Product Overview
The Siemens 6AG1195-7HC00-2XA0 Active Bus Module is a compact industrial automation component designed to support the modular architecture of Siemens distributed I/O systems. As an Active Bus Module within the SIPLUS ET 200 product family, it forms part of the infrastructure used to interconnect compatible modules and maintain an organized distributed I/O station.
Distributed I/O technology is widely used in modern factory automation, machine control, process equipment, and infrastructure systems. Instead of routing every field signal to a central control cabinet, distributed I/O stations can be installed closer to sensors and actuators. This reduces field wiring complexity and allows control systems to be constructed from modular components. The active bus infrastructure is an important part of this architecture because it provides the internal system connections required by the installed modules.
The Siemens 6AG1195-7HC00-2XA0 has specified dimensions of 97 × 92 × 30 mm and a weight of 0.127 kg. Its compact design makes it suitable for industrial control cabinets and modular I/O installations where efficient use of available space is important.
The 6AG1195-7HC00-2XA0 is not a standalone PLC, CPU, or conventional signal-processing module. Its function is associated with the internal infrastructure of a compatible distributed I/O station. Therefore, correct selection should always be based on the complete system configuration, including the controller, interface components, I/O modules, bus architecture, power arrangement, and field wiring.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Siemens |
| Model | 6AG1195-7HC00-2XA0 |
| Product Type | Active Bus Module |
| Product Family | SIPLUS ET 200 |
| System Function | Modular I/O bus infrastructure |
| Primary Role | Internal module interconnection |
| Dimensions (H × W × D) | 97 × 92 × 30 mm |
| Weight | 0.127 kg |
| Installation | Distributed I/O station |
| Mounting Environment | Industrial automation cabinet |
| Application | Industrial automation and distributed I/O |
| Typical Systems | Siemens modular automation architectures |
| Typical Applications | Machine automation, factory automation, process control, distributed I/O |
What Is the Siemens 6AG1195-7HC00-2XA0?
The Siemens 6AG1195-7HC00-2XA0 is an Active Bus Module intended for use within a compatible Siemens SIPLUS ET 200 distributed I/O architecture.
In a modular I/O system, multiple electronic modules must operate together as one coordinated station. Digital input modules acquire discrete signals, digital output modules control field devices, and analog modules handle continuous process signals. These electronic components require a common infrastructure for their physical and electrical interconnection.
The active bus module is part of this infrastructure.
Its purpose is therefore different from that of a PLC CPU or an I/O signal module. Instead of executing application logic or directly processing field signals, it supports the internal organization of the distributed I/O station.
This makes the component particularly important when designing or maintaining modular systems in which reliability of the internal bus connection is essential.
Understanding the Active Bus Module
The term Active Bus Module refers to a component that participates in the internal bus architecture of a modular automation station.
In a distributed I/O system, the bus architecture provides the communication path between the individual station components. This allows the controller to exchange process data with the appropriate I/O modules.
A simplified architecture can be represented as:
PLC → Industrial Network → I/O Interface → Active Bus Infrastructure → I/O Modules → Field Devices
The exact system architecture depends on the selected Siemens components, but the principle remains the same: the bus infrastructure connects the individual modules into a coordinated automation station.
This modular approach provides significant advantages for industrial system designers.
Function and Working Principle
The 6AG1195-7HC00-2XA0 supports several aspects of distributed I/O system construction.
Internal Module Interconnection
The active bus module provides part of the infrastructure required for compatible modules to operate together.
Instead of treating every I/O module as an isolated device, the modular station allows multiple components to share a common system architecture.
Bus Infrastructure
Reliable internal communication is essential for distributed I/O.
The active bus structure allows data and system information to be exchanged between the station’s components and the external automation controller.
Modular Expansion
A modular bus architecture makes it easier to construct I/O stations according to the application requirements.
For example, a machine may require a combination of:
- Digital input modules
- Digital output modules
- Analog input modules
- Analog output modules
- Technology modules
- Communication modules
- Power-related components
The modular infrastructure allows the station to be configured around these requirements.
Maintenance Support
The modular design also simplifies maintenance. A technician can identify individual system components and investigate them separately instead of replacing the complete I/O station.
Role in Distributed Automation
The Siemens 6AG1195-7HC00-2XA0 occupies an infrastructure position within a distributed automation system.
A complete system may contain:
- PLC controller
- Industrial Ethernet infrastructure
- Distributed I/O interface
- Active bus components
- Digital I/O modules
- Analog I/O modules
- Power modules
- Terminal components
- Sensors
- Actuators
- HMI devices
- Supervisory control systems
The PLC executes the control logic. The network transfers information between the controller and remote I/O. I/O modules interface directly with field devices, while bus infrastructure supports the internal organization of the I/O station.
This separation of functions provides a scalable approach to industrial automation.
Why the Internal Bus Is Important
The internal bus is an important part of any modular distributed I/O system.
Consider a typical process signal:
Sensor → I/O Channel → Internal Bus → I/O Interface → Network → PLC
A problem with the sensor normally affects one signal.
A problem with an I/O module may affect one group of channels.
However, an infrastructure problem can potentially affect multiple modules simultaneously.
This is why the active bus module should be considered during troubleshooting when several I/O modules show communication or availability problems at the same time.
Industrial Applications
The Siemens 6AG1195-7HC00-2XA0 Active Bus Module can be incorporated into compatible SIPLUS ET 200 distributed automation systems.
Factory Automation
Distributed I/O is commonly used in:
- Assembly lines
- Packaging machinery
- Conveyor systems
- Automated production cells
- Robotic systems
- Material handling equipment
- Inspection machines
Remote I/O stations can be positioned close to the equipment they control, reducing field wiring requirements.
Machine Building
Machine builders can use modular distributed I/O to create standardized control architectures.
A common platform can be adapted to different machine configurations by changing the required I/O modules.
Process Automation
Distributed I/O can be used near:
- Pumps
- Valves
- Flow instruments
- Pressure sensors
- Temperature transmitters
- Level measurement equipment
This approach can simplify field wiring and improve system organization.
Water and Wastewater
Distributed control stations can monitor and control equipment throughout treatment facilities, including pumps, valves, motors, and instrumentation.
Energy and Infrastructure
The modular I/O concept can also be used in utility systems, equipment monitoring, and infrastructure automation.
Installation Considerations
The active bus module should be installed according to the requirements of the compatible Siemens distributed I/O architecture.
Before installation, engineers should confirm:
- Complete order number
- Correct product family
- Compatible system architecture
- Required mounting position
- Adjacent module configuration
- Electrical arrangement
- Hardware configuration in the engineering project
The specified dimensions of the 6AG1195-7HC00-2XA0 are 97 × 92 × 30 mm. Cabinet space should therefore be considered together with the dimensions of adjacent modules and wiring.
The specified weight is 0.127 kg, which is relatively low for an industrial automation component. Nevertheless, the complete modular assembly must be securely installed.
Mechanical Installation
A careful mechanical installation process should include:
- De-energize the relevant equipment according to the site’s safety procedures.
- Verify the part number before installation.
- Inspect the component for visible damage.
- Confirm the correct mounting location.
- Install the active bus module in the appropriate system position.
- Check alignment with adjacent components.
- Confirm proper mechanical engagement.
- Inspect the complete station before power is restored.
Incorrect installation may result in poor connections and intermittent communication problems.
System Integration
The 6AG1195-7HC00-2XA0 should be treated as part of the complete distributed I/O architecture.
A typical control system can be divided into several layers.
Control Layer
The PLC executes the application program and determines machine or process behavior.
Communication Layer
The industrial network transfers process data and diagnostic information between the controller and remote I/O.
Interface Layer
The interface components connect the distributed station to the controller network.
Internal Bus Layer
The active bus infrastructure provides the internal interconnection between compatible station components.
I/O Layer
The electronic I/O modules process field signals.
Field Layer
Sensors, actuators, valves, motors, switches, and other devices interact with the physical process.
Understanding these layers makes both engineering and troubleshooting more systematic.
Commissioning Procedure
A structured commissioning procedure is recommended after installing or replacing an active bus module.
Hardware Verification
Confirm that the physical station matches the approved hardware configuration.
Check:
- Module order
- Part numbers
- Station layout
- Associated I/O modules
- Interface components
Mechanical Inspection
Verify that all components are correctly seated and mechanically secure.
Power Inspection
Check the station power supply and grounding arrangement before operation.
Network Verification
Confirm that the PLC can communicate with the distributed I/O station.
Diagnostic Verification
Review controller and I/O diagnostic information for communication or configuration problems.
I/O Testing
Test representative input and output channels.
Functional Testing
Operate the machine or process under controlled conditions and confirm that the distributed I/O behaves as expected.
Troubleshooting the 6AG1195-7HC00-2XA0
Troubleshooting should focus on the complete signal path rather than immediately replacing the active bus module.
A practical diagnostic sequence is:
Field Device → Wiring → I/O Module → Internal Bus → Interface → Network → PLC
The scope of the fault is particularly useful.
Single Channel Failure
If only one channel fails, investigate:
- Field device
- Field wiring
- Terminal connection
- Individual I/O channel
- PLC logic
The active bus module is not normally the first item to inspect in this situation.
Multiple Channels on One Module
Investigate:
- I/O module
- Module power
- Wiring
- Configuration
- Internal connections
Several Modules Fail Simultaneously
In this case, the diagnostic priority should include:
- Station power
- Internal bus infrastructure
- Interface components
- Communication network
- Hardware configuration
Common Fault Conditions
Station Communication Loss
Possible causes include:
- Network interruption
- Interface problem
- Station power loss
- Hardware configuration mismatch
- Internal bus problem
Check the controller diagnostics and determine whether the entire station or only selected modules are affected.
Intermittent Communication
Possible causes include:
- Poor mechanical contact
- Vibration
- Contamination
- Power instability
- Electrical interference
- Aging components
Intermittent faults should be correlated with machine operating conditions whenever possible.
Module Recognition Problem
If an installed module is not correctly recognized, compare the physical configuration with the engineering project.
Check:
- Module position
- Hardware identification
- System configuration
- Internal bus connections
- Interface communication
Preventive Maintenance
Preventive maintenance of the complete distributed I/O station can reduce unexpected downtime.
Recommended activities include:
- Inspect the active bus module during scheduled shutdowns.
- Check mechanical seating of the modular station.
- Inspect surrounding components for contamination.
- Check for signs of overheating.
- Review communication diagnostics.
- Inspect field wiring.
- Maintain accurate electrical documentation.
- Keep replacement parts correctly identified.
- Record recurring faults.
Control cabinets should also be maintained in a clean and suitable industrial environment.
Replacement Guidelines
Before replacing a Siemens 6AG1195-7HC00-2XA0, verify the exact part number and system requirements.
| Identification | Specification |
|---|---|
| Manufacturer | Siemens |
| Full Model | 6AG1195-7HC00-2XA0 |
| Product Type | Active Bus Module |
| Product Family | SIPLUS ET 200 |
| Dimensions | 97 × 92 × 30 mm |
| Weight | 0.127 kg |
A visually similar component should not automatically be considered a suitable substitute.
The full order number should be checked against the system documentation and existing hardware.
After replacement, the complete station should be inspected and tested before returning the machine to normal operation.
Spare-Part Management
For critical automation systems, maintaining an appropriate spare-parts inventory can significantly reduce recovery time.
A useful inventory may include:
- Active bus modules
- Interface modules
- Digital I/O modules
- Analog I/O modules
- Power modules
- Communication components
- Terminal components
The spare 6AG1195-7HC00-2XA0 should be stored in a clean and controlled environment and protected against:
- Moisture
- Dust
- Mechanical impact
- Electrostatic discharge
- Excessive environmental conditions
The full Siemens order number should be recorded in the maintenance database and spare-parts list.
Engineering Best Practices
Maintain Accurate Hardware Documentation
The actual installed station should match the electrical documentation and PLC hardware configuration.
Identify Fault Scope Before Replacement
Determine whether the fault affects one channel, one module, several modules, or the entire station.
This simple diagnostic step can prevent unnecessary replacement.
Check Physical and Logical Conditions Separately
A communication fault may originate from:
- Hardware
- Wiring
- Power
- Network
- Configuration
- Software
Separating these categories makes troubleshooting more efficient.
Record Maintenance History
Each replacement should be documented with:
- Component part number
- Installation location
- Replacement date
- Failure symptoms
- Diagnostic findings
- Final test result
This information can reveal recurring system-level problems.
Advantages of the Siemens 6AG1195-7HC00-2XA0
The Siemens 6AG1195-7HC00-2XA0 Active Bus Module offers practical benefits as part of a compatible distributed I/O system:
- Compact 97 × 92 × 30 mm form factor
- Low specified weight of 0.127 kg
- Supports modular distributed I/O architecture
- Provides active bus infrastructure
- Helps organize multi-module I/O stations
- Supports scalable automation system design
- Suitable for space-conscious control cabinets
- Facilitates modular maintenance
- Supports distributed field-level automation
- Useful for machine and process control applications
Technical FAQs
What is Siemens 6AG1195-7HC00-2XA0?
The 6AG1195-7HC00-2XA0 is a Siemens Active Bus Module designed to form part of a compatible SIPLUS ET 200 distributed I/O architecture.
What are the dimensions of the 6AG1195-7HC00-2XA0?
The specified dimensions are 97 × 92 × 30 mm.
What is the weight of the Siemens 6AG1195-7HC00-2XA0?
The specified weight is 0.127 kg.
Is this component a PLC?
No. The 6AG1195-7HC00-2XA0 is an Active Bus Module. It provides infrastructure within a modular distributed I/O system rather than executing PLC application logic.
What is the purpose of an active bus module?
An active bus module supports the internal interconnection and bus architecture of compatible distributed I/O modules, allowing them to operate as part of a coordinated station.
Can an active bus module affect multiple I/O modules?
Potentially, yes. Because it is associated with the internal bus infrastructure, a problem in this part of the system can affect multiple modules. The actual impact depends on the system architecture and location of the fault.
How should the 6AG1195-7HC00-2XA0 be diagnosed?
Start by determining the scope of the problem. Check station power, physical installation, module configuration, controller diagnostics, communication infrastructure, and internal bus connections before replacing hardware.
What should be checked before ordering a replacement?
Always verify the complete order number 6AG1195-7HC00-2XA0, product type, dimensions, existing station architecture, associated modules, and system documentation.
Conclusion
The Siemens 6AG1195-7HC00-2XA0 Active Bus Module is a compact component designed to support the modular infrastructure of compatible SIPLUS ET 200 distributed I/O systems. With specified dimensions of 97 × 92 × 30 mm and a weight of 0.127 kg, it is well suited to industrial control cabinets where space efficiency and modular system construction are important.
The component does not function as a standalone PLC or conventional I/O module. Instead, it contributes to the internal bus architecture that connects compatible modules within a distributed I/O station. This makes it an important supporting element in systems that require scalable, organized, and maintainable automation hardware.
For machine builders, system integrators, and industrial maintenance engineers, the 6AG1195-7HC00-2XA0 should be evaluated as part of the complete automation architecture. Proper mechanical installation, accurate hardware configuration, systematic fault diagnosis, and appropriate spare-part management can help maintain the reliability and serviceability of distributed Siemens automation systems.
