indicating built-in HART communication support and the “A4S00” marking a specific modular form tailored for high-density rack integration. Ideal for compact control cabinets, it balances precision analog data capture with digital diagnostics capability.
Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | AAI143‑H00/A4S00 |
| Input Channels | 16 (fully isolated) |
| Input Signal | 4–20 mA (standard analog) |
| Isolation Voltage | 1,500 VAC (input to system, sustained 1 minute) |
| Measurement Accuracy | ±16 µA |
| Data Update Rate | Approximately 10 ms per channel |
| Transmitter Supply Voltage | ≥ 19 V @ 20 mA; ≤ 25.5 V @ 0 mA (max 25 mA per channel) |
| Wiring Configuration | Switchable per-channel: 2‑wire or 4‑wire transmitters |
| Power Consumption | ~230 mA @ 5 V DC; ~540 mA @ 24 V DC |
| HART Communication | Yes — Full bi-directional support |
| Temperature Drift | ±16 µA per 10 °C |
| Operating Temperature | –20 °C to +60 °C |
| Protection Level | Standard industrial environment |
| Weight (kg) | 0.30 kg |
| External Dimensions (approx.) | 107.5 × 32.8 × 130 mm |
Applications
This module is commonly used in industrial automation systems for monitoring multiple analog field instruments. It is suited to sectors such as petrochemical, power generation, water treatment, and chemical manufacturing. The inclusion of HART communication allows for device diagnostics without dedicated wiring, making it perfect for systems requiring advanced monitoring in compact spaces.
Key Advantages
-
High Channel Density – Captures 16 analog channels in one modular unit.
-
Integrated HART – Enables smart diagnostics and parameter tuning while maintaining analog signal flow.
-
Robust Signal Isolation – 1,500 VAC isolation guards against interference and ground loops.
-
Fast Data Refresh – Approx. 10 ms update ensures responsive control.
-
Flexible Wiring – Choose per channel between 2‑wire or 4‑wire transmitter connections.
-
Compact & Lightweight – At 0.30 kg and compact size, it optimizes cabinet space use.
-
Reliable & Rugged – Designed for continuous operation in standard industrial conditions.
Brand & Series Information
Brand: Yokogawa
A trusted leader in industrial automation with a legacy of precision, reliability, and innovation in control systems.
Series: AAI143 modules
Part of a modular I/O family for distributed control systems, with variations tailored for analog inputs (with or without HART), wide-temperature rating, and environmental sealing.
Related Models (Same Series or Similar)
| Model | Description | Key Feature | Weight (kg) |
|---|---|---|---|
| AAI143‑H00/A4S00 | HART analog input in compact rack module | Current model | 0.30 |
| AAI143‑S50 | Standard analog input (no HART) | Basic signal capture | 0.30 |
| AAI143‑H50 | HART analog input in standard format | Diagnostics plus analog | 0.30 |
| AAI143‑S53 | Wide-temperature analog input | –20 °C to +70 °C support | 0.30 |
| AAI143‑H53 | HART + wide-temperature | Smart input for harsh environments | 0.30 |
Popular Models from the Same Brand
| Model | Function | Typical Application | Weight (kg) |
|---|---|---|---|
| AAI143‑H00/A4S00 | Compact HART analog input | High-density DCS I/O rack | 0.30 |
| AAI543‑S00 | Analog output module | Driving analog actuators or indicators | ~0.40 |
| AAI141‑H00 | Non-isolated analog input | Budget and lower panel space usage | 0.30 |
| ADV151‑P00 | Digital output module | Actuator control, alarms | ~0.30 |
| PW482‑10 | Power supply module | Panel or I/O rack power provisioning | ~0.50 |
Frequently Asked Questions (FAQ)
Q1: How many channels does the module support?
A1: Sixteen isolated 4–20 mA channels.
Q2: Does the module support HART communication?
A2: Yes—HART is fully supported on all channels.
Q3: Are the channels isolated?
A3: Yes, with 1,500 VAC isolation between inputs and the control system.
Q4: What is the module’s measurement accuracy?
A4: ±16 µA accuracy.
Q5: How quickly does it update data?
A5: Approximately every 10 ms per channel.
Q6: What wiring options are available?
A6: Each channel can be configured for either 2‑wire or 4‑wire transmitters.
Q7: What is its typical operating temperature range?
A7: –20 °C to +60 °C.
Q8: Does the module require calibration?
A8: No, it is factory calibrated and ready for use.
Q9: What are its dimensions and weight?
A9: About 107.5 × 32.8 × 130 mm, weighing approximately 0.30 kg.
Q10: Is the power requirement high?
A10: It draws about 230 mA at 5 V DC or 540 mA at 24 V DC.
